TRENDnet TEW-643PI Manuale utente

The Wireless N PCI Adapter allows you to connect your desktop computer

wirelessly with unsurpassed speed and reliability. Enjoy up to 8x the speed

and 4x the coverage of a wireless g connection. Upgrade your desktop and

enjoy faster than wired speeds with a wireless connection.

Setup is a breeze with Wi-Fi Protected Setup technology. Advanced

wireless encryption protects your valuable data. The latest in MIMO

antenna technology ensures the fastest communication speeds that

wireless n technology provides. Stream media, download files, play

games and talk online when connected to a wireless n router.

TEW-643PI (V1.0R)

Wireless N PCI Adapter

• Wi-Fi compliant with IEEE 802.11n standard

• Backwards compatible with IEEE 802.11g and IEEE 802.11b devices

• Supports Ad-Hoc (Client-Client) and Infrastructure (AP-Client) Mode

• Supports Multiple Input Multiple Output (MIMO) technology

• Maximum reliability, throughput and connectivity with automatic data rate switching

• Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK

• Low interference and high susceptibility guarantee reliable performance

• Wi-Fi Multimedia (WMM) Quality of Service (QoS) supported

• Compatible with Windows XP/Vista operating systems

• Easy user setup and intuitive diagnostics utilities

• Coverage of up to 50 meters indoor and 100 meters outdoor *

• 3-Year limited Warranty

FEATURES

wireless

TEW-643PI

rev:02.06.2009

Power Consumption

Supported OS

Certification

• IEEE 802.11b, IEEE 802.11g and IEEE 802.11n (draft 2.0)

• Windows XP(32/64-bit)/Vista (32/64-Bit)

• 802.11b: -84dBm (typical) at 11mpbs

• 120 x 80mm (4.7 x 3.1in)

• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps

• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps

• 1~11 (FCC), 1~13 (ETSI)

Wireless

Interface

Hardware

SPECIFICATIONS

• 32-Bit PCI Bus

LED Indicator

• Receive mode: 550mA (max) ; Transmit mode : 600mA (max)

Receiving Sensitivity

Encryption

Channels

• 64/128-bit WEP (Hex & ASCII), WPA/WPA2 (TKIP/AES), WPA-PSK/WPA2-PSK

• PWR (power), NET (link activity)

Standards

• FCC, CE

• DBPSK/DQPSK/CCK/OFDM (BPSK/QPSK/16-QAM/64-QAM)

• 2 x 2dBi dipole detachable antennas with Reverse SMA connector

Dimensions (LxWxH)

Weight

Data Rate (auto fallback)

• 2.412 ~ 2.484 GHz

Module Technique

Temperature

Humidity

• 75g (2.6oz)

• Operating: 0° ~ 40° C (32° ~ 104° F); Storage: -10° ~ 70° C (14° ~ 158° F)

• 10% ~ 90% max (non-condensing)

Antenna

Frequency

Output Power

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending on

interference, network traffic, building materials and other conditions.

• 802.11g: -68dBm (typical) at 54Mbps

• 802.11n: -65dBm at 135Mbps

• 802.11b: 15dBm (typical)

• 802.11g: 14dBm (typical)

• 802.11n: 14dBm (typical)

• 802.11n: up to 300Mbps (RX)/150Mbps(TX)

TEW-643PI (V1.0R)

Wireless N PCI Adapter

TEW-643PI

rev:02.06.2009

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

RELATED PRODUCTS

PACKAGE CONTENTS

• TEW-643PI

• Multi-Language Quick Installation Guide

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

TEW-652BRP

TEW-641PC Wireless N PC Card

Wireless N Home Router

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

TEW-644UB Wireless N USB Adapter

• CD-ROM (Utility & User’s Guide)

N Speed

Wireless N

Home Router

(TEW-652BRP)

Notebook with Wireless N PC Card

(TEW-641PC) Cable/DSL

Modem

Workstation with

Wireless N PCI Adapter

(TEW-643PI)

Internet

Workstation with

Wireless N USB Adapter

(TEW-644UB)

TEW-643PI (V1.0R)

Wireless N PCI Adapter
