Toa F-1300WTWP Manuale utente
EN 54 Certified Speakers
F-1300WTWP EB-Q
SPEAKER
Article number:F-1300WTWPEB-Q
Alternative products: F-1300BTWP EB-
Q, F-1300WTWP, F-2000WTWP EB-Q,
F-1000BTWP EB-Q, F-1000WTWP EB-Q
Specifications
Sensitivity (1 W, 1 m) 90 dB
Frequency response 80 Hz - 20 kHz (-10 dB)
Connection Screw terminals
Crossover frequency 2000 Hz
Rated input (high impedance) 30 W
Tappings 100 V : 330 Ω (30 W) / 1 kΩ (10 W) / 3.3 kΩ (3 W) / 10 kΩ (1 W)
70 V : 170 Ω (30 W) / 330 Ω (15 W) / 1 kΩ (5 W) / 3.3 kΩ (1.5 W) / 10 kΩ (0.5 W)
Speaker component Woofer: 13 cm (5'') cone-typeTweeter: 25 mm (1'') dome tweeter
Finish HIPS resin, Steel plate, off-white (RAL 9010 or equivalent),
Operating temperature -10°C to + 50°C
We supply sound, not equipment.
www.toa.eu.
©TOA Electronics Europe GmbH | Data subject to change without notice.
EN, 2022/08/18
EN 54 Certified Speakers
F-1300WTWP EB-Q
SPEAKER
Appearance
30 [1.18"]
161 [6.34"]162 [6.38"]
250 [9.84"]
30 [1.18"]
30 [1.18"]
2-M5 (depth 14[0.55"])*
(for bracket mounting)
38 [1.5"]
76.2 [3"]
(for bracket mounting)
4-M5 (depth 14[0.55"])
Rotary switch
Side ViewFront View
SCALE:1/4
UNIT:mm
Bottom View the holes at the factory.
Before attaching the speaker
mounting bracket to this side,
* Hole plugs are pre-fitted into
remove them using a pointed
Rear View
tool.
We supply sound, not equipment.
www.toa.eu.
©TOA Electronics Europe GmbH | Data subject to change without notice.
EN, 2022/08/18
