TRENDnet TE-1710 Manuale utente

TRENDware Small Business Solutions series palmtop hubs

provide a cost effective connectivity solution and plug-and-play

solution for small departmental networks and workgroups. Their

compact size and lightweight design provide easy installation

and portability. In addition to the UTP/STP ports, the TE-1710

has an additional BNC connector for cascading up to 30 hubs

through a 10 Base-2 backbone cable. Each hub is also equipped

with an uplink port (shared with the last RJ45 port), makes

connecting to another 10 Base-T hub effortless.

For added durability these hubs are protected by heavy gauge

aluminum chassises. These hubs are also UL, CSA and FCC

Class A approved, and features a 5 Year Parts and Labor

Warranty.

TE-1710

16-Port 10Base-T Ethernet Hub

IEEE 802.3 10 Base-T and 10 Base-2 Ethernet

Standard

CSMA/CD protocol for complete data integrity

Easy to Read LED’s for Global Power, Collision,

Link/Activity and BNC indicators

Auto-Partitioning

Uplink port (shared with the last RJ45 port) provides

easy expansion to another hub

10Mbps transfer rate

Heavy duty aluminum chassis

Compact, lightweight, and portable

UL & CSA Certified, FCC Class A

5 Year Warranty

FEATURES

TE-1710 (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

SPECIFICATIONS

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TE-500: 5-Port 10Base-T Hub

AD-0730: 120V AC power adapter for TE-500

AD-0730B: 230V AC power adapter for TE-500

TE-800: 8 RJ45 ports Ethernet hub

TE-900: 10Base-T Ethernet Hub with 9 UTP

Ports

TE-910: 10Base-T Ethernet Hub with 8 UTP

and 1 BNC Ports

TE-910plus: 8 RJ45 ports + 1 BNC Ethernet

hub

TE-1710: 16 RJ45 ports + 1 BNC Ethernet hub

ORDERING INFORMATIONORDERING INFORMATION

TRENDnet

TRENDware, USA

Standards:

• IEEE 802.3 10 Base-T and 10 Base-2

Speed:

• 10Mbps

Ports:

• 16 RJ45 UTP/STP port, 1 BNC port

Power:

• 7.5 VDC, 1A

Dimensions:

• 305 x 102 x 30 (mm)

12.0"x4.0"x1.18" (L x W x H)

Weight:

• 625g / 1.38 lb

Temperature:

• Operating: 0°C ~ 50°C (32°F ~ 122°F)

• Storage: -20°C ~ 70°C (-4°F ~ 158°F)

Humidity:

• Operating: 10% ~ 80%

• Storage: 5% ~ 90%

Certifications:

• FCC, UL, CE

TE-1710

16-Port 10Base-T Ethernet Hub

TE-1710

16-Port 10Base-T Ethernet Hub

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
