TRENDnet TV-IP600W - Wireless Pan/Tilt/Zoom Internet Camera Server... Manuale utente

TV-IP600

TV-IP600W

H/W: V1

Quick Installation Guide

Table of Contents

English ....................................................................................................... 1

1. Before You Start

2. Hardware Installation and Configuration .............................................

.................................................................................

Troubleshooting ..........................................................................................

Version 03.25.2009

System Requirements

Package Contents

1. Before You Start

?CD-ROM Drive

?Wireless router or access point (TV-IP600W)

?An available DHCP Server –routers usually have a built-in DHCP server.

10/100Mbps Ethernet Adapter

CPU: 2GHz processor or above

Memory: 256MB RAM or above / 512MB RAM or above (Windows Vista)

VGA Resolution: 800 x 600 or above

Web Brower: Internet Explorer (6.0 or higher)

English

?Utility CD-ROM

?Multi-Language Quick Installation

Guide

?1 x 2dbi Detachable Antenna

?Mounting Kit

?AC Power Adapter (5V, 2.5A)

TV-IP600/TV-IP600W

RJ-45 Cable

Application

English

Pan/Tilt/Zoom Internet Camera Server

(TV-IP600)

Wireless Pan/Tilt/Zoom

Internet Camera Server

(TV-IP600W)

300Mbps Wireless N

Gigabit Router

(TEW-639GR)

Internet

Wireless Pan/Tilt/Zoom

Internet Camera Server

(TV-IP600W)

300Mbps Wireless N

Gigabit Router

(TEW-639GR)

Internet

Pan/Tilt/Zoom Internet

Camera Server

(TV-IP600)

Wireless Pan/Tilt/Zoom Internet Camera Server

(TV-IP600W)

Pan/Tilt/Zoom Internet

Camera Server

(TV-IP600)

2. Hardware Installation and Configuration

2. Click Run autorun.exe

(Windows Vista only)

3. Click Setup Winzard.

1. Insert the Utility CD-ROM into your

CD-ROM drive.

Note:

1. It is recommended that you configure the IP Camera from a wired computer.

2. If you would like to use IPViewPro 2.0 software, please install the software

by clicking the Install IPView Pro 2.0 in the Autorun window and refer to the

User's Guide on the CD for more information.

4. Click Next. Then follow the Setup

Wizard instructions.

English

7. Attach the antennas to the IP

camera.

8. Connect a RJ-45 network cable

from a Switch/Router to the

Ethernet port on the IP Camera.

9. Connect the AC Power Adapter to

the IP Camera and then to a power

outlet.

6. Double click on the SetupWizard

icon on your desktop.

5. Click Close.

10. Click Next.

English

11. Select the IP camera and click

Next.

14. Select DHCP and then click Next.

15. Click I want to use wireless for

the camera and then click Next.

12. Enter your ID and password.

Then click Next. By default:

ID: admin

Password: admin

13. If you would like to change the

administrator password, click

Change Password, enter a new

password, retype the new

password and then click Next.

Leave Change Password

unchecked if you do not wish to

change the password.

Note: Password is limited to up to

8 characters.

English

Note: If you have the TV-IP600, please skip to step 18. If you have the

TV-IP600W, continue on to step 15.

19. Click Next.

20. Please wait while the settings on

your cameras are being saved.

English

16. Click Manually Setup Wireless

and then click Next.

18. Configure the Camera Name and

Camera Time. Click Copy

Local Time to automatically

configure the Camera Time to

match your computer. Then click

Next.

17. Select your wireless network from

the Available AP dropdown list.

If your wireless network does not

appear, manually enter the SSID

of your wireless network. If you

have Encryption enabled, select

the Authentication, select the

Encryption and enter your Key.

Then click Next.

21. Disconnect the RJ-45 cable and

unplug the power. Then plug the

power back in. Wait about 30

seconds while the IP Camera

reboots. Then verify the PWR

and LNK LEDs are on.

22. Click on the following URL or click

Link to open up the browser

configuration.

23. Enter the User name and

Password, and then click OK. By

default:

User Name: admin

Password: admin

English

Note: The TV-IP600W will not work wirelessly until you disconnect the Ethernet

cable from the back of the camera.

24. Click View Video | ActiveX or

View Video | Java to view live

video.

28. Use the command icons to control

the camera.

English

Your installation is now complete.

Note: For detailed information regarding the TV-IP600/TV-IP600W configuration

and advanced settings, please refer to the Troubleshooting section, User's Guide

on the Utility CD-ROM, or TRENDnet's website at http://www.trendnet.com.

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

26. Click Install (ActiveX.only).

25. Right click on the yellow bar and

select Install ActiveX Control

(ActiveX.only).

27. Live Video will now appear.
