TRENDnet TV-IP410PI Manuale utente
Quick Installation Guide
TV-IP410PI (V1)
Table of Content
1 English
1. Before You Start
2. Hardware Installation and Configuration
ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
1
1. Before You Start
Package Contents
ŸTV-IP410PI
ŸCD-ROM (Utility and User's Guide)
ŸQuick Installation Guide
ŸMounting kit
Minimum Requirements
ŸPower over Ethernet (PoE) switch (e.g. TPE-S80) or PoE Injector (e.g. TPE-113GI)
ŸA networked computer and web browser
ŸWired network
ŸNetwork cable
Free Mobile App: TRENDnet IPView Requirements
Supported Operating Systems
Android (version 4.4 or above)
iOS (version 8.2 or above)
Note: The TV-IP410PI only works with Power over Ethernet (PoE) devices that follow the IEEE
802.3af standard.
2
2. Hardware Installation and Configuration
1. Do not install or mount the IP camera until after you complete the installation steps below.
Temporarily place the IP camera next to your computer.
2. Insert the Utility CD-ROM into your CD-ROM drive.
3. Click Install Camera Utility.
Note: You can also download the utility at http://www.trendnet.com/camerautility
ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
3
4 Run the utility and you will see your camera is set to Inactive under security..
5. After the utility is done scanning. Click on the IP address section of the camera you would like
to access.
6. Once you get to the login page you will be prompted to change the password. Please follow the
password requirements and enter your new password.
4
7. Once you login the camera will prompt you for a password change. Please change the default
password.
8. Now you can access the camera's configuration page for Live view and additional settings. For
more details, please refer to the User's Guide.
9. Scan the QR code below to download a free mobile app to view the camera from your IOS or
Android device. Please refer to the quick install guide for instructions on how to setup your
camera in the app from your cameras download page at www.TRENDnet.com.
Android iOS
Note
ŸSee User's Guide for advanced management functions
ŸWhen viewing live video, you may be required to install plug-ins.
ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
5
ŸConnect the provided network cable from the Power over Ethernet switch (e.g. TPE-S80) to
the network port on the IP Camera.
ŸConnect the switch to your network.
Using the TV-IP410PI with a PoE switch (TPE-S80)
10. Install the camera in your desired location. To connect the IP camera to your network with
PoE, please use either of the following examples:
PoE
Internet
Power
Switch
Non-PoE
TV-IP410PI
6
ŸConnect the power adapter to the TPE-113GI and then to a power outlet.
ŸConnect a network cable from the TV-IP410PI to the TPE-113GI's PWR+DATA OUT (PoE)
port.
ŸConnect a network cable from a switch or router (e.g. TEW-818DRU) to the TPE-113GI's
DATA IN (Non-PoE) port.
Using the TV-IP410PI with an Injector (TPE-113GI)
TV-IP410PI
Internet
Non-PoE
TPE-113GI
DATA
IN
PWR+DATA
OUT
PoE
ENGLISHFRANÇAISDEUTSCH
ESPAÑOLРORTUGUÊS
7
Mounting the camera
Note:
1. Loosen the adjustable nut and manually position the camera as desired.
2. Place the provided template label on the mounting surface.
3. Drill holes for the provided screw anchors at each marked position on the template. Make sure
the drill bit matches the size of the provided screw anchors.
4. Insert the provided screw anchors into the holes.
5. Align the mounting bracket with the screw anchors, and then use the provided screws to
secure the camera to the mounting surface.
ŸBefore mounting the camera, the lens must be manually positioned and focused.
ŸFor tips on capturing appropriate camera viewing angle, please refer to the user's guide.
Front
1
11
A
Indoor 2MP 1080p WDR Mini Pan/Tilt PoE IR Network Camera
Directives:
TRENDnet hereby declare that the product is in compliance with the essential requirements and
other relevant provisions under our sole responsibility.
This product is herewith confirmed to comply with the Directives.
Product Information:
Product Name:
Model Number: TV-IP410PI
Trade Name: TRENDnet
Safety
EMC
EMC Directive 2004/108/EC
RoHS Directive 2011/65/EU
WEEE Directive 2012/19/EU
REACH Regulation No.1907/2006
EN60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
Manufacturer’s Name and Address
TRENDnet, Inc.
20675 Manhattan Place
Torrance, CA 90501 USA
Zwolsestraat 156 2587 WB
The Hague The Netherlands
Date: February 07, 2017
Title: Director of Technology
Person responsible for this declaration.
Place of Issue: Torrance, California, USA
Name: Sonny Su
Signature:
EN 55022:2010 CLASS B
EN 50130-4:2011
EN 61000-3-2:2014
EN 61000-3-3:2013
