TRENDnet TU2-H5PI Manuale utente

TU2-H5PI

Quick Installation Guide

Table of Contents

Version 11.20.2007

English ..................................................................................................... 1

1. Before You Start

2. How to Install .....................................................................................

................................................................................

Troubleshooting ........................................................................................

System Requirements

Application

?TU2-H5PI

?Driver CD-ROM

?Quick Installation Guide

Package Contents

1. Before You Start

English

USB Printer

5-Port USB 2.0

Host PCI Adapter

(TU2-H5PI)

USB Camera USB Mouse

USB Scanner

USB 2.0 Hard Drive

480Mbps USB 2.0

12Mbps USB 1.1 * * Backwards compatible with USB 1.1 at 12Mbps

32-bit PCI 2.2 slot

CD-ROM

CPU: 300MHz or above (Windows 2003 Server/XP/2000/ME/98SE)/

800MHz or above (Windows Vista)

Memory: 256MB RAM or above (Windows XP/2000/ME/98SE, Mac OS X

10.1~10.4)/ 512MB RAM or above (Windows Vista)

Windows 98SE/ME/2000/XP/2003 Server/Vista, Mac OS X 10.1~10.4

2. How to Install

English

Important! DO NOT install the PCI adapter in the computer until instructed to

do so.

1. Insert the Driver CD-ROM into

your computer's CD-ROM Drive

and then click Install Driver.

3. When prompted to reboot, select

No and then click Close.

2. A warning message will appear.

Click Continue Anyway.

(Windows XP only).

For Windows Users

Note: Please refer to your computer's user manual regarding hardware

installation.

English

7. After your computer reboots,

Windows will automatically

complete installation of your new

hardware.

6. Insert PC Card firmly into free PC

Card slot of desktop PC, and then

powerup computer.

8. Connect USB devices to the USB

ports.

Your installation is now complete.

4. Shutdown your computer.

5. Open your computer's case.

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Can I connect or disconnect the USB cable while the computer is on?

Yes, you can connect or disconnect the USB cable, or any external USB

device while the computer is on because the USB interface is Plug-and-Play and

hot-pluggable.

I have a USB 1.1 cable. Can it work with USB 2.0 devices?

Yes, it works but it may cause problems when connecting high-speed USB 2.0

external peripherals. Therefore it is recommended that you use a certified USB 2.0

cable.

After successfully installing the TU2-H5PI USB 2.0 PCI Adapter, I connected

my external USB device to the USB port, but it doesn't seem to work. What should

I do?

If you have an external AC power adapter that came with the external USB

device, connect the AC power adapter to the device and power on the device.

Also make sure that you have installed the correct driver for your external USB

device.

How do I install the TU2-H5PI on my Windows 98SE computer?

Follow the instructions below:

1. Follow steps 1-7 in Section 2 How to Install.

2. When the computer boots up, the Found New Hardware wizard appears.

Click Next.

3. When the Insert Disk window appears, insert your Windows 98SE CD into

your CD-ROM drive and then click OK.

4. Click Finish.

5. Repeat steps 1-4.

6. Connect USB devices to the USB ports.

If you still encounter problems or have any questions regarding the TU2-H5PI, please

contact TRENDnet's Technical Support Department.

Troubleshooting

Limited Warranty

TRENDnet warrants its products against defects in material and

workmanship, under normal use and service, for the following lengths of

time from the date of purchase.

TU2-H5PI - 2 Year Warranty

If a product does not operate as warranted above during the applicable

warranty period, TRENDnet shall, at its option and expense, repair the

defective product or part, deliver to customer an equivalent product or

part to replace the defective item, or refund to customer the purchase

price paid for the defective product. All products that are replaced will

become the property of TRENDnet. Replacement products may be new

or reconditioned.

TRENDnet shall not be responsible for any software, firmware,

information, or memory data of customer contained in, stored on, or

integrated with any products returned to TRENDnet pursuant to any

warranty.

There are no user serviceable parts inside the product. Do not remove

or attempt to service the product by any unauthorized service center.

This warranty is voided if (i) the product has been modified or repaired

by any unauthorized service center, (ii) the product was subject to

accident, abuse, or improper use (iii) the product was subject to

conditions more severe than those specified in the manual.

Warranty service may be obtained by contacting TRENDnet office within

the applicable warranty period for a Return Material Authorization (RMA)

number, accompanied by a copy of the dated proof of the purchase.

Products returned to TRENDnet must be pre-authorized by TRENDnet

with RMA number marked on the outside of the package, and sent

prepaid, insured and packaged appropriately for safe shipment.

WARRANTIES EXCLUSIVE: IF THE TRENDnet PRODUCT DOES NOT

OPERATE AS WARRANTED ABOVE, THE CUSTOMER'S SOLE

REMEDY SHALL BE, AT TRENDnet'S OPTION, REPAIR OR

REPLACEMENT. THE FOREGOING WARRANTIES AND REMEDIES

ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES,

EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF

LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

TRENDnet NEITHER ASSUMES NOR AUTHORIZES ANY OTHER

PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN

CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR

USE OF TRENDnet'S PRODUCTS.

TRENDnet SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS

TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED

DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY

CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT,

IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED

ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE

BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT,

FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW

TRENDnet ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY

LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING

NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT,

SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF

REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF

INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT

OF OR IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION

OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY

TO REPAIR, REPLACEMENT, OR REFUND OF THE PURCHASE PRICE

PAID, AT TRENDnet’S OPTION. THIS DISCLAIMER OF LIABILITY FOR

DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED

HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of

the state of California.

AC/DC Power Adapter, Cooling Fan, Cables and Power Supply carry 1

Year Warranty

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may

cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO

OPERATE THE EQUIPMENT.

Waste electrical and electronic products must not

be disposed of with household waste. Please

recycle where facilities exist. Check with you Local

Authority or Retailer for recycling advice.

ADVERTENCIA

En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de alimentacón

necesario para su funcionamiento. El uso de un adaptador distinto al mencionado puede producir

daños fisicos y/o daños al equipo conectado. El adaptador de alimentación debe operar con voltaje y

frecuencia de la energia electrica domiciliaria existente en el pais o zona de instalación.

TRENDnet Technical Support

Product Warranty Registration

Please take a moment to register your product online.

Go to TRENDnet’s website at http://www.trendnet.com/register

US Canada

24/7 Tech Support

Toll Free Telephone: 1(866) 845-3673

Europe (Germany France Italy Spain Switzerland UK)

English/Espanol - 24/7

Francais/Deutsch - 11am-8pm, Monday - Friday MET

English/Espanol - 24/7

Francais/Deutsch - 11am-8pm, Monday - Friday MET

Worldwide

Telephone: +(31) (0) 20 504 05 35

Toll Free Telephone: +00800 60 76 76 67

. . . . .

20675 Manhattan Place

Torrance, CA 90501

USA
