Totally Wicked OPAL Manuale utente
USER MANUAL
TW-Opal-Manual-UK.indd 1TW-Opal-Manual-UK.indd 1 21/06/2023 13:4721/06/2023 13:47
2 3
USB
charging
port
YOUR
Filling port
Mouthpiece
Top cap
Cartridge
Atomizer head
Airow
control ring
Power button
Adjustment
buttons
YOUR OPAL KIT
TW-Opal-Manual-UK.indd 2-3TW-Opal-Manual-UK.indd 2-3 21/06/2023 13:4721/06/2023 13:47
4 5
QUICK
STA RT
GUIDE
REMOVE THE CARTRIDGE
TW-Opal-Manual-UK.indd 4-5TW-Opal-Manual-UK.indd 4-5 21/06/2023 13:4721/06/2023 13:47
6 7
x2
PRIME THE
ATOMIZER HEAD
Wait 5 minutes before vaping
a new atomizer head.
FIT THE ATOMIZER HEAD
TW-Opal-Manual-UK.indd 6-7TW-Opal-Manual-UK.indd 6-7 21/06/2023 13:4721/06/2023 13:47
8 9
REATTACH THE CARTRIDGE
Push and slide the top cap where marked to reveal
the lling port. Insert e-liquid nozzle and ll.
FILL THE CARTRIDGE
TW-Opal-Manual-UK.indd 8-9TW-Opal-Manual-UK.indd 8-9 21/06/2023 13:4721/06/2023 13:47
10 11
ADJUST AIRFLOW
x5
On/O
TURN POWER ON
TW-Opal-Manual-UK.indd 10-11TW-Opal-Manual-UK.indd 10-11 21/06/2023 13:4721/06/2023 13:47
12 13
SET WATTAGE
Press and hold to vape.
VAPING
Press the up or down
buttons to adjust the power.
TW-Opal-Manual-UK.indd 12-13TW-Opal-Manual-UK.indd 12-13 21/06/2023 13:4721/06/2023 13:47
14 15
CHARGE THE BATTERY
PRIMING THE ATOMIZER HEAD
It is important to “prime” a new atomizer head
before rst use. Failure to do so can damage
the atomizer head. Take an atomizer head
from the box and remove all packaging, drip
a few drops of e-liquid onto the cotton inlets
on the side of the atomizer head. Remove the
cartridge from the battery by pulling upwards.
Invert the cartridge and insert the atomizer
head into the cartridge by pushing it into the
recess at the base. Reattach the cartridge
to the battery. After priming a new atomizer
head, it is recommended to wait 5 minutes
before vaping to ensure the atomizer head is
fully saturated.
ATOMIZER HEAD LIFESPAN
Atomizer heads do not last forever and
need to be replaced periodically. Lifespan is
generally from a few days to several weeks,
depending on power used, vaping style,
avour and type of e-liquid. A slight burnt
taste, general loss of vapour production,
or a reduction in avour intensity can all be
indicators that the atomizer head requires
replacement.
USING YOUR OPAL
TW-Opal-Manual-UK.indd 14-15TW-Opal-Manual-UK.indd 14-15 21/06/2023 13:4721/06/2023 13:47
16 17
FILLING THE TANK
Slide the top of the cartridge in the direction
indicated by the arrow on the top cap to reveal
the lling port. Insert your e-liquid bottle
nozzle and ll. Close the cartridge by sliding
the top back into place.
Note: To avoid air-locks, ensure an air gap of
2mm remains above the e-liquid after lling.
After priming a new atomizer head and lling
the cartridge, wait 5 minutes to ensure the
atomizer head is fully saturated.
POWERING ON AND OFF
Press the power button 5 times in quick
succession to turn the Opal on. Pressing the
power button 5 times quickly will turn the
device o again.
SETTING THE WATTAGE
The Opal has adjustable wattage that can be
set from 10-25W in increments of 2 or 3W.
Use the adjustment buttons on the battery to
increase or decrease the wattage.
The GTL 0.8ohm atomizer heads provided
perform the best between 10W – 21W, with
the optimum power being 17W.
VAPING
Press and hold the power button and inhale
through the mouthpiece. The device will begin
to produce vapour.
ADJUSTING THE AIRFLOW
To adjust the airow to your personal
preference, slide the airow control switch
located on the battery. The more area
exposed on the side of the device, the more
open the air draw will be. Sliding the airow
switch to the left will allow for a more open air
draw, and sliding it to the right will restrict the
airow draw.
USING YOUR OPAL
TW-Opal-Manual-UK.indd 16-17TW-Opal-Manual-UK.indd 16-17 21/06/2023 13:4721/06/2023 13:47
18 19
E-LIQUID LEVEL
To prevent the atomizer head from becoming
dry and burning prematurely, ensure the
e-liquid level does not drop below the e-liquid
inlets on the atomizer head, visible through
the cartridge.
CHARGING THE BATTERY
To charge the battery, connect the charge
port on the battery to a USB port or suitable
wall adaptor using the charging lead supplied.
The LED will glow red until fully charged, at
which point it will turn o.
REPLACING THE ATOMIZER HEAD
Remove the cartridge from the battery and
invert. Remove the atomizer head from
the cartridge by pulling, then insert a new
atomizer head. Before tting a new atomizer
head, remember that it will need priming as
described in the section “Priming the Atomizer
Head”.
Reminder: After priming a new atomizer
head, it is recommended to wait 5 minutes
before vaping to ensure the atomizer head is
fully saturated.
BATTERY LIFE INDICATION
The colour of the LED below the power
button will change dependant on the level
of remaining charge the Opal has. The table
below displays what battery percentage each
colour indicates.
USING YOUR OPAL
Colour of LED Battery Level
Green 100% - 60%
Blue 59% - 20%
Red ≤ 20%
TW-Opal-Manual-UK.indd 18-19TW-Opal-Manual-UK.indd 18-19 21/06/2023 13:4721/06/2023 13:47
