TRENDnet TEG-PCITXRL Manuale utente

Features

• Designed to fit a low profile PCI slot

• Support 32-Bit PCI Local Bus Master high-speed operation (Rev. 2.3 specification)

• 1 x 10/100/1000Mbps Auto Negotiation and Auto MDI-X Gigabit Port

• Built-in FIFO (8K/64K) buffers reduce overhead of memory transfers

• Full-Duplex Mode Doubles Network Data Rate to 2000Mbps

• Supports IEEE 802.1Q VLAN Tagging (Windows 2000 and above only)

• Supports Wake-on-LAN for Remote Wake up

• Supports Windows 7 (64/32bit) / Vista (64/32bit) / XP, and Linux operating systems

• Plug and Play

• 3-year limited warranty

network

accessories

rev: 05.20.2010

TEG-PCITXRL

The Low Profile Gigabit PCI Adapter, model TEG-PCITXRL, adds a Gigabit

Ethernet port to a low profile desktop computer with an available PCI slot.

VLAN tagging technology efficiently utilizes network bandwidth for maximum

data throughput. With its 2000Mbps bandwidth capacity, the TEG-PCITXRL

provides a high bandwidth connection to your low profile desktop computer.

TEG-PCITXRL (V3.0R)

Low Profile Gigabit PCI Adapter

SPECIFICATIONS

Network Media

Standards

Protocol

Interface

Power Consumption

Diagnostic LED

• IEEE 802.3 10Base-T Ethernet

• ANSI/IEEE 802.3 Auto-Negotiation

• IEEE 802.3u 100Base-TX Fast Ethernet • IEEE 802.3ab 1000Base-T Gigabit

• Ethernet: UTP Cat. 3, 4, 5, EIA/TIA-568 100-ohm STP

• Gigabit: UTP Cat. 5E, 6 EIA/TIA-568 100-ohm STP

• Fast Ethernet: UTP Cat. 5, 5e EIA/TIA-568 100-ohm STP

• CSMA/CD

• Ethernet: 10Mbps/20Mbps (Half/Full-Duplex)

• Windows 7 (64/32bit)/Vista (64/32bit)/ XP

• 32-Bit 33/66Mhz PCI Rev 2.3

• 3.7watts

• Operating: 0° ~ 40° C (32° ~ 104° F) • Storage: -10° ~ 70° C (14° ~ 158° F)

• 135 x 85 x 20 mm (5.3 x 3.3 x 0.8 inch)

• Fast Ethernet: 100Mbps/200Mbps (Half/Full-Duplex)

• Novel NetWare Server 5.x / 6.x • Linux Kernel 2.4.x / 2.6.x

Hardware

SPECIFICATIONS

Supported OS

• Link/Activity

• Gigabit: 2000Mbps(Full Duplex)

• Operating: 10%~90% (Non-Condensing)

• CE, FCC

• Storage: 5%~90% (Non-Condensing)

• Multi-Language Quick Installation Guide

CONTACT INFORMATION

RELATED PRODUCTS

PACKAGE CONTENTS

• TEG-PCITXRL

• Driver CD-ROM

TEG-S80g

TEG-PCBUSR

8-Port Gigabit GREENnet Switch

Gigabit PC Card

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

1-888-326-6061

www.trendnet.com

TEG-S50g 5-Port Gigabit GREENnet Switch

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

TEG-PCITXRL (V3.0R)

Low Profile Gigabit PCI Adapter

Data Rate

Dimension

Temperature

Humidity

Certification

NETWORKING SOLUTIONS

Cable/DSL

Modem

Workstations with Low Profile

Gigabit PCI Adapter

(TEG-PCITXRL)

Gigabit Wireless

Internet

Printers

300Mbps Wireless N Gigabit Router

(TEW-639GR)

Wireless 2-Port USB/Parallel Print Server

(TEW-P11G)
