TRENDnet TEG-PCITXR Manuale utente

TEG-PCITXR 32-bit 10/100/1000Mbps Copper Gigabit Ethernet

adapter is a high-bandwidth network adapter that auto-senses

10/100/1000Mbps connection speed, half/full-duplex modes, and

MDI-X media type. It includes the latest VLAN tagging to efficiently

utilize network bandwidth for maximum data throughput. With its

2000Mbps bandwidth capacity, TRENDnet’s TEG-PCITXR is ideal

for high traffic Power Server and Video-Conferencing Workstation.

TEG-PCITXR (V3.0R)

10/100/1000Mbps Gigabit PCI Adapter

TEG-PCITXR

rev:06.29.2010

• Support 32-Bit PCI Local Bus Master high-speed operation of Rev. 2.3 specification

• 1 x 10/100/1000Mbps Auto Negotiation and Auto MDI-X Gigabit Port

• Built-in FIFO (8K/64K) buffers reduce overhead of memory transfers

• Supports Full-Duplex Mode Doubles Network Data Rate to 20/200/2000Mbp

• Supports IEEE 802.1Q VLAN Tagging (Windows 2000 and above only)

• Supports Wake-on-LAN for Remote Wake up

• Supports Windows 98SE/ME/2000/XP/Vista Operating Systems

• Plug and Play

• 3-Year Limited Warranty

FEATURES

gigabit

Protocol

Network Media

Diagnostic LEDs

Power Consumption

Dimensions

Temperature

Humidity

Supported OS

• IEEE 802.3 10Base-T Ethernet, IEEE 802.3u 100Base-TX Fast Ethernet

• 32-Bit 33/66Mhz PCI Rev 2.1/2.2/2.3

• IEEE 802.3ab 1000Base-T Gigabit Ethernet, ANSI/IEEE 802.3 Auto-Negotiation

• Link, Activity

• 120 x 59 x 15 mm (4.7 x 2.3 x 0.6 inch)

• Operating: 10 % to 90 % ; Storage: 5% ~ 90%

• CSMA/CD

• Ethernet: UTP Cat. 3, 4, 5, EIA/TIA-568 100-ohm STP

• Fast Ethernet: UTP Cat. 5, EIA/TIA-568 100-ohm STP

• Gigabit: UTP Cat. 5, 5E, 6 EIA/TIA-568 100-ohm STP

• 3.7watts

Data Rate

• Ethernet: 10Mbps/20Mbps (Half/Full-Duplex)

• Fast Ethernet: 100Mbps/200Mbps (Half/Full-Duplex)

• Gigabit: 2000Mbps(Full Duplex)

• Windows 98/ME/NT4.0/2000/XP/2003/Vista; Novel NetWare Server 5.x / 6.x; Linux Kernel 2.4.x / 2.6.x

• Operating: 0° to 40° C (32° to 104°F); Storage: -10° to 70° C (14° to 158°F)

• CE, FCC

Certifications

Interface

Standards

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

10/100/1000Mbps Gigabit PCI Adapter

TEG-PCITXR (V3.0R)

RELATED PRODUCTS

TEG-S18TXE 9-Port 10/100/1000Mbps Copper Gigabit Switch

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

SPECIFICATIONS

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

PACKAGE CONTENTS

• Driver CD-ROM

• TEG-PCITXR

• Multi-Language Quick Installation Guide

Cable/DSL

Modem

Cable/DSL 4-Port

Firewall Router)

(TW100-BRF114)

Workstations with 10/100/1000Mbps

Gigabit PCI Adapter

(TEG-PCITXR)

10/100Mbps

Multi-Port Print Server

(TE100-P21)

Printers

Internet

Gigabit

10/100Mbps
