TRENDnet TEW-228PI Manuale utente

TRENDnet’s TEW-228PI 11Mbps Wireless LAN PCI Adapter

creates freedom for your Desktop PC. This PCI Adapter installs

right into your PCI Bus Slot providing wire-free access to

networked resources from your LAN and Internet or create a

network without networking cables. It dynamically shifts

between 11, 5.5, 2, and 1 Mbps for maximum availability and

reliability. Complying with 2.4 GHz IEEE 802.11b standard,

TRENDnet’s TEW-228PI ensures great security and

performance for your wireless networking environment.

TEW-228PI

11Mbps Wireless LAN PCI Adapter

BENEFITSFeatures

Integration Friendly:

Flexible:

Cost Effective:

Performance:

Drivers support Windows Network

Operating Systems.

User can connect to wired or wireless

LAN without exchanging card or

reconfiguring network settings.

Save money from buying separate

network cards for different types of

network.

Connects at a speed up to 11Mbps for

Wireless LAN, 10/100Mbps for Wired

LAN.

Low interference and high susceptibility guarantee reliable

performance

Wire-Free access to networked resources for Desktop PC

32-bit PCI Local Bus Rev. 2.2 interface

Wi-Fi compatible

Uses 2.4 GHz frequency band (DSSS), which complies with

worldwide requirements

Dynamically shifts between 11, 5.5, 2, and 1 Mbps network speed,

based on signal strength, for maximum availability and reliability of

connection

Diagnostic LED indicators

Male Reverse SMA connector for detachable external Antenna

Supports Windows 98SE/2000/ME/XP

Ensures great security by providing the 64-bit and 128-bit Wired

Equivalent Privacy (WEP)

Distance coverage 35 to100 meters indoor, 100 to 300 meters

outdoors (depends on the environment)

3-Year Warranty

TEW-228PI (03-04-05)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TEW-228PI:

11Mbps Wireless LAN PCI Adapter

TEW-222CF

11Mbps Wireless CompactFlash Network Adapter

TEW-224UB

1Mbps Wireless USB Network Adapter

TEW-226PC

11Mbps Wireless CardBus PC Card

TEW-310PAB

22Mbps Wireless AP + AP Client + Bridge

TEW-311BRP

22Mbps Wireless Broadband Router + Access Point

NETWORKING SOLUTIONS

SPECIFICATIONS

Interface Type:

PCI Bus Specification 2.2

Standards:

IEEE 802.11b WLAN Standard

Antenna:

2dBi detachable antenna with female

Reverse SMA connector

Data Rate:

11Mbps, 5.5Mbps, 2Mbps, and 1Mbps

Media Access Protocol:

CSMA/CA with ACK

Module Technique:

Direct Sequence Spread Spectrum

(DSSS), CCK, DQPSK, DBPSK

Frequency:

2.4 ~ 2.497GHz (Industrial Scientific

Medical Band)

•

LED Indicator:

Power, Link

Transmit Power:

15 dBm (typical)

Receiving Sensitivity:

11Mbps: -80dBm @ 8% PER

2Mbps: -87dBm @ 8% PER

Channels:

11 Channels (US), 13 Channels (EU)

Power Consumption:

PCI 3.3V

Receiving: 250mA

Transmitting: 450mA

Dimensions:

133 x 121 x 21.6 mm

(5.24 x 4.73 x 0.85 inch)

Weight:

56.7 grams (2 Oz.) without antenna

•

Temperature:

Operating: 0° ~ 55°C (32° ~ 131°F)

Storage: -20° ~ 75°C (-4° ~ 167°F)

Humidity:

10% ~ 95% (Non-condensing)

Certification:

FCC Part 15.247(US), EST 300328

(Europe), ARIB STD-T66 (Japan)

•

TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA

TEW-228PI

11Mbps Wireless LAN PCI Adapter
