TRENDnet TE100-PCIWplus Manuale utente

FEATURES

• Realtec RTL8139A based chipset

• 10/100Mbps auto-sensing

• Single RJ-45 connector (CAT 3,4,5 UTP cable for 10Mbps operation and CAT 5 UTP

cable for 100Mbps operation)

• 32 bit PCI Bus Master Mode

• Plug and Play (PnP)

• Supports half- and full-duplex operation

• Compatible with all popular operating systems

• 5-years warranty

TREND SPEC’S

Standards: IEEE 802.3 10Base-T, IEEE 802.3 100Base　-TX

Data Bus Width: 32-bit bus mastering PCI

Data Transfer Rate: 10/100Mbps (20/200Mbps in full-duplex mode)

Protocol: CSMA/CD

Connectors: 1 RJ-45 (10Mbps or 100Mbps speed)

Diagnostic LEDs: LNK (Green) Green light will light when a good link is established.

100 (Green) LED will light when a good 100Mbps connection is

established. Green LED will be unlit when a good 10Mbps

connection is detected.

Network Drivers: Novell ODI, NDIS, SCO UNIX, MS LAN Manager,

Windows NT/95/98, Windows for Workgroupsand Packet Driver

Operating Temp.: 0°to 50°C ( 32°to 122°F)

Storage Temp.: -20°to 80°C ( -4°to 176°F)

Operating Humidity: 10 to 90% (non-condensing)

Storage Humidity: 10 to 90% (non-condensing)

Certifications: FCC Class B, CE

10/100Mbps Fast Ethernet PCI Adapter

TRENDware’s TE100-PCIW Plus is a Plug and Play (PnP)

high performance 10/100Mbps Fast Ethernet PCI Adapter. The

TE100-PCIW Plus utilizes the latest chipset technology and 32-bit-

wide bus mastering interface. And its Plug and play function

makes it fully auto-configurable. This PCI adapter automatically

senses and switches to either 10Mbps or 100Mbps (20 Mbps o

200Mbps in full-duplex mode) and has a dual speed connection to

an Ethernet /Fast Ethernet network with a single connection ove

Unshielded/Shielded Twisted Pair cable (UTP/STP). The TE100-

PCIW Plus is backed by TRENDware’s limited lifetime parts and

labor warranty.

TE100-PCIW

TOP FIVE REASONS THE TE100-PCIW

plus

IS A LASTING TREND

Integration Friendly: Designed to easily integrate into any Ethernet/Fast Ethernet network.

Speed: Capable of 100Mbps performance when you need it!

Flexible: Just plug into your workstation and it’s ready to go!

Compatibility: Supports most operating systems.

Performance: Top performance at an affordable price.

TE100-PCIA 10/100Mbps PCI Fast Ethernet Card with ACPI Support

(Intel Chipset)

TE100-PCIE 10/100Mbps PCI Fast Ethernet Card (Winbond Chipset)

TE100-PCIW Plus 10/100Mbps PCI Fast Ethernet Card (Realtec Chipset)

TE1 0 0 - PCI W Pl u

10/100Mbps Fast Ethernet PCI Adapter

To order please call: 888-326-6061

3135 Kashiwa Street • Torrance, CA 90505 • (310) 891-1100 • Fax: (310) 891-1111

Sates: [email protected] • Support: [email protected]

PRODUCT

INFORMATION
