TRENDnet TEW-P1U1P Manuale utente
TRENDnet's TEW-P1U1P is a wireless multi-protocol print server
that transforms virtually all stand-alone USB and Parallel printer
into shared network printers. The TEW-P1U1P incorporates IEEE
802.11b wireless technology for integrating into existing wireless
network. An auto-sensing 10/100Mbps RJ-45 interface is also
available for trouble-free Ethernet network installation. Network
professionals can choose wired or wireless interface depending on
the networking project. The TEW-P1U1P is an ideal network
solution to transform conventional printers into shared resources on
the network. Network managers can utilize the TEW-P1U1P to
promote productivity in a workgroup environment and lower
equipment cost.
TEW-P1U1P
11Mbps Wireless Print Server with 1 USB and 1 Parallel Port
Compliant with IEEE 802.3 Ethernet, 802.3u Fast Ethernet, and
802.11b 11Mbps Wireless LAN standard
Also compatible with IEEE 802.11g wireless products
Compliant with USB 1.1
Supports Ad-Hoc or Infrastructure wireless mode
64/128-bit Wired Equivalent Privacy (WEP) in wireless mode
512KB Flash and 512KB SDRAM memories
One 10/100Mbps auto-sensing Fast Ethernet Port
One USB and one Parallel printer port
Supports TCP/IP, NetBEUI, and AppleTalk protocols
DHCP Client
Supports Windows 95/98/NT/Me/2000/XP, Mac OS (9.x and
higher), Unix, and Linux
Configurable via Windows-based administrative program and
Web Browser
PTP, LPD, SMB, IPP and LaserWriter Chooser printing methods
Diagnostic Printing and Reset Buttons
3-year warranty
BENEFITSFEATURES
Integration Friendly:
Flexible:
Cost Effective:
Performance:
Supports multiple protocols and all
popular Operating Systems.
Integrates with 10Base-T, 100Base-
TX or IEEE 802.11b Wireless network
and supports USB and Parallel
Printers.
Turns the stand-alone printer into a
network printer.
11Mbps bandwidth for wireless
network.
TEW-P1U1P (09-16-2003)
TRENDnet
TRENDware, USA
What's Next in Networking
PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TEW-P1P: 11Mbps Wireless 1 Parallel Port Print Server
TEW-P1U: 11Mbps Wireless 1 USB Port Print Server
TEW-P1U1P: 11Mbps Wireless 1 USB + 1 Parallel Port
Print Server
TE100-PS1U: 10/100Mbps 1 USB Port Print Server
TE100-P2U1P: 10/100Mbps 2 USB + 1 Parallel Port Print
Server
TE100-PS1plus: 10/100Mbps 1-Parallel Port Print Server
TE100-PS3plus: 10/100Mbps 3-Parallel Port Print Server
NETWORKING SOLUTIONS
SPECIFICATIONS
TEW-P1U1P
11Mbps Wireless Print Server with 1 USB and 1 Parallel Port
TEW-P1U1P
11Mbps Wireless Print Server with 1 USB and 1 Parallel Port
LAN Standards:
• IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX
LAN Port:
• 10/100Mbps Auto-Sense and Auto-MDIX RJ-45 Port
Wireless Data Rate:
• 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps (auto-fallback)
Antenna:
• Built-in 2dBi Antenna (non-removable)
Printer Interfaces:
• USB 1.1 Type A Female and DB-25 Female Parallel
Network Cables:
• Cat. 3, 4, 5 UTP/STP for 10Base-T (100 meters max.)
• Cat.5 UTP/STP for 100Base-TX (100 meters max.)
Supported Protocols:
• TCP/IP, NetBEUI and AppleTalk
LED Indicator:
• LAN, WLAN, Status, and Error
Power:
• 12V, 800mA DC External Power Adapter
Dimensions:
• 130 x 95 x 28mm (5.1 x 3.7 x 1.1 inches)
Weight:
• 204 g (7.2 Oz)
Temperature:
• Operating: 0° ~ 40° C (32° ~ 104° F)
• Storage: -10° ~ 70° C (14° ~ 158° F)
Humidity:
• Operating: 10% to 80%
• Storage: 5% to 90%
Emission:
• FCC, CE
TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit
____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2004. All Rights Reserved.
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: 310-891-1100
Fax: 310-891-1111
Web:
Email: [email protected]
www.TRENDNET.com
ORDERING INFORMATION
TRENDnet
TRENDware, USA
R
