TP-Link TL-SF1008P Manuale utente

User Guide

TL-SF1008P

8-Port 10/100Mbps Desktop PoE Switch

Rev：1.0.2

7106503183

Specifications are subject to change without notice.

is a registered trademark of TP-LINK

TECHNOLOGIES CO., LTD. Other brands and product names

are trademarks or registered trademarks of their respective

holders.

No part of the specifications may be reproduced in any form or

by any means or used to make any derivative such as

translation, transformation, or adaptation without permission

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following

measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and

receiver.

•Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/ TV

technician for help.

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received,

including interference that may cause undesired

operation.

Any changes or modifications not expressly approved by the

party responsible for compliance could void the user’s authority

to operate the equipment.

CE Mark Warning

This is a class B product. In a domestic environment, this

product may cause radio interference, in which case the user

may be required to take adequate measures.

SAFETY NOTICES

Cautions

Do not use this product near water, for example, in a wet

basement or near a swimming pool.

Avoid using this product during an electrical storm. There may

be a remote risk of electric shock from lightning.

CONTENT

Package Contents ......................................................1

Chapter 1. Introduction of the Product ..........................1

1.1 Overview of the Product ...................................... 1

1.2 Convention ............................................................ 2

1.3 Features................................................................. 2

Chapter 2. Installation ................................................3

2.1 Mounting the Switch on a Desk........................... 3

2.2 Power On ............................................................... 4

Chapter 3. Identifying External Components ...................4

3.1 Front Panel ............................................................ 4

3.2 Rear Panel ............................................................. 6

Appendix A: Specifications..........................................8

Package Contents

The following items should be found in your box:

¾One TL-SF1008P 8-Port 10/100Mbps Desktop PoE Switch

¾One DC Power Adapter

¾Four rubber cushions to be used under the switch

¾This User Guide

Note

Make sure that the box contains the above items. If any of the

listed items are damaged or missing, please contact with your

distributor.

Chapter 1. Introduction of the Product

Thank you for choosing the TL-SF1008P 8-Port 10/100Mbps

Desktop PoE Switch.

1.1 Overview of the Product

The TL-SF1008P 8-Port 10/100Mbps Desktop PoE Switch

provides the seamless network connection, which integrates

100Mbps Fast Ethernet and 10Mbps Ethernet network

capabilities.

This PoE Switch is also a Power Sourcing Equipment (PSE*).

Four of the eight Auto-Negotiation RJ45 ports (port-1~port-4) on

the switch support Power over Ethernet (PoE*) function, which

can automatically detect and supply power with those IEEE

802.3af-complaint powered devices (PDs*).

1.2 Convention

The Switch or TL-SF1008P mentioned in this User Guide stands

for TL-SF1008P 8-Port 10/100Mbps Desktop PoE Switch

without any explanation.

1.3 Features

¾Complies with IEEE802.3, IEEE802.3u, IEEE802.3af

standards

¾8 10/100Mbps Auto-Negotiation RJ45 ports with 4-port PoE

function (port-1~port-4), all of them support Auto-MDI/MDIX

¾Supports PoE power up to 15.4W for each PoE port

¾Supports PoE power up to 53W for PoE ports

¾Supports PoE IEEE802.3af compliant PDs

¾Supports IEEE802.3x flow control for Full-duplex Mode and

backpressure for Half-duplex Mode

¾1K entry MAC address table of the TL-SF1008P with auto-

learning and auto-aging

*PSE: a device (switch or hub for instance) that will provide power in a PoE

setup.

*PoE: This technology describes a system to transmit electrical power, along

with data, to remote devices over standard twisted-pair cable in an

Ethernet network.

*PD: a device powered by a PSE and thus consumes energy. Examples

include powering IP telephones, wireless LAN access points, network

cameras, network hubs, embedded computers etc.

¾LED indicators for monitoring power, link, activity and speed

¾External power adapter supply

Chapter 2. Installation

During the installation procedure, please only use the

accessories equipped with the switch.

2.1 Mounting the Switch on a Desk

To install the Switch, please follow the steps:

1) You can place the Switch on a flat desk.

2) Please insert the power adapter carefully to the power

socket of the switch, and then connect it properly to a power

source through the cable of the switch.

3) Ensure adequate ventilation space around the switch for

dissipating heat and air.

Note

1) Please avoid any heavy thing placed on the switch.

2) Make sure the power is off before unplugging the power

adapter.

2.2 Power On

The TL-SF1008P Switch can be used with DC power supply.

Powering on the Switch, it will automatically initialize and its LED

indicators will respond as follows:

1) All the LED indicators except PoE ports LED will light syn-

chronously at first, then all of them included Link/Act LED

(green), 100Mbps LED (green) and PoE MAX LED (red), will

light off at once, which indicates the system initialized well.

2) The Power indicator will light all the time.

Note

If the LED indicators don’t respond as described above, please

check the power supply and its connection.

Chapter 3. Identifying External Components

This Chapter describes the front panel, rear panel and LED indi-

cators of the Switch.

3.1 Front Panel

Figure 3-1 TL-SF1008P Switch Front Panel

The Switch’s LEDs are located on the front panel.
