TRENDnet TEW-703PI Manuale utente

FEATURES

• Wi-Fi compliant with IEEE 802.11n standard

• Backwards compatible with IEEE 802.11g and IEEE 802.11b devices

• Supports Ad-Hoc (Peer-to-Peer b/g only) or Infrastructure (AP-Client) mode

• High-speed data rates up to 150Mbps using an IEEE 802.11n connection

• Dynamic Data Rate Scaling from 150Mbps to 1Mbps

• Maximum reliability, throughput, and connectivity with Automatic Data Rate Switching

• Supports advanced wireless encryption up to WPA/WPA2-RADIUS

• Easy user setup and diagnostic utilities

• Coverage of up to 50 meters indoor and 150 meters outdoor*

• 3-year limited warranty

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specications. Actual data throughput and coverage

will vary depending on interference, network trafc, building materials and other conditions.

TEW-703PI

rev: 10.19.2011

150Mbps Wireless N PCI Adapter

TEW-703PI (V1.0R)

The 150Mbps Wireless N PCI Adapter, model TEW-703PI, connects a desktop

computer to a high speed wireless n network.

This adapter installs quickly to a free PCI slot on a Window’s based desktop

computer. An LED conveys wireless connection status. Advanced wireless

encryption protects your valuable data. A detachable antenna gives users the

ability to change the connected antenna. Stream media, download les, and

play games on a desktop computer over a wireless connection.

150Mbps Wireless N PCI Adapter

TEW-703PI (V1.0R)

SPECIFICATIONS

HARDWARE

Interface • 32-Bit PCI 2.1 Bus

Standards • IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

LED Indicator • Link/ Activity

Power Consumption • Receive mode: 350mA (max.)

• Transmit mode: 400mA (max.)

Supported OS • Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)

Dimensions • 120 x 44 mm (4.7 x 1.75 in.)

Weight • 55 g (1.8 oz)

Temperature • Operating: 0° ~ 40° C (32° ~ 104° F)

• Storage: -10° ~ 70° C (14° ~ 158° F)

Humidity • 95% max. (non-condensing)

Certications • CE, FCC

WIRELESS

Modulation • DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM)

Antenna • 1 x 2dBi dipole detachable antenna with Reverse SMA connector

Frequency • 2.412 ~ 2.484 GHz

Data Rate (auto fallback) • 802.11b: up to 11Mbps

• 802.11g: up to 54Mbps

• 802.11n: up to 150Mbps

Output Power • 802.11b: 15dBm (typical)

• 802.11g: 14dBm (typical)

• 802.11n: 12dBm (typical)

Receiving Sensitivity • 802.11b: -84dBm (typical) at 11Mbps

• 802.11g: -65dBm (typical) at 54Mbps

• 802.11n: -61dBm (typical) at 150Mbps

Encryption • 64/128-bit WEP (Hex & ASCII), WPA/WPA2 (TKIP/AES), WPA-PSK/WPA2-PSK

Channels • 1~11 (FCC), 1~13 (ETSI)

TEW-703PI

rev: 10.19.2011

150Mbps Wireless N PCI Adapter

TEW-703PI (V1.0R)

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TEW-703PI

CD-ROM (Utility & User’s Guide)

Multi-Language Quick Installation Guide

RELATED PRODUCTS

TEW-648UB 150Mbps Mini Wireless N USB Adapter

TEW-711BR 150Mbps Wireless N Home Router

TEW-648UBM 150Mbps Micro Wireless N USB Adapter

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,
