TRENDnet TEW-303PI Manuale utente

TRENDnet’s TEW-303PI 11/22Mbps Wireless LAN PCI Card

creates freedom for your desktop PC. This PCI Card plugs

right into your PCI Bus Slot providing wire-free access to

networked resources from your LAN and Internet or create a

network without networking cables. It dynamically shifts

between 22, 11, 5.5, 2, and 1 Mbps for maximum availability

and reliability. Complying with 2.4 GHz frequency band and

IEEE 802.11b standard, TRENDnet’s TEW-303PI ensures

great security and performance for your wireless networking

environment.

TEW-303PI

11/22Mbps Wireless PCI Network Adapter

Wire-Free access to networked resources for desktop PC

Uses 2.4 GHz frequency band (DSSS), which complies

with world wide requirements

Delivers data rate up to 22 Mbps

Dynamically shifts between 22, 11, 5.5, 2, and 1 Mbps

network speed, based on signal strength, for maximum

availability and reliability of connection

Reverse SMA connector with detachable external

Antenna

Supports Windows 98 (SE)/ME/2000/XP

Ensures great security by providing the 64/128/256-bit

Wired Equivalent Privacy (WEP) defined in IEEE 802.11b

standard

3-Year Warranty

BENEFITSFEATURES

Integration Friendly:

Economical:

Flexible:

Cost Effective:

Performance:

Drivers support most popular Network

Operating Systems.

Save time, labor, and material for

network cable installation.

Creates wireless peer-to-peer network

in Ad-Hoc mode or connects to

Ethernet LAN in Infrastructure mode

using wireless Access Point.

Supports IEEE 802.11b wireless

standard, user can connect to any

IEEE 802.11b wireless network.

Connects at a speed up to 22Mbps,

wirelessly!

TEW-303PI (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TEW-301PC: 11/22Mbps Wireless PCMCIA Network Adapter

TEW-302CF: 11/22Mbps Wireless CompactFlash Network

Adapter

TEW-303PI: 11/22Mbps Wireless PCI Network Adapter

TEW-304UB: 11/22Mbps Wireless USB Network Adapter

TEW-310APB: 11/22Mbps Wireless Access Point + Bridge

TEW-311BRP: 11/22Mbps Wireless Broadband Router

+ Access Point

TEW-PS3: 3-port Wireless Ethernet Print Server

NETWORKING SOLUTIONS

SPECIFICATIONS

Interface Type:

PCI Bus Power Management

Specification 1.0

Standards:

IEEE 802.11b WLAN Standard,

PCI Rev 2.2, ACPI 1.0

Antenna:

External 2dbi Antenna

(length = 103 mm) with

reverse SMA connector

Data Rate:

22Mbps, 11Mbps, 5.5Mbps,

2Mbps, and 1Mbps

Media Access Protocol:

CSMA/CA with ACK

Module Technique:

Direct Sequence Spread Spectrum

(DSSS), CCK, DQPSK, DBPSK

•

Frequency:

2.4 to 2.4835GHz (Industrial

Scientific Medical Band)

LED Indicator:

Power

Output Power:

15 dBm (typical)

Receiving Sensitivity:

10-5 BER @ -80 dbm (11Mbps) min.

Channels:

11 Channels (US & Canada)

Power Consumption:

3.3V, 350mA (Max.)

Dimensions:

134 x 120 x 23 mm

(5.27 x 4.72 x 0.9 inches)

without antenna

•

Weight:

Appr. 85 grams (3.0 Oz.) with antenna

Temperature:

Operating: 0° ~ 55°C (32° ~ 131°F)

Storage: -20° ~ 65°C (-4° ~ 149°F)

Humidity:

95% max. (Non-condensing)

Certification:

FCC, CE

•

TEW-303PI

11/22Mbps Wireless PCI Network Adapter

TEW-303PI

11/22Mbps Wireless PCI Network Adapter

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
