TPS65916 EVM User’s Guide

Windows is a registered trademark of Microsoft Corporation.

All other trademarks are the property of their respective owners.

User's Guide

SLIU021–September 2016

TPS65916 EVM User’s Guide

This user’s guide describes the characteristics, operation, and use of the TPS65916EVM. An EVM

description, graphical user interface (GUI) description, interface requirements, and complete schematic

are included.

Contents

1 Introduction ................................................................................................................... 1

2 Schematics, Bill of Materials, and Layout ................................................................................ 4

3 Setup and Operation....................................................................................................... 16

List of Figures

1 EVM ........................................................................................................................... 2

2 Powered EVM................................................................................................................ 4

3 TPS65916 EVM Schematic (Page 1) ..................................................................................... 5

4 TPS65916 EVM Schematic (Page 2) ..................................................................................... 6

5 TPS65916 EVM Schematic (Page 3) ..................................................................................... 7

6 TPS65916 EVM Schematic (Page 4) ..................................................................................... 8

7 Composite - Top View..................................................................................................... 12

8 Top Layer ................................................................................................................... 13

9 Layer 1 GND................................................................................................................ 13

10 Layer 2 SIGNAL............................................................................................................ 14

11 Layer 3 POWER............................................................................................................ 14

12 Bottom Layer................................................................................................................ 15

13 Composite - Bottom View ................................................................................................ 15

14 Default GPIO Configuration............................................................................................... 16

15 GPIO Configuration After GPIO_1 Set to Logic High ................................................................. 17

16 Low Level Configuration Page............................................................................................ 18

17 Sample Script............................................................................................................... 19

List of Tables

1 Default Jumper Settings for TPS65916EVM............................................................................. 3

2 TPS65916EVM BOM........................................................................................................ 8

1 Introduction

The TPS65916 device is a power-management integrated circuit (PMIC) for industrial and consumer

applications. The device provides five configurable step-down converters, with up to 7 A of output current

for memory, processor core, input/output (I/O), or preregulation of LDOs. The TPS65916 device contains 5

LDO regulators for external use. For more details, see the device datasheet, TPS65916 Power

Management Unit (PMU) for Processor.

SMPS4

SMPS2

SMPS1

LDO outputs

GPIO_0 through GPIO_6

MicroUSB Port

SMPS3

SMPS5

Status LEDs

GND

VCC (3.135V to 5.25V)

Introduction

www.ti.com

2SLIU021–September 2016

Submit Documentation Feedback

TPS65916 EVM User’s Guide

1.1 EVM Overview

The features of this EVM are as follows:

• Allows monitoring of all LDO and SMPS output voltages.

• Allows loading of all SMPS outputs.

• Allows access to the GPIOs and other logic signals to test functionality.

• Optimized layout for stable operation of all SMPS.

• Onboard MSP430 to enable communication with the PMIC.

• Graphical User Interface (GUI) on Windows®to allow access to the registers of the PMIC through

USB-I2C.

1.2 EVM with Components Identified

Figure 1. EVM

LEDs —Display status of POWERGOOD, RESET_IN, POWER_HOLD, LDOVRTC_OUT, RESET_OUT,

INT, and power supply of MSP430

USB —Connection to PC to enable communication through the GUI

MSP430 —Microcontroller used to convert USB data to I2C format

SMPSxx —Monitor point for SMPS outputs

LDO Outputs —Monitor point for LDO outputs

VIO SelectorX —Jumper used to select VIO voltage. P12 requires a jumper installed, and by default pins

11 and 12 are shorted to select external 1.8 V as VIO. Only one jumper should be installed

between P12 and P15.

GPIOs —Jumper that provides access to the GPIOs

VSYS —VSYS power supply input. P16 is the same connector as SMPS12_OUT and must not be

confused to prevent applying VSYS to SMPS-output.

www.ti.com

Introduction

SLIU021–September 2016

TPS65916 EVM User’s Guide

1.3 Default Jumper Settings

Table 1 describes the default jumper settings for the TPS65916 EVM. No changes should be made to

these settings without consulting the TPS65916 EVM schematic.

Table 1. Default Jumper Settings for TPS65916EVM

JUMPER PURPOSE EVM CONFIGURATION

P12 VIO Selection Pins 11 and 12 are shorted to select external 1.8V as VIO

P15 VIO Selection No pins on this header are shorted since there is a shunt on

P12.

J2 POWERGOOD Pull-up resistor J2 is closed to enable the pull-up resistor for the POWERGOOD

signal

J3 Level Shifter Voltage Selection J3 is closed to select VIO as the level shifted voltage for U5,

U6, and U7

J7 I2C or SPI CLK J7 is closed to select the I2C_SCL signal

J10 I2C or SPI Data J10 is closed to select the I2C_SDA signal

J22 GPIO_1 GUI Control J22 is closed to allow GPIO_1 (RESET_IN) to be controlled

through the GUI

J26 GPIO_5 Selection GPIO_5 is shorted HIGH to allow the device to power-up

J30 BOOT Selection BOOT is shorted LOW to exercise the default power-up

sequence

J31 PWRON Selection PWRON is shorted HIGH

J32 LDO5 Input Selection J32 is closed to supply LDO5 from the same supply as the

other LDOs

J35 I2C_SCL Connection to PMIC J35 is closed to use the onboard SCL signal from the MSP430

J36 I2C_SDA Connection to PMIC J36 is closed to use the onboard SDA signal from the MSP430

J43 – J54 Level Shifter Direction Selection and

Enable Jumpers J43 through J54 should be left as they are configured

to enable proper level shifter functionality

JP1 LDO Input Selection JP1 is closed to supply the LDOs from VSYS instead of an

external supply (VDD)

JP2 VCC_SENSE Selection VCC_SENSE is shorted to VSYS instead of an external supply

(VDD)

JP3 D2 Indicator Selection Pins 1 and 2 are shorted to allow the status of POWERGOOD

signal to be indicated by D2

JP6 D5 Indicator Selection Pins 1 and 2 are shorted to allow the status of the

POWER_HOLD signal to be indicated by D5

JP7 D7 Indicator Selection Pins 1 and 2 are shorted to allow the status of the RESET_IN

signal to be indicated by D7

Introduction

www.ti.com

4SLIU021–September 2016

Submit Documentation Feedback

TPS65916 EVM User’s Guide

1.4 Power-Supply Requirements and Connections

To set up the EVM, ensure that VSYS (3.3 V to 5 V) is connected to the pin labeled VSYS of P16, and

that GND is connected to the pin labeled GND of P16.

1.4.1 VIO Selection

As mentioned in Table 1, there are two 12-pin headers (P12 and P15) for selecting the voltage to use for

the VIO supply voltage of the PMIC.

CAUTION

It is important to make sure that there is a total of one shunt populated between

P12 and P15. If there is a shunt on P12, there should not be one on P15 and

vice versa. Also, there should never be more than one shunt on either P12 or

P15. Violating this requirement will short two PMIC outputs together, which

could potentially damage the PMIC device.

Power for the MSP430 and the two fixed voltage LDOs (3.3-V and 1.8-V outputs) is supplied through the

USB connection, as shown in Figure 2.

Figure 2. Powered EVM

2 Schematics, Bill of Materials, and Layout

This section contains the schematics, bill of materials (BOM) and layout for the EVM.
