Thermaltake W0155RU Manuale utente

80 PLUS Verification and Testing Report

TYPICAL EFFICIENCY (50% Load):

AVERAGE EFFICIENCY :

80 PLUS COMPLIANT:

YES

Value

Units

100-240 Volts

13 Amps

47-63 Hz

1000

Watts

Note: All measurements were taken with input voltage at 115 V nominal and 60 Hz. Input AC Current Waveform (ITHD = 4.9%, 50% Load)

RMS

-12V

3.3V

5V*

5VSB

2.21 0.98 7.6% 20% Light 249 12/0.2 3.3/3.6 5.1/3.6 5.1/0.7 202 81.05%

5.16 1.00 4.9% 50% Typical 590 11.9/0.4 3.2/9.1 5/9.1 4.9/1.7 500 84.71%

10.47 1.00 3.6% 100% Full 1202 12/0.8 3.1/18.1 4.9/18.2 4.7/3.4 983 81.77%

Tested by Electric Power Research Institute, Knoxville, TN.

8/22/2007

Efficiency

Rated Output Power

Load

(%)

Rated Specifications

Input Voltage

Input Current

THD

(%) Input

Watts

Fraction

of Load DC Terminal Voltage (V)/ DC Load Current (A) Output

Watts

12V (cumulative of 12V1, 12V2, etc.)

12.1/13.8

12/34.3

11.8/68.6

Test Date

Input Frequency

334.1

Type

Ecos ID #

Model Number

Serial Number

Year EPS12V

2007

Manufacturer

84.71%

82.51%

Thermaltake

W0155RU

Input and Output Power

Input Watts

Output Watts

200

400

600

800

1000

1200

1400

20% 50% 100%

Loading (% of Rated Output Power)

Power (Watts)

Efficiency of the Power Supply

30%

40%

50%

60%

70%

80%

90%

0% 25% 50% 75% 100% 125%

Loading (% of Rated Output Power)

Efficiency (%)

Efficiency %

These tests were conducted as a part of the 80 PLUS program. 80 PLUS is

a computer buy-down program to promote high-efficiency power supplies

(greater than 80% efficiency in the active mode) in desktop computers and

desktop-derived servers.

Input Current and Voltage Waveforms

-200

-150

-100

-50

100

150

200

0 0.003 0.006 0.009 0.012 0.015

Time (s)

Voltage (V)

-15

-10

-5

Current (A)

Voltage Current
