80 PLUS Verification and Testing Report

TYPICAL EFFICIENCY (50% Load):

AVERAGE EFFICIENCY :

80 PLUS COMPLIANT:

YES

Value

Units

100-240 Volts

15 Amps

47-63 Hz

1200

Watts

Note: All measurements were taken with input voltage at 115 V nominal and 60 Hz. Input AC Current Waveform (ITHD = 4.6%, 50% Load)

RMS

-12V

3.3V

5V*

5VSB

2.57 0.99 6.3% 20% Light 293 12.1/0.2 3.3/4.4 5/4.4 4.9/0.7 241 82.50%

6.15 1.00 4.6% 50% Typical 705 12.1/0.4 3.2/11 4.8/11 4.6/1.7 593 84.06%

12.63 1.00 3.4% 100% Full 1451 12/0.8 3/21.8 4.8/22 4.5/3.4 1162 80.09%

Tested by Electric Power Research Institute, Knoxville, TN.

8/24/2007

Efficiency

Rated Output Power

Load

(%)

Rated Specifications

Input Voltage

Input Current

THD

(%) Input

Watts

Fraction

of Load DC Terminal Voltage (V)/ DC Load Current (A) Output

Watts

12V (cumulative of 12V1, 12V2, etc.)

12.1/16.6

11.9/41.4

11.7/82.8

Test Date

Input Frequency

335.2

Type

Ecos ID #

Model Number

Serial Number

Year EPS12V

2007

Manufacturer

84.06%

82.22%

Thermaltake

W0133RU

Input and Output Power

Input Watts

Output Watts

200

400

600

800

1000

1200

1400

1600

20% 50% 100%

Loading (% of Rated Output Power)

Power (Watts)

Efficiency of the Power Supply

30%

40%

50%

60%

70%

80%

90%

0% 25% 50% 75% 100% 125%

Loading (% of Rated Output Power)

Efficiency (%)

Efficiency %

These tests were conducted as a part of the 80 PLUS program. 80 PLUS is

a computer buy-down program to promote high-efficiency power supplies

(greater than 80% efficiency in the active mode) in desktop computers and

desktop-derived servers.

Input Current and Voltage Waveforms

-200

-150

-100

-50

100

150

200

0 0.003 0.006 0.009 0.012 0.015

Time (s)

Voltage (V)

-15

-10

-5

Current (A)

Voltage Current
