TRENDnet TEW-203PI Manuale utente

TRENDnet's TEW-203PI 11Mbps Wireless LAN PCI Card

creates freedom for your desktop PC. This PCI Card plugs

right into your PCI Bus Slot providing wire-free access to

networked resources from your LAN and Internet or create a

network without networking cables. It dynamically shifts

between 11, 5.5, 2, and 1 Mbps for maximum availability and

reliability. Complying with 2.4 GHz frequency band and IEEE

802.11b standard, TRENDnet's TEW-203PI ensures great

security and performance for your wireless networking

environment.

TEW-203PI

11Mbps Wireless PCI Network Adapter

Wire-Free access to networked resources for desktop PC

Uses 2.4 GHz frequency band (DSSS), which complies

with world wide requirements

Delivers data rate up to 11 Mbps

Dynamically shifts between 11, 5.5, 2, and 1 Mbps

network speed, based on signal strength, for maximum

availability and reliability of connection

Reverse SMA connector with detachable external

Antenna

Supports Windows 98/2000/ME/NT4.0 (SP6)/XP and

Linux

Ensures great security by providing the 64-bit and 128-bit

Wired Equivalent Privacy (WEP) defined in IEEE 802.11b

standard

3-Year Warranty

BENEFITSFEATURES

Integration Friendly:

Economical:

Flexible:

Cost Effective:

Performance:

Drivers support most popular Network

Operating Systems.

Save time, labor, and material for

network cable installation.

Creates wireless peer-to-peer network

in Ad-Hoc mode or connects to

Ethernet LAN in Infrastructure mode

using wireless Access Point.

Supports IEEE 802.11b wireless

standard, user can connect to any

IEEE 802.11b wireless network.

Connects at a speed up to 11Mbps,

wirelessly!

TEW-203PI (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TEW-201PC 11Mbps Wireless PCMCIA Network Adapter

TEW-202CF:11Mbps Wireless CompactFlash Network Adapter

TEW-203PI: 11Mbps Wireless PCI Network Adapter

TEW-204UB: 11Mbps Wireless USB Network Adapter

TEW-210APB: 11Mbps Wireless Access Point + Bridge

TEW-211BRP: 11Mbps Wireless Broadband Router + Access Point

TEW-PS3: 3-port Wireless Ethernet Print Server

TEW-IA04O: 4.0 dBi 2.4GHz ISM Band Omni Directional Antenna

(with Reverse SMA Connector)

TEW-IA06D: 6.0 dBi 2.4GHz ISM Band Patch Antenna (with Reverse SMA Connector)

TEW-OA14D: 14dBi Directional Antenna (outdoor) for IEEE 802.11b 2.4 GHz ISM Band

TEW-2000F: N-Type Male to Reverse SMA Female Antenna Cable (2 meters)

for Outdoor Antenna

NETWORKING SOLUTIONS

SPECIFICATIONS

Interface Type:

PCI Bus Power Management

Specification 1.0

Standards:

IEEE 802.11b WLAN Standard, PCI

Rev 2.2, ACPI 1.0

Antenna:

External 2dbi Antenna (length =

103mm) with Reverse SMA connector

Data Rate:

11Mbps, 5.5Mbps, 2Mbps,

and 1Mbps

Media Access Protocol:

CSMA/CA with ACT

Module Technique:

Direct Sequence Spread Spectrum

(DSSS), CCK, DQPSK, DBPSK

•

Frequency:

2.4 to 2.4835GHz (Industrial

Scientific Medical Band)

LED Indicator:

Power

Output Power:

15 dBm (typical)

Receiving Sensitivity:

10-5 BER @ -80 dbm (11Mbps) min.

Channels:

11 Channels (US & Canada)

Power Consumption:

3.3V, 350mA (Max.)

Dimensions:

134 x 120 x 23 mm without antenna

(5.27 x 4.72 x 0.9 inches)

•

Weight:

Appr. 85 grams (3.0 Oz.) with

antenna

Temperature:

Operating: 0° ~ 55°C (32° ~ 131°F)

Storage: -20° ~ 65°C (-4° ~ 149°F)

Humidity:

95% max. (Non-condensing)

Certification:

FCC, CE

•

TEW-203PI

11Mbps Wireless PCI Network Adapter

TEW-203PI

11Mbps Wireless PCI Network Adapter

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
