Thermaltake W0131RU Manuale utente

80 PLUS Verification and Testing Report

TYPICAL EFFICIENCY (50% Load):

AVERAGE EFFICIENCY :

80 PLUS COMPLIANT:

YES

Value

Units

100-240 Volts

10 Amps

47-63 Hz

850

Watts

Note: All measurements were taken with input voltage at 115 V nominal and 60 Hz. Input AC Current Waveform (ITHD = 6.87%, 50% Load)

RMS

-12V

3.3V

5V*

5VSB

1.83 0.98 8.7% 20% Light 207 12.2/0.2 3.3/4.3 5.1/4.3 5.1/0.6 168 81.24%

4.34 0.99 6.9% 50% Typical 496 12.3/0.4 3.3/10.8 4.9/10.8 5/1.5 415 83.72%

8.93 1.00 5.8% 100% Full 1024 12.3/0.8 3.2/21.5 4.9/21.7 4.9/3 821 80.16%

Tested by Electric Power Research Institute, Knoxville, TN.

8/13/2007

Efficiency

Rated Output Power

Load

(%)

Rated Specifications

Input Voltage

Input Current

THD

(%) Input

Watts

Fraction

of Load DC Terminal Voltage (V)/ DC Load Current (A) Output

Watts

12V (cumulative of 12V1, 12V2, etc.)

12.1/10.4

12.1/26.1

12/52.1

Test Date

Input Frequency

338.3

Type

Ecos ID #

Model Number

Serial Number

Year ATX

2007

Manufacturer

83.72%

81.71%

Thermaltake

W0131RU

Input and Output Power

Input Watts

Output Watts

200

400

600

800

1000

1200

20% 50% 100%

Loading (% of Rated Output Power)

Power (Watts)

Efficiency of the Power Supply

30%

40%

50%

60%

70%

80%

90%

0% 25% 50% 75% 100% 125%

Loading (% of Rated Output Power)

Efficiency (%)

Efficiency %

These tests were conducted as a part of the 80 PLUS program. 80 PLUS is

a computer buy-down program to promote high-efficiency power supplies

(greater than 80% efficiency in the active mode) in desktop computers and

desktop-derived servers.

Input Current and Voltage Waveforms

-200

-150

-100

-50

100

150

200

0 0.003 0.006 0.009 0.012 0.015

Time (s)

Voltage (V)

-15

-10

-5

Current (A)

Voltage Current
