Thermaltake W0128RU Manuale utente

80 PLUS Verification and Testing Report

TYPICAL EFFICIENCY (50% Load):

AVERAGE EFFICIENCY :

80 PLUS COMPLIANT:

YES

Value

Units

100-240 Volts

8/4 Amps

47-63 Hz

650

Watts

Note: All measurements were taken with input voltage at 115 V nominal and 60 Hz. Input AC Current Waveform (ITHD = 8.02%, 50% Load)

RMS

12V1

12V2

12V3

12V4

-12V

3.3V

5V*

5VSB

1.43 1.00 10.2% 20% Light 162 12/2.2 12/2.2 12.1/2.2 12/2.2 12.1/0.1 3.3/2.7 5/2.6 5.1/0.4 130 80.46%

3.36 0.99 8.0% 50% Typical 384 12/5.5 12/5.5 12/5.5 11.9/5.5 12.1/0.2 3.3/6.9 5/6.4 5/0.9 324 84.28%

6.91 1.00 7.1% 100% Full 792 11.9/10.9 11.9/10.9 12/10.9 11.9/10.9 12.3/0.5 3.2/13.7 5/12.8 5/1.8 643 81.20%

Tested by Electric Power Research Institute, Knoxville, TN.

84.28%

81.98%

Thermaltake

W0128RU

64446649

2006

Manufacturer

Test Date

Input Frequency

157.2

Type

Ecos ID #

Model Number

Serial Number

Year ATX12V

Input

Watts

Fraction

of Load DC Terminal Voltage (V)/ DC Load Current (A) Output

Watts

1/11/2007

Efficiency

Rated Output Power

Load

(%)

Rated Specifications

Input Voltage

Input Current

THD

(%)

Input and Output Power

Input Watts

Output Watts

100

200

300

400

500

600

700

800

900

20% 50% 100%

Loading (% of Rated Output Power)

Power (Watts)

Efficiency of the Power Supply

30%

40%

50%

60%

70%

80%

90%

0% 25% 50% 75% 100% 125%

Loading (% of Rated Output Power)

Efficiency (%)

Efficiency %

These tests were conducted as a part of the 80 PLUS program. 80 PLUS is

a computer buy-down program to promote high-efficiency power supplies

(greater than 80% efficiency in the active mode) in desktop computers and

desktop-derived servers.

Input Current and Voltage Waveforms

-200

-150

-100

-50

100

150

200

0 0.003 0.006 0.009 0.012 0.015

Time (s)

Voltage (V)

-20

-15

-10

-5

Current (A)

Voltage Current
