Tractus3D DESK Series Manuale utente
A PROUD DUTCH COMPANY
HEART
SOUL
&
DUTCH
PERFECTION
Inside every 3D Printer
Installation and user manual
DESK series
Original manual v3.0
2
Table of Contents
Disclaimer 4
Preface 5
1. Safety and compliance 6
1.1 Safety Notices 6
1.2 Hazards 6
2. Introduction 8
2.1 Main components 8
2.2 Specifications T1250 8
2.3 Specifications T850 10
2.4 Specifications T650 11
3. Unboxing 13
4. Setup for rst use 13
4.1 Set up network 13
4.2 Update the firmware 16
4.3 Calibrating the print bed 17
4.4 Installing slicing software 18
4.5 Uploading files to 3D printer 24
5. Operation 25
5.1 Web interface 25
6. Materials 30
6.1 Material compatibility 30
6.2 Print recommendations 31
6.3 Tips for experimental materials 32
7. Operating the 3D printer 33
7.1 Load material 33
7.2 Unload material 35
7.3 Removing the filament with a blob 36
3
7.4 Preparing your print bed 38
7.5 Remove support material or brim 41
8. Maintenance 42
8.1 Maintenance schedule 42
8.2 Change the print head 43
8.3 Change the bed plate 46
8.4 Dimensional accuracy calibration 47
8.5 Material usage and storage 49
8.6 Clean the 3D printer 50
8.7 Check all arms 50
8.8 Clean the print head and nozzle 51
8.9 Clean the Bowden tube 52
8.10 Clean the slide wheels 54
8.11 Check for play on the slides 55
8.12 Check tension and wear of belts 56
8.13 Check if print head fan is running after heating up 57
8.14 Clean or replace the feeder/extruder motor 57
9. Troubleshooting 60
9.1 Unclog a print head 60
9.2 Print quality issues 61
4
Disclaimer
Please read this installation and user manual carefully before using this product. Misuse or failure to follow
warnings and instructions may result in personal injuries, inferior results or damages to the 3D printer. Users and
purchasers of this product must know and understand the contents of the manual for correct use and care of
the Tractus3D Printer.
The conditions or methods necessary for assembling, care, storage, use or removal of the product is not within
our control or knowledge. Therefor we do not take any responsibility and explicitly disclaim liability for injuries,
loss, damages, or costs ensued from or connected with the assembly, care, storage, use or removal of the
Tractus3D Printer.
The contents of this document is provided by Tractus3D and without warranties of any kind, either expressed or
implied in relation to the propriety, reliability or accuracy or otherwise of these contents.
Intended use of our 3D printers
Tractus3D printers are engineered and manufactured for use within a commercial environment and for FFF
materials. Tractus3D printers are ideal for functional prototypes, concept models and series production on a
small scale. With the usage of Simplify3D, we have reached a very high level in the production of 3D models.
However the user is responsible for qualifying and validating the utilization of the printed object, in particular if
these are vital in highly restricted circumstances, like medical or automotive applications.
Our printers are compatible with 3rd party filaments but we do recommend the use of Tractus3D materials for
the best results. The properties of these materials are fully matched with our printer settings.
Copyright © 2019 Tractus3D. All rights reserved worldwide.
This language version of the manual is verified by the manufacturer (Original manual). No part of this publication, including
pictures may be reproduced and/or made public, whether by printing, photocopying, microfilm or by any other means
whatsoever, without the prior written permission of Tractus3D.
5
Preface
This is the installation and user manual for your Tractus3D printer.
This manual contains chapters about the installation and use of the 3D printer.
The manual contains important information and instructions on safety, installation and use. Please read all
information and follow the instructions and guidelines in this manual carefully. This ensures that you will obtain
great quality prints and that possible accidents and injuries are prevented. Make sure that everyone who uses the
Tractus3D printer has access to this manual.
Every effort has been made to make this manual as accurate and complete as possible. The information is
believed to be correct but does not aim to be all inclusive and shall be used only as a guide. Should you discover
any errors or omissions, please bring this to our attention, so that we can make amendments.
This will enable us to improve our documentation and service to you.
6
Safety and compliance
1. Safety and compliance
Always work safe with your Tratus3D printer and follow all warnings and instructions to prevent any possible
personal injuries or accidents.
1.1 Safety Notices
This manual includes warnings and safety notices.
Provides additional information that is helpful to do a task or to avoid problems.
Warns of a situation that may cause material damage or injuries if one does not follow the safety
instructions.
General safety information
The Tractus3D printer has moving parts that will get hot and generate high temperatures. This may cause
injuries. When in operation, never reach inside of the 3Dprinter. Control the 3Dprinter with the touchscreen,
positioned on the front or with the power switch at the front. Let the Tractus3D printer cool down for at least 5
minutes before reaching inside.
Do not leave or store items inside the 3D printer.
Without explicit instructions from Tractus3D, please do not adjust or change anything on the Tractus3D printer.
Persons with reduced physical and/or mental capabilities that are unable them to act accurately in case of
emergency or persons with lack of experience and knowledge, should not use the Tractus3D Printer. Only when
given instructions concerning the use of the appliance, or under supervision by a person responsible for their
safety.
Children should always be under supervision when using the 3D printer.
1.2 Hazards
Electromagnetic compatibility (EMC)
This product has been tested and found to comply with the limits for a digital device Class A, according to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the 3D printer is operated in a commercial environment. This Tractus3D printer generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.
Electrical safety
Every printer has passed testing before shipment. This test guarantees the right level of insulation against
electrical shock. An earthed mains socket must be used. Be sure that the building installation has dedicated
7
Safety and compliance
means for over-current and short-circuiting.
The printer is powered by a power adapter or mains voltage, which is hazardous when touched. This has been
marked with a high-voltage symbol.
Always unplug the printer before doing maintenance. Never turn off the printer with a print head above 50
degrees Celsius!
Mechanical safety
The Tractus3D printer complies to the Machine Directive 2006/42/EU. The Tractus3D printer contains moving
parts. No damage to the user will be expected from the drive belts, arms or slides. Always unplug the printer
before doing maintenance.
Risk of burns
Do not touch the heated bed or printhead with your bare hands.
The print head can reach temperatures up to 300 °C and the heated bed can reach temperatures of more than
100 °C. This means there is a potential risk of burns!
Let the 3D printer cool down for 30 minutes before you perform any maintenance. Never turn off printer with a
print head above 50 degrees Celsius!
Health and safety
Our printers are compatible with all brands of 3D print filament, but we do recommend the use of Tractus3D
materials for the best results. The properties of these materials are fully matched with our printer settings. These
materials can be printed safely if the recommended temperatures and settings are used. Printing in a well-
ventilated area is always recommended. Please check the SDS of each specific material for more information.
Third-party materials may release VOCs* that are above regulated threshold levels when processed in Tractus3D
printers (not covered by warranty). These substances may cause headaches, fatigue, dizziness, confusion,
drowsiness, malaise, difficulty in concentration, and feelings of intoxication. We recommend the use of a fume.
Check the SDS of these materials for more information.
*Volatile Organic Compounds
8
Introduction
2. Introduction
About the possibilities of your new Tractus3D printer
2.1 Main components
Print head(s)
Heated build plate
Spool holder
Touchscreen
Extruder
Bowden tubes
Polycarbonate panels
Power socket with cord or adapter
Ethernet port
Power Switch
2.2 Specifications T1250
Machine properties
Printing technology Fused filament fabrication (FFF) - Fused deposition modeling (FDM)
Build width 350 mm diameter (13.8”)
Build height 600 mm (23.6”)
Speed 300 mm/s
XYZ resolution 10, 10, 10 micron
Layer resolution 0.3 mm nozzle: 150 - 10 micron
0.4 mm nozzle: 300 - 10 micron
0.6 mm nozzle: 450 - 10 micron
0.8 mm nozzle: 600 - 10 micron
1.0 mm nozzle: 800 - 50 micron
Operating sound +/- 40 dBA
Power rating max. 510 W
Connectivity LAN
Display 7” color touchscreen (17.8 cm)
Language support English, Dutch, French, German
Monitoring Web interface
9
Introduction
Physical dimensions
Dimensions 640 mm x 555 mm x 1540 mm
Net weight 30 kg
Shipping weight 50 kg
Shipping box dimensions 760 mm x 685 mm x 1400 mm
Build plate
Build plate material Heated glass build plate with PEI sheet
Build plate temperature 10 - 120 °C
Build plate levelling Automatic bed levelling
Build plate heat up time < 4 min (from 20 to 60 °C)
Print head
Feeder type Hardened steel geared (ready for composite materials)
Nozzle diameter 0.3 mm, 0.4 mm, 0.6 mm, 0.8 mm, 1.0 mm
Nozzle temperature up to 300 °C
Nozzle heat up time < 90 sec
Max. extrusion volume < 15 mm3/s
Ambient conditions
Operating ambient temperature 15 - 35 °C, 10 - 90% RH non-condensing
Materials
Supported materials PLA, PRO1, PET-G, ABS, ASA, Facilan C8, TPU/TPE, Nylon, PC, Fillers
like woodfill
Filament diameter 1.75 mm
Software
Supplied software Simplify3D with 1 license (usage on 2 computers)
Supported OS MacOS, Windows and Linux
File types STL, OBJ, 3MF, JPG, PNG
Printable formats G, GCODE
10
Introduction
2.3 Specifications T850
Machine properties
Printing technology Fused filament fabrication (FFF) - Fused deposition modeling (FDM)
Build width 280 mm diameter (11”)
Build height 400 mm (15.7”)
Speed 300 mm/s
XYZ resolution 10, 10, 10 micron
Layer resolution 0.3 mm nozzle: 150 - 10 micron
0.4 mm nozzle: 300 - 10 micron
0.6 mm nozzle: 450 - 10 micron
0.8 mm nozzle: 600 - 10 micron
1.0 mm nozzle: 800 - 50 micron
Operating sound +/- 40 dBA
Power rating max. 360 W
Connectivity LAN
Display 5” color touchscreen (12.7 cm)
Language support English, Dutch, French, German
Monitoring Web interface
Physical dimensions
Dimensions 550 mm x 476 mm x 1140 mm
Net weight 23 kg
Shipping weight 30 kg
Shipping box dimensions 660 mm x 620 mm x 1010 mm
Build plate
Build plate material Heated glass build plate with PEI sheet
Build plate temperature 10 - 120 °C
Build plate levelling Automatic bed levelling
Build plate heat up time < 4 min (from 20 to 60 °C)
Print head
Feeder type Hardened steel geared (ready for composite materials)
Nozzle diameter 0.3 mm, 0.4 mm, 0.6 mm, 0.8 mm, 1.0 mm
Nozzle temperature up to 300 °C
Nozzle heat up time < 90 sec
Max. extrusion volume < 15 mm3/s
