Features
Image Sensor
oPanasonic 1/2.7”, 2.07 million effective pixels, HD CMOS sensor
oTAMRON high quality telephoto lens supporting 12X/20X/30X optical zoom
oFull HD 1920x1080p resolution up to 60 frames per second
o2D & 3D noise reduction with our latest “low noise CMOS sensor”
o0.05 Lux @ F1.8 AGC On
oWide angle 60.7°horizontal field of view
oDynamic Range Control (DRC) for higher image quality and detail across simultaneously well lit and shadowed
scenes.
oImage Freeze to temporarily pause the video while calling presets (so viewers won‟t see camera movement)
oHigh SNR (signal to noise ratio) of the CMOS sensor (≥55dB), combined with 2D & 3Dnoise reduction algorithms,
effectively reduces noise, even under low illumination conditions.
Video Outputs
oNDI | HX Video Output.
oSimultaneous IP network streaming, 3G-SDI, and HDMI video outputs.
o3G-SDI High Definition video output up to 60 frames per second
oHDMI 1.4 High Definition video output up to 60 frames per second
oRTSP, RTMP, & RTMPS streaming using H.264, H.265,& MJPEG
oLine level audio embedding over IP network stream & HDMI. UsesAAC audio encoding for better sound quality
and lower bandwidth usage.
oSupport for ultra-high FPS mode 1280x720p @ 120 frames per second over IP network stream.
Control and Settings
oNDI PTZ Control
oVISCA over IP
oIR Remote Control
oWeb-based IP remote control interface
oRS232 & RS485 VISCA, Pelco-D, & Pelco-P control
Installation
oStandard 1/4-20 female thread for camera mounting
oPower over Ethernet –Supports 802.3af
o12VDC 2A Power Supply provided for non-PoE infrastructure
Warranty
o3-year warranty
