TRENDnet TEG-PCISXM2 Manuale utente

TRENDnet’s TEG-PCISXM2 32/64-bit 1000-Base SX

Compatible Fiber Gigabit Adapter boosts your network

performance with up to 2000Mbps speed in Full Duplex Mode.

The adapter supports most operating systems including

Win98SE/ME/NT4/2000/XP, Linux and Netware.

TRENDnet’s TEG-PCISXM2 is ideal for high traffic Power

Servers, Network Gaming and Video Conferencing Multi-

Media Workstations.

TEG-PCISXM2

64-bit 1000Base-SX Fiber Gigabit PCI Adapter

BENEFITSFEATURES

Performance:

User Friendliness:

Flexibility:

Cost-Effectiveness:

The full-duplex Gigabit adapter brings

high bandwidth with up to 2000Mbps

speeds.

Plug and Play with drivers support all

popular network operating systems.

Connect to fiber type network

Provides the benefit of Gigabit

Ethernet networking with the

familiarity of Ethernet that operates in

existing 64-bit PCI Bus.

IEEE 802.3z 1000Base-SX Compliant

Support 32/64-Bit PCI Local Bus Master high-speed

operation of Rev. 2.2 specification

One SC type connector for 50/125µ and 62.5/125µ

Multimode Fiber cable

Supports Full-Duplex mode and doubles the bandwidth to

2000Mbps

Supports Win98SE/ME/NT4/2000/XP, Linux and Netware

Built-in FIFO buffer reduces overhead of Memory Transfer

802.3x Full Duplex Flow Control, including Automatic

Transmission of Pause Frames based on Rx FIFO

thresholds

128KB RAM On-Chip Buffer

Plug and Play Installation

5-Year Warranty

TEG-PCISXM2(04-22-2004)

TRENDnet

TRENDware, USA

What's Next in Networking

RELATED PRODUCT

To Order Please Call:

1-888-326-6061

TEG-PCISXM2:

64-Bit 1000Base-SX Fiber Gigabit PCI Adapter

TEG-S18TXE:

9-port 10/100/1000Mbps Copper Gigabit Switch

TE100-PCIWN:

10/100Mbps Fast Ethernet PCI Adapter/Realtec Chipset

TE100-S55Eplus:

5-port 10/100Mbps NWay Mini Switch

TE100-PS3plus:

10/100Mbps Multiple Protocol Direct Print Server

(3 Parallel)

NETWORKING SOLUTIONS

SPECIFICATIONS

TEG-PCISXM2

64-bit 1000Base-SX Fiber Gigabit PCI Adapter

TEG-PCISXM2

64-bit 1000Base-SX Fiber Gigabit PCI Adapter

Standards:

• IEEE 802.3z 1000Base-SX Compliant

Protocol:

• CSMA/CD

Media Type:

• SC Type Connector for 50/125µ and 62.5/125µ

Host Interface:

• 32/64-bit PCI Rev.2.2

Diagnostic LEDs:

• Link: and ACT

Data Transfer Rate:

• 2000Mbps (Full Duplex)

Power Consumption:

• 4.25 watts (max)

Driver Support:

• Windows 98SE/ME/NT4/2000/XP,

• Linux Kernel 2.4.x or later

• Netware 5.x. 6x

Temperature:

• Operating: 0° to 40° C (32° to 104°F)

• Storage: -10° to 70° C (14° to 158°F)

Humidity:

• Operating: 10 % to 90 %

• Storage: 5% ~ 90%

Certifications:

• FCC Class B, CE Class B, VCCI Class B

TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet
