TRENDnet TU-S9 Manuale utente

TU-S9

Quick Installation Guide

Table of Contents

Version 06.24.2010

English 1

1. Before You Start

2. How to Install 2

Troubleshooting 7

1. Before You Start

!USB port: 2.0 or 1.1

!RS-232 device (e.g. modem)

!RS-232 Male to Female Serial Cable (Optional)

CD-ROM drive

Package Contents

System Requirements

Supported Operating Systems CPU Memory

Windows 7 (32/64-bit)

Windows Vista (32/64-bit)

Windows XP (32/64-bit) /

2000 / ME / 98SE

Mac OS X (10.6)

Mac OS X (10.5)

Mac OS X (10.4)

Mac OS X (10.1-10.3)

1GHz or above

800MHz or above

300MHz or above

Intel Processor

867MHz or above

333MHz or above

300MHz or above

1GB RAM or above

512MB RAM or above

256MB RAM or above

1GB RAM or above

512MB RAM or above

256MB RAM or above

!CD-ROM (Driver)

!Multi-Language Quick Installation Guide

TU-S9

256MB RAM or above

2. How to Install

Note: Do not connect the TU-S9 until instructed to do so.

Windows 7 / Vista / XP / 2000 / ME / 98SE

1. Turn on your computer and wait until the

Windows desktop appears.

2. Insert the Driver CD-ROM into your CD-ROM

drive.

3. Click RunAutorun.exe (Windows 7/Vista only).

4. Click Install Driver.

5. Follow the InstallShield Wizard and then click

Finish.

7. Drivers will install automatically.

6. Connect the adapter to an available USB port

of your computer.

8. Connect a serial device to the TU-S9.

Mac OS X (10.1~10.6)

1. Turn on your computer and wait until the

computer desktop appears.

2. Insert the Driver CD-ROM into your CD-ROM

drive.

3. Double-click on the TU-S9 CD-ROM icon on

your desktop.

4. Double-click on the Mac folder.

5. Double-click on PL2303_1.2.1r2.dmg.

6. Double-click on PL2303_1.2.1.

8. Select a destination and then click Continue.

9. Click Install.

11. Click Continue Installation.

7. Click Continue.

10. When the Authenticate screen appears, enter

the Name and Password for your computer

and then click OK.

12. Click Restart.

14. Connect a serial device to the TU-S9.

13. Connect the adapter to an available USB port

on your computer.

Your installation is now complete

For detailed information regarding the TU-S9 configuration and advanced settings, please

refer to the User's Guide included on the Driver CD-ROM or TRENDnet's website at

www.trendnet.com

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

The autorun window does not appear on my windows PC after I put in the

Driver CD-ROM. What should I do?

For Windows 7, if the installation menu does not appear automatically, click on

the Windows Icon on the bottom left hand corner of the screen, click the “Search

programs and files” box, and type D:\autorun.exe, where “D” in “D:\autorun.exe”

is the letter assigned to your CD-ROM Drive, and then press the ENTER key on

your keyboard

2. For Windows Vista, if the installation menu does not appear automatically, click

Start, click the Start Search box, and type D:\autorun.exe where "D" in

"D:\autorun.exe" is the letter assigned to your CD-ROM Drive, and then press

the ENTER key on your keyboard.

3. For Windows XP/2000, if the installation menu does not appear automatically,

click Start, click Run, and type D:\autorun.exe where "D" in "D:\autorun.exe" is

the letter assigned to your CD-ROM Drive, and then press the ENTER key on

your keyboard.

2. Windows is unable to recognize my hardware. What should I do?

Make sure your computer meets the minimum requirements as specified in

Section 1 of this Quick Installation Guide.

2. Try plugging the TU-S9 into a different USB port.

3. Can I use the TU-S9 with my serial keyboard, mouse, or joystick?

The TU-S9 does not support interrupt transfer mode devices. If your serial

keyboard, mouse, or joystick is an HID Device, it is not supported.

4. Can I connect or disconnect the TU-S9 while the computer is on?

Yes, you can connect or disconnect TU-S9 while the computer is on because the

USB interface is Plug-and-Play compliant and hot-pluggable.

If you still encounter problems or have any questions regarding the TU-S9 USB to Serial

Converter, please contact TRENDnet's Technical Support Department.

Troubleshooting
