TRENDnet TE100-PCIE Manuale utente

This economical PCI card is designed for both small office and

home office environment. It utilizes high-speed 100Base-TX

technology and 32-bit Bus Mastering for computers that are

equipped with PCI Bus Slots. This adapter runs in bus master

mode, directly sending and receiving Ethernet packets to and from

memory while using a minimum CPU resources. It complies with

IEEE 802.3/802.3u standards and transmits data over the Ethernet

network at either 10 or 100Mbps and 20 or 200Mbps in full-duplex

mode.

The TE100-PCIE utilizes one RJ-45 port to support existing

10Base-T or 100Base-TX. It also automatically senses either

10Mbps or 100Mbps, and includes a full set of drivers for popular

network operating systems.

TE100-PCIE

10/100Mbps Fast Ethernet PCI Card

PCI 32-bit Bus Master architecture

Single RJ-45 port for both 10Base-T and 100Base-TX

Plugs into any 486/Pentium/Pentium II® PCI Bus Slot

32 bit PCI Bus Master Mode

Plug and Play (PnP)

Supports Multi-thread operation

Supports half-and full-duplex operation

5 Year Warranty

FEATURES BENEFITS

User Friendly:

Speed:

Versatility:

Affordability:

Compatibility:

Just plug the TE100-PCIE into your

workstation and it’s ready to go !

The TE100-PCIE Fast Ethernet

prevents network slowdowns.

Provides 10/100Mbps performance

using only one port.

Top performance at an economical

price for small office or home office.

The TE100-PCIE can be

supported with a variety of

software.

TE100-PCIE (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

To Order Please Call:

1-888-326-6061

SPECIFICATIONS

NETWORKING SOLUTIONS PRODUCT INFORMATION

TE100-PCIA

10/100Mbps Fast Ethernet Adapter for PCI

TE100-PCIE

Boot-ROM for Netware and Windows NT

TE100-PCIWplus

10/100Mbps PCI Fast Ethernet Card (Realtec

Chipset)

TE100-PCIE

10/100Mbps Fast Ethernet PCI Card

TE100-PCIE

10/100Mbps Fast Ethernet PCI Card

Standards:

• IEEE 802.3 10Base-T, IEEE 802.3µ 100Base-TX

Data Bus Width:

• 32-bit bus mastering PCI

Data Transfer Rate:

• 10 or 100Mbps in full-duplex mode

Protocol:

• CSMA/CD

Connectors:

• 1 RJ-45 (10Mbps or 100Mbps speed)

Diagnostic LED’s:

• Power/Transmit, Link/Receive,100Mbps media selection

Certifications:

• FCC Class A, CE

Temperature:

• Operating: 0° to 50° C ( 32° -122° F)

• Storage: -25° to 70° C ( -13° to 158° F)

Humidity:

• Operating: 10 to 70% (non-condensing)

• Storage: 10 to 90% (non-condensing)

Certifications:

• FCC Class B, CE

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
