OWNER’S MANUAL

(WITH DOCUMENT IMAGING CAMERA)

TLP450U

TLP451U

TLP650U

TLP651U

3LCD DATA PROJECTOR

CONTENTS

Before use

SAFETY PRECAUTIONS

The lightning flash with arrowhead

symbol, within an equilateral triangle,

is intended to alert the user to the

presence of uninsulated “dangerous

voltage” within the product’s

enclosure that may be of sufficient

magnitude to constitute a risk of

electric shock to persons.

The exclamation point within an

equilateral triangle is intended to

alert the user to the presence of

important operating and

maintenance (servicing) instructions

in the literature accompanying the

appliance.

WARNING: TO REDUCETHE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

APPLIANCETO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE

PRESENT INSIDETHE ENCLOSURE. DO NOT OPENTHE CABINET. REFER

SERVICINGTO QUALIFIED PERSONNEL ONLY.

FCC Radio Frequency Interference Statement

Note: This equipment has been tested and found to comply with the limits for a Class A

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates, uses, and can

radiates radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his

own expense.

WARNING: Changes or modifications made to this equipment, not expressly approved by

Toshiba, or parties authorized by Toshiba, could void the user’s authority to operate

the equipment.

Notice: This Class A digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe A est conforme à la norme NMB-003 du

Canada.

CAUTION: Laser beam is emitted when the laser button of the remote control is pressed.Do not

look from the front of the remote control.Do not face toward a person or to a mirror.

CONTENTS

Before use

IMPORTANT PRECAUTIONS

Save Original Packing Materials

The original shipping carton and packing materials will come in

handy if you ever have to ship your LCD projector. For maximum

protection, repack the set as it was originally packed at the factory.

Avoid Volatile Liquid

Do not use volatile liquids, such as an insect spray, near the unit.

Do not leave rubber or plastic products touching the unit for a long

time.They will mar the finish.

Moisture Condensation

Never operate this unit immediately after moving it from a cold

location to a warm location.When the unit is exposed to such a

change in temperature, moisture may condense on the crucial

internal parts.To prevent the unit from possible damage, do not use

the unit for at least 2 hours when there is an extreme or sudden

change in temperature.

In the spaces provided below, record the Model and Serial No.located

at the rear of your LCD projector.

Model No. Serial No.

Retain this information for future reference.

CONTENTS

Before use

IMPORTANT SAFETY INSTRUCTIONS

CAUTION: PLEASE READ AND OBSERVE

ALL WARNINGS AND

INSTRUCTIONS GIVEN INTHIS

OWNER’S MANUAL AND THOSE

MARKED ONTHE UNIT. RETAIN

THIS BOOKLET FOR FUTURE

REFERENCE.

This set has been designed and manufactured

to assure personal safety. Improper use can

result in electric shock or fire hazard.The

safeguards incorporated in this unit will protect

you if you observe the following procedures for

installation, use and servicing.This unit is fully

transistorized and does not contain any parts

that can be repaired by the user.

DO NOT REMOVETHE CABINET COVER, OR

YOU MAY BE EXPOSEDTO DANGEROUS

VOLTAGE. REFER SERVICINGTO

QUALIFIED SERVICE PERSONNEL ONLY.

1. Read Owner’s Manual

After unpacking this product, read the

owner’s manual carefully, and follow all the

operating and other instructions.

2. Power Sources

This product should be operated only from

the type of power source indicated on the

marking label. If you are not sure of the type

of power supply to your home, consult your

product dealer or local power company.

For products intended to operate from

battery power, or other sources, refer to the

operating instructions.

3. Source of Light

Do not look into the lens while the lamp is

on. The strong light from the lamp may

cause damage to your eyes or sight.

4. Ventilation

Openings in the cabinet are provided for

ventilation and to ensure reliable operation

of the product and to protect it from

overheating, and these openings must not

be blocked or covered.The openings

should never be blocked by placing the

product on a bed, sofa, rug or other similar

surface.This product should not be placed

in a built-in installation such as a bookcase

or rack unless proper ventilation is provided

or the manufacturer’s instructions have

been adhered to.

CONTENTS

Before use

5. Heat

The product should be situated away from

heat sources such as radiators, heat

registers, stoves, or other products

(including amplifiers) that produce heat.

IMPORTANT SAFETY INSTRUCTIONS

6. Water and Moisture

Do not use this product near water – for

example, near a bath tub, wash bowl,

kitchen sink, or laundry tub; in a wet

basement; or near a swimming pool and the

like.

7. Cleaning

Unplug this product from the wall outlet

before cleaning.Do not use liquid cleaners

or aerosol cleaners.Use a damp cloth for

cleaning.

8. Power-Cord Protection

Power-supply cords should be routed so

that they are not likely to be walked on or

pinched by items placed upon or against

them, paying particular attention to cords at

plugs, convenience receptacles, and the

point where they exit from the product.

9. Overloading

Do not overload wall outlets; extension

cords, or integral convenience receptacles

as this can result in a risk of fire or electric

shock.

10. Lightning

For added protection for this product during

storm, or when it is left unattended and

unused for long periods of time, unplug it

from the wall outlet.

This will prevent damage to the product due

to lightning and power-line surges.

CONTENTS

Before use

11. Object and Liquid Entry

Never push objects of any kind into this

product through openings as they may

touch dangerous voltage points or short-out

parts that could result in a fire or electric

shock.Never spill liquid of any kind on the

product.

IMPORTANT SAFETY INSTRUCTIONS

12. Do not place the product vertically

Do not use the product in the upright

position to project the pictures at the

ceiling, or any other vertical positions.

It may fall down and dangerous.

13. Stack Inhibited

Do not stack other equipment on this

product or do not place this product on the

other equipment.

Top and bottom plates of this product

develops heat and may give some

undesirable damage to other unit.

14. Attachments

Do not use attachments not recommended

by the product manufacturer as they may

cause hazards.

15. Accessories

Do not place this product on an unstable

cart, stand, tripod, bracket, or table.The

product may fall, causing serious injury to a

child or adult, and serious damage to the

product. Use only with a cart, stand, tripod,

bracket, or table recommended by the

manufacturer, or sold with the product. Any

mounting of the product should follow the

manufacturer’s instructions, and should use

a mounting accessory recommended by the

manufacturer.

A product and cart combination should be

moved with care. Quick stops, excessive

force, and uneven surfaces may cause the

product and cart combination to overturn.

S3125A

CONTENTS

Before use

16. Damage Requiring Service

Unplug this product from the wall outlet and

refer servicing to qualified service

personnel under the following conditions:

a) When the power-supply cord or plug is

damaged.

b) If liquid has been spilled, or objects have

fallen into the product.

c) If the product has been exposed to rain or

water.

d) If the product does not operate normally by

following the operating instructions. Adjust

only those controls that are covered by the

operating instructions as an improper

adjustment of other controls may result in

damage and will often require extensive

work by a qualified technician to restore the

product to its normal operation.

e) If the product has been dropped or

damaged in any way.

f) When the product exhibits a distinct change

in performance – this indicates a need for

service.

IMPORTANT SAFETY INSTRUCTIONS

17. Servicing

Do not attempt to service this product

yourself as opening or removing covers

may expose you to dangerous voltage or

other hazards.Refer all servicing to

qualified service personnel.

18. Replacement Parts

When replacement parts are required, be

sure the service technician has used

replacement parts specified by the

manufacturer or have the same

characteristics as the original part.

Unauthorized substitutions may result in

fire, electric shock, or other hazards.

(Replacement of the lamp only should be

made by users.)

19. Safety Check

Upon completion of any service or repairs

to this product, ask the service technician to

perform safety checks to determine that the

product is in proper operating condition.

20. Do not get your hands between the

camera arm and the main unit when

setting the camera arm back in its

original position.

To avoid injury, be careful not to get your

hands caught when setting the camera arm

back in its original position. Families with

children should be particularly careful.

CONTENTS

Before use

IMPORTANT SAFETY INSTRUCTIONS

21. Do not carry by the camera arm.

Do not carry the projector by the camera

arm.

Doing so can result in damage or injury.

22. Do not leave documents on the unit for

long periods of time while using the

document imaging function.

Do not leave texts, papers or other

documents for projection on the unit for

long periods of time.The heat could erase

the letters on a thermal paper.

23. Do not move the projector while the arm

is still erect.

Always store the arm back in position when

moving the projector. Otherwise injury or

damage may result.

CONTENTS

Before use

Power supply cord

selection

If your line voltage is 220 to 240, use one of the

following types of cable.

Plug

configuration Plug type

EURO

240V

10 – 15A

240V

Australian

240V

10A

North American

240V

15A

Switzerland

240V

Line voltage

220 – 240V

200 – 240V

CONTENTS

Before use

Contents

Before use

SAFETY PRECAUTIONS ............................................................... 2

IMPORTANT PRECAUTIONS....................................................... 3

IMPORTANT SAFETY INSTRUCTIONS ..................................... 4

Power supply cord selection ............................................................. 9

Part names and functions .............................................................. 11

Connections and installation

Connections .................................................................................... 16

Projector placement........................................................................ 18

Operations

Picture projection ........................................................................... 21

Operating the computer by the remote control.............................. 25

Adjustments

Setting and adjustments on the menu............................................ 27

Initial settings – Default................................................................. 28

Keystone correction – Keystone ..................................................... 30

Projection adjustments – Image..................................................... 31

Picture adjustments – Picture ........................................................ 32

Sound adjustments – Audio............................................................ 33

Saving data – Save.......................................................................... 34

Camera

Part names and functions of document imaging camera ............. 35

Picture projection with the document imaging camera ................ 37

Overlaying projection ..................................................................... 39

Maintenance

Trouble indications......................................................................... 40

Air filter, lens and main unit cleaning........................................... 41

Lamp replacement .......................................................................... 42

Others

Before calling service personnel .................................................... 43

Input signal..................................................................................... 45

Adjustments with RS-232C ............................................................ 49

Specifications.................................................................................. 51

LIMITED WARRANTY ................................................................. 53

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Toshiba Proiettore

Toshiba

Toshiba TDP-B1-US Manuale utente

Toshiba

Toshiba TDP-PX10U - XGA DLP Projector Manuale utente

Toshiba

Toshiba TDP-S8U Manuale utente

Toshiba

Toshiba TLP470E Manuale utente

Toshiba

Toshiba TLP470EF Manuale utente

Toshiba

Toshiba TDP MT200 Manuale di istruzioni

Toshiba

Toshiba TDP-TW95 Manuale utente

Toshiba

Toshiba TDP-P6 Manuale utente

Toshiba

Toshiba TLP TLP-X2000 Manuale utente

Toshiba

Toshiba TDP-EX20 Manuale utente

Toshiba

Toshiba TDP-EX20 Manuale utente

Toshiba

Toshiba TLP-S10 Manuale utente

Toshiba

Toshiba TDP-MT400 Manuale utente

Toshiba

Toshiba TDP-WX5400U Manuale utente

Toshiba

Toshiba TDP-S80U Manuale utente

Toshiba

Toshiba TDP-MT200 Manuale utente

Toshiba

Toshiba Camileo TDP-S20 Manuale utente

Toshiba

Toshiba TDP-TW95 Manuale utente

Toshiba

Toshiba X100U - TLP XGA LCD Projector Manuale utente

Toshiba

Toshiba TDP-WX5400 Manuale utente

Toshiba

Toshiba TDP-PX10U - XGA DLP Projector Manuale utente

Toshiba

Toshiba TDP-TW300U Manuale utente

Toshiba

Toshiba TDP TDP-S8 Manuale utente

Toshiba

Toshiba TDP-F10U Manuale utente

Manuali Proiettore popolari di altre marche

iEmmet

iEmmet MP-312 Manuale utente

Epson

Epson VS400 Manuale utente

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuale utente

Sony

Sony VPL-HW65ES Manuale di servizio

Philips

Philips LC1341 Guida di riferimento

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuale utente

NEC

NEC NP600S EDU Manuale utente

BenQ

BenQ SH753P Manuale utente

Eiki

Eiki EK-623U series Manuale utente

Epson

Epson PowerLite Pro Cinema 6020UB Manuale utente

Epson

Epson PowerLite Home Cinema 705HD Manuale utente

Christie

Christie LHD700 Manuale utente

Navitar

Navitar FX Manuale utente

InFocus

InFocus LitePro 560 Manuale utente

Sony

Sony SRX-R815P Manuale utente

Vivitar

Vivitar DP1500 X Manuale utente

Acer

Acer C20 Series Manuale utente

Asus

Asus ZenBeam Latte Manuale utente
