EVM User's Guide: BQ25750

BQ25750 Evaluation Module

Description

The BQ25750EVM evaluation module (EVM) is a

complete evaluation system for the BQ25750 IC, a

buck-boost battery charge controller with direct power

path control. The BQ25750 has a wide input range of

4.2 V – 70 V, a wide output voltage range of up to 70

V, and bi-directional capabilities.

The BQ25750EVM has a max input and output of 55

V and a max charge current of 10 A.

Get Started

1. Order the EVM on ti.com

2. Order the EV2400 to communicate with the EVM

3. Download the BQ25750 BQZ file

4. Download the BQ25750 EVM design files on

ti.com

Features

• Wide input voltage operating range: 4.2 V – 55 V

• Wide output operating range: up to 55 V with

CC/CV support for:

– 2 to 13–Cell Li-Ion

– 2 to 14–Cell LiFePO4

• Synchronous buck-boost DC/DC charge controller

with NFET drivers

– Adjustable switching frequency from 200 kHz to

600 kHz

– Optional synchronization to external clock

– Optional gate driver supply input for optimized

efficiency

• Resistor-programmable stand-alone with added

I2C mode

• Built in MPPT to maximize power from solar panel

arrays

• Power up from battery (reverse-mode) output 4 V

to 55 V

• High safety integration

– Adjustable input overvoltage and undervoltage

protection

– Output overvoltage and overcurrent protection

www.ti.com Description

SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

BQ25750 Evaluation Module 1

1 Evaluation Module Overview

1.1 Introduction

The BQ25750EVM evaluates for applications that use greater than a 100 W USB input with the new USB-C

Power Delivery (PD) Extended Power Range (EPR) and up to 13 cell Li-Ion battery charging implementing

CC/CV profile. Typical applications include medical equipment, solar backup chargers, energy storage systems,

drones, cordless power and garden tools.

This EVM does not include the EV2400 or USB2ANY interface device and does not provide any electrical

isolation for the digital interfaces. EV2400 or USB2ANY can be ordered separately to evaluate the

BQ25750EVM and considering electrical safety is important when interfacing between the PC and EVM board.

When interfacing the EVM to the PC through the digital interfaces, digital isolators with isolation boundary is

recommended.

The BQ25750EVM does not have an isolation boundary and has smaller clearance and creep than normally

used on high-voltage boards. If the user applies high voltage to this board, all terminals are considered high

voltage and hazardous when live. Electric shock is possible when connecting the board to live wire. The board

must be handled by a professional with care. TI recommends the use of isolated test equipment with safety

protection features (such as overvoltage and overcurrent).

1.2 Kit Contents

This EVM kit includes:

• 1 BQ25750 EVM

1.3 Device Information

The BQ25750EVM evaluation module (EVM) is an evaluation system for the BQ25750 IC. The BQ25750 IC is a

buck-boost battery charge controller with direct power path control. The BQ25750 has a wide input range of 4.2

V – 70 V, a wide output voltage range of up to 70 V, and bi-directional capabilities.

The device offers high-efficiency battery charging with accurate charge current and charge voltage regulation

over a wide voltage range. The design also includes automatic charge preconditioning, termination, and charge

status indication. The device integrates loop compensation for the buck-boost converter, which provides a

high-density design with ease of use. In reverse mode, the device draws power from the battery and regulates

the SYS terminal voltage.

The device supports stand-alone charging mode through resistor programmable limits in addition to the I2C

host-controlled charging mode. Input current, charge current, and charge voltage regulation targets are set

through the ILIM_HIZ, ICHG and FB pins, respectively.

Evaluation Module Overview www.ti.com

2BQ25750 Evaluation Module SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

1.4 Texas Instruments High Voltage Evaluation User Safety Guidelines

WARNING

Always follow TI's set-up and application instructions, including use of all interface components within their

recommended electrical rated voltage and power limits. Always use electrical safety precautions to help verify

your personal safety and those working around you. Contact TI's Product Information Center http://ti.com/

customer support for further information.

Save all warnings and instructions for future reference.

WARNING

Failure to follow warnings and instructions can result in personal injury, property damage or death

due to electrical shock and burn hazards.

The term TI HV EVM refers to an electronic device typically provided as an open framed, unenclosed printed

circuit board assembly. It is intended strictly for use in development laboratory environments, solely for qualified

professional users having training, expertise and knowledge of electrical safety risks in development and

application of high voltage electrical circuits. Any other use and/or application are strictly prohibited by Texas

Instruments. If you are not suitably qualified, then you need to immediately stop from further use of the HV EVM.

1. Work Area Safety:

a. Keep work area clean and orderly.

b. Qualified observers must be present anytime circuits are energized.

c. Effective barriers and signage must be present in the area where the TI HV EVM and the interface

electronics are energized, indicating operation of accessible high voltages can be present, for the

purpose of protecting inadvertent access.

d. All interface circuits, power supplies, evaluation modules, instruments, meters, scopes, and other related

apparatus used in a development environment exceeding 50Vrms/75VDC must be electrically located

within a protected Emergency Power Off EPO protected power strip.

e. Use stable and non-conductive work surface.

f. Use adequately insulated clamps and wires to attach measurement probes and instruments. No

freehand testing whenever possible.

2. Electrical Safety:

a. As a precautionary measure, a good engineering practice to assume is that the entire EVM can have

fully accessible and active high voltages.

b. De-energize the TI HV EVM and all the inputs, outputs and electrical loads before performing any

electrical or other diagnostic measurements. Re-validate that TI HV EVM power has been safely de-

energized.

c. With the EVM confirmed de-energized, proceed with required electrical circuit configurations, wiring,

measurement equipment hook-ups and other application needs, while still assuming the EVM circuit and

measuring instruments are electrically live.

d. Once EVM readiness is complete, energize the EVM as intended.

WARNING

While the EVM is energized, never touch the EVM or the electrical circuits, as the electrical

circuits and EVM can be at high voltages capable of causing electrical shock hazard.

3. Personal Safety

a. Wear personal protective equipment e.g. latex gloves or safety glasses with side shields or protect EVM

in an adequate lucent plastic box with interlocks from accidental touch.

Limitation for safe use:

EVMs are not to be used as all or part of a production unit.

www.ti.com Evaluation Module Overview

SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

BQ25750 Evaluation Module 3

1.4.1 General Safety Information

The following warnings and cautions are noted for the safety of anyone using or working close to the BQ25750

EVM. Observe all safety precautions.

Warning Caution

The BQ25750EVM circuit module can become hot during operation due to the

dissipation of heat. Avoid contact with the board. Follow all safety procedures

applicable to your laboratory.

CAUTION

Hot surface. Contact can cause burns. Do not touch!

Warning

The BQ25750EVM does not have an isolation boundary and has smaller clearance

and creep than normally used on high-voltage boards. If the user applies high

voltage to this board, all terminals are considered high voltage and hazardous

when live. Electric shock is possible when connecting the board to live wire. The

board must be handled by a professional with care. TI recommends the use of

isolated test equipment with safety protection features (such as overvoltage and

overcurrent).

Warning

High voltages that can cause injury exist on this evaluation module (EVM). Please

follow all safety procedures when working on this EVM. Never leave a powered

EVM unattended.

Warning High voltage can be present on board capacitors after power down. Check and

discharge all on-board energy reservoirs properly after EVM power down.

Caution Do not leave the EVM powered when unattended.

CAUTION

The communication interfaces are not isolated on the EVM. TI recommends the use of digital

isolators. Observe all high voltage safety precautions during testing.

CAUTION

Connections for a rated current must be made at the terminal block. Test points are not rated for the

board current.

CAUTION

The circuit module can be damaged by overtemperature. To avoid damage, monitor the temperature

during evaluation and provide cooling, as needed, for your system environment. Do not operate

beyond the current and voltage limits in Section 2.3.

CAUTION

Test equipment can be damaged by the application of external voltages. Check your equipment

requirements and use blocking diodes or other isolation techniques, as needed, to prevent damage

to your equipment.

CAUTION

The circuit module has signal traces, components, and component leads on the bottom of the board.

Exposed voltages, hot surfaces, or sharp edges can result in these areas. Do not reach under the

board during operation.

Evaluation Module Overview www.ti.com

4BQ25750 Evaluation Module SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

CAUTION

The default settings of the BQ25750 are not designed for all applications. Set the EVM settings

appropriately for test setup before device power up. Set all protections appropriately and limit current

for safe operations.

CAUTION

The board has no fuse installed and relies on the external voltage source current limit for circuit

protection.

www.ti.com Evaluation Module Overview

SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

BQ25750 Evaluation Module 5

2 Hardware

2.1 Board Parameters

Table 2-1. Default Board Setup for BQ25750EVM

Description Value Unit

ACUV Input undervoltage 4.2 V

ACOV Input overvoltage 55 V

IIN Input current of the EVM 8 A

IOUT Output current of the EVM 10 A

FSW_SYNC Switching frequency of the power stage 250 kHz

Table 2-2. PCB and Mechanical Parameters

Value Unit

Board size (X dimension, or length) 112 mm

Board size (Y dimension, or width) 84 mm

IC + power stage max height 5 mm

Total copper layers 6 layer

Copper weight per layer 2 oz

Total board thickness 62 mil

2.2 IO and Jumper Descriptions

Table 2-3. Connector and Port Description

Jack Description

J1-VIN Input: positive terminal

J1-PGND Input: negative terminal (ground terminal)

J2-VSYS Charger system output voltage, typically connected to the system load

J2-PGND Ground

J3-VOUT Connected to battery pack output

J3-PGND Ground

J4-EXT_I2C Communication port for the USB2ANY

J5-I2C Communication port for the EV2400

J6-EXT_DRV Connection for external gate drive

J7-Power Connector Connection for VAC and BAT

J8-Communication Port Connection for EXT_DRV, /INT, I2C, /PG, and 3.3 V

Hardware www.ti.com

6BQ25750 Evaluation Module SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

Table 2-4. Jumper Description

Jumper Description Factory Default

JP1 Use JP1 to connect the default feedback resistor and set the charger to the default 7

cell battery. Installed

JP2 Use JP2 to connect a new feedback resistor to program a different cell count. Not installed

JP3 Use JP3 to connect external IOUT resistor. JP3 can be shorted to PGND to turn off

hardware output current limiting.

Not installed

JP4 Shunt JP4 to use default IOUT resistor. By closing JP4, the default IOUT current is

set to 10 A.

Installed

JP5 Shunt JP5 to bias TS. Installed

JP6 With JP5 shunted (REGN connected for voltage divider). Shunt JP6 to set TS status

to normal.

Installed

JP7 With JP5 shunted (REGN connected for voltage divider). Use JP7 to connect

external resistor to change TS status.

Not installed

JP8 Use JP8 to connect external FSW_SYNC resistor. Not installed

JP9 Shunt JP9 to use default FSW_SYNC resistor. By closing JP9, the default switching

frequency is set to 250 kHz.

Installed

JP10 Shunt JP10 to use default IIN resistor. By closing JP10, the maximum input current

is set to 8 A.

Installed

JP11 Use JP11 to connect external IIN resistor. JP11 can be shorted to PGND to turn off

hardware input current limiting.

Not installed

JP12

Use JP12 to select the gate driver source. Shunt pin1 to pin2 to use IC internal

LDO REGN output. Shunt pin2 to pin3 to use external gate drive supply. Maximum

external gate drive supply can be up to 11 V.

Pin1 and pin2 shunted

JP13 Shunt JP13 to enable controller in forward mode. Open JP13 to disable controller.

The /CE pin can also be used as a general purpose indicator.

Installed

JP14 Shunt JP14 to connect /INT to a pullup rail. Installed

JP15 Shunt JP15 to connect STAT1 to a pullup rail. The STAT1 pin can also be used as a

general purpose indicator.

Installed

JP16 Shunt JP16 to generate on board 3.3-V pullup rail. Installed

2.3 Recommended Operating Conditions

Table 2-5. Recommended Operating Conditions for BQ25750EVM

Description MIN TYP MAX UNIT

VIN (J1) Input voltage to the EVM 4.2 55(1) V

VOUT (J3) Output voltage of the EVM 3.3 55(1) V

IIN (J1) Input current of the EVM 10(3) (4) A

IOUT (J3) Output current of the EVM 10(3) A

Regulator output power Output power of the EVM 400(3) W

EXT_DRV (J6) Voltage applied to DRV_SUP pin of the regulator 4 11 V

EVM Operating Ambient

Temperature (TA) 25(2) °C

(1) Nodes on the EVM can have high spikes above the input voltage (in buck mode) or output voltage (in boost mode) level due to the

high di/dt and dv/dt electrical flow associated with switch-mode power supplies. Switch node voltage can swing up to input or output +

inductive spike level. High-side gate drives can swing up to switch node voltage + 11 V (DRV_SUP supply voltage dependent) + gate

drive inductive spike level. Observe safety precautions at all times.

(2) Connectors, bump-ons, and jumpers on the EVM are not good choices for evaluation under temperatures that greatly deviate from a

room temperature of 25°C. Please refer to the Bill of Materials (BOM) for temperature ratings of board components.

(3) TI recommends thermal monitoring (for example, using a thermal camera) if the power-stage output current > 5 A or total output power

> 100 W.

(4) The default EVM input current limit is set to 8 A through the IIN pin. The current-limiting feature can be turned off by setting the

EN_IIN_PIN bit to '0', changing the IIN pin resistor, or shorting the IIN pin to PGND through JP11.

www.ti.com Hardware

SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

BQ25750 Evaluation Module 7

2.4 Equipment

TI recommends two ways to test the EVM. The first and preferred way to test the EVM is to use a four-quadrant

power supply. The second is to use a electronic load in constant voltage mode. Testing with a constant voltage

load is covered in Section 2.4.3. TI recommends the following list of equipment when testing with a four-quadrant

power supply.

1. Power Supplies:

A power supply capable of supplying 40 V at 8 A is required. This part can handle larger voltage and current,

however, larger power levels are not necessary for this procedure.

2. Load 1:

A Kepco load: BOP36-6M, DC 0 to ±36 V, 0 to ±6 A (or higher), or equivalent. When testing without a real

battery, connect 2000 uF of capacitance across the input.

3. Meters:

Six Fluke 75 multimeters, (equivalent or better) or: Three equivalent voltage meters and three equivalent

current meters.

4. Computer:

A computer with at least one USB port and a USB cable.

5. EV2400 Communication Kit

6. Software:

Download and properly install bqStudio.

2.4.1 Equipment Set Up

EV2400

USB

–

VAC

IAC

VBAT

IBAT



onal Gate

Drive Supply

DMM

VAC

DMM

I2C

Use the following guidelines to set up the equipment:

1. Set power supply 1 for 23 V DC, 8 A current limit and then turn off the supply.

2. Connect the output of power supply 1 in series with a current meter to J1 (VIN and PGND).

3. Connect a voltage meter across J1 (VIN) and J1 (PGND).

4. Connect load 1 in series with a current meter to J3 (VBAT and PGND).

5. Connect a voltage meter across J5 (VBAT and PGND).

6. Set 23 V at KEPCO load output. Limit KEPCO to 6 A. Use load 2 to power EVM from the VOUT output.

7. Connect J5 to the EV2400. Connect J5 to the I2C PORT 2 on the EV2400.

8. Install the jumpers as indicated in IO and Jumper Descriptions.

Hardware www.ti.com

8BQ25750 Evaluation Module SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

9. Turn on the computer and load 2. Open the bqStudio software.

a. Select Charger and click the Next button.

b. Select Charger_1_00_BQ25750.bqz on the Select a Target Page.

c. Click Field View after selecting the target device and then click the Read Register button.

10. Set WATCHDOG and EN_CHG to disabled.

11. Set ICHG_REG to 4000 mA and IPRECHG to 1000 mA in the 16 Bit Registers field.

12. Turn on power supply 1, measure:

V(J1(VAC)) = 23 V ± 0.5 V

I(J1(IAC)) = 4.1 A ± 0.5 A

V(J3(VBAT)) = 23 V ± 0.5 V

I(J3(IBAT)) = 3.9 A ± 0.5 A

13. Set power supply 1 for 40 V, measure:

V(J1(VAC)) = 40 V ± 0.5 V

I(J1(IAC)) = 2.4 A ± 0.5 A

V(J3(VBAT)) = 23 V ± 0.5 V

I(J3(IBAT)) = 3.9 A ± 0.5 A

www.ti.com Hardware

SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

BQ25750 Evaluation Module 9

14. Set power supply 1 for 19 V, measure:

V(J1(VAC)) = 19 V ± 0.5 V

I(J1(IAC)) = 5.0 A ± 0.5 A

V(J3(VBAT)) = 23 V ± 0.5 V

I(J3(IBAT)) = 3.9 A ± 0.5 A

Use the following guidelines to test the BQ25750 EVM power path:

1. Disconnect the power supply from J1 (VIN and PGND) and disconnect Load 1 from J3 (VOUT and PGND).

2. Connect the output of power supply #1 to J3 (VOUT and PGND).

3. Set power supply 1 for 20 V DC, 8 A current limit and then turn off power supply.

4. Connect a voltage meter across J2 (VSYS) and J2 (PGND).

5. Turn on power supply 1, measure V(J2(VSYS)) = 20 V ± 0.5 V.

2.4.2 Equipment - Using a CV Load

The following list of equipment is recommended when testing with a constant voltage electronic load.

1. Power Supplies:

A power supply capable of supplying 40 V at 8 A is required. This part can handle larger voltage and current,

however, larger power levels are not necessary for this procedure.

2. Load 1:

Kikusui PLZ164WA 0-150 V, 0-33 A when testing without a real battery, connect 2000 uF of capacitance

across the input.

3. Meters:

Six Fluke 75 multimeters (equivalent or better) or three equivalent voltage meters and three equivalent

current meters.

4. Computer:

A computer with at least one USB port and a USB cable.

5. EV2400 Communication Kit

6. Software:

Download and properly install bqStudio.

Hardware www.ti.com

10 BQ25750 Evaluation Module SLUUCY7 – NOVEMBER 2023

Submit Document Feedback

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Texas Instruments Unità di controllo

Texas Instruments

Texas Instruments SimpleLink CC3235MODS Manuale utente

Texas Instruments

Texas Instruments bq2023EVM-001 Manuale utente

Texas Instruments

Texas Instruments MCT8316ZTEVM Manuale utente

Texas Instruments

Texas Instruments DRV601EVM Manuale utente

Texas Instruments

Texas Instruments TPS65988EVM Manuale utente

Texas Instruments

Texas Instruments UCC2 5 EVM-286 Series Manuale utente

Texas Instruments

Texas Instruments LMK00725EVM Manuale utente

Texas Instruments

Texas Instruments TMS320 Series Manuale utente

Texas Instruments

Texas Instruments DRV2605LEVM-MD Manuale utente

Texas Instruments

Texas Instruments TMS320C6A816 Series Manuale del prodotto

Texas Instruments

Texas Instruments DP159RSB Manuale utente

Texas Instruments

Texas Instruments TRF7960TB Manuale utente

Texas Instruments

Texas Instruments 2000 series Manuale utente

Texas Instruments

Texas Instruments INA290EVM Manuale utente

Texas Instruments

Texas Instruments TCA5405EVM Manuale utente

Texas Instruments

Texas Instruments AWR1642 Manuale utente

Texas Instruments

Texas Instruments TMS320TCI648 Series Manuale utente

Texas Instruments

Texas Instruments TPS40190EVM-001 Manuale utente

Texas Instruments

Texas Instruments AM437x Manuale utente

Texas Instruments

Texas Instruments SimpleLink CC2652PSIP Manuale utente

Texas Instruments

Texas Instruments TPS54232EVM-415 Manuale utente

Texas Instruments

Texas Instruments SimpleLink Wi-Fi CC3 20 Series Manuale utente

Texas Instruments

Texas Instruments FPD23DAEVM Manuale utente

Texas Instruments

Texas Instruments MCT8316AEVM Manuale utente

Manuali Unità di controllo popolari di altre marche

Festo

Festo Compact Performance CP-FB6-E Manuale elenco delle parti

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuale utente

JS Automation

JS Automation MPC3034A Manuale utente

JAUDT

JAUDT SW GII 6406 Series Guida rapida

Spektrum

Spektrum Air Module System Manuale utente

BOC Edwards

BOC Edwards Q Series Manuale utente

KHADAS

KHADAS BT Magic Manuale utente

Etherma

Etherma eNEXHO-IL Manuale utente

PMFoundations

PMFoundations Attenuverter Manuale utente

GEA

GEA VARIVENT Manuale utente

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuale utente

Altronix

Altronix LINQ8PD Istruzioni per il montaggio

Eaton

Eaton Powerware Series Manuale utente

WAGO

WAGO 750-407/040-000 Manuale utente

Sony

Sony CCU-590 Manuale utente

Graco

Graco 25D614 Manuale utente

Task Force Tips

Task Force Tips YE-RF-900 Manuale di programmazione

Shini

Shini SPV-U Series Manuale utente
