TRENDnet's TE-910plus 9-port palmtop hub is the cost

effective connectivity solution for your small departmental

networks and workgroups. Its compact size and lightweight

design provides easy installation and portability. Addition to 8

UTP/STP ports, the TE-910plus also has a BNC connector

that allows cascading up to 30 hubs through a 10Base-2

backbone cable. TRENDnet's TE-910plus is the perfect

choice for your home/office network environment.

TE-910plus

8-port RJ-45 and 1-port BNC Ethernet Hub

Compliant with IEEE802.3 10Base-T and 10Base-2

Standards

8 STP RJ-45 ports and 1 BNC port (one T connector

and one 50 Ohms Terminator included)

10Mbps Transfer Rate

Sturdy light weight plastic housing

Small Footprint with Attractive Shell for

Home/Classroom/Office Use

Easy to Read LED's for Power, Collision,

Link/Receive, and BNC port activity

Auto-Partitioning

MDI-II Uplink Port (shared with port 1) provides easy

expansion to another Hub or Switch

5-Year Warranty

BENEFITSFEATURES

User Friendly:

Versatility:

Expandability:

Affordability:

Plug-n-Play, install the hub is a snap.

Lightweight and small in size, you

can install it anywhere in the

network.

Uplink port for easy expansion with

another Hub, Switch, or Ethernet

device.

Excellent "per port" price with

10Mbps bandwidth.

TE-910plus (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TE-500plus: 5 RJ-45 port Ethernet Hub

TE-800plus: 8 RJ-45 port Ethernet Hub

TE-910plus: 8 RJ-45 & 1 BNC ports Ethernet

Hub

TE-1710: 16 RJ-45 & 1BNC ports Ethernet

Hub

NETWORKING SOLUTIONS

SPECIFICATIONS

TE-910plus

8-port RJ-45 and 1-port BNC Ethernet Hub

TE-910plus

8-port RJ-45 and 1-port BNC Ethernet Hub

Standards:

IEEE 802.3 10Base-T and 10Base-2

Topology:

Star

Protocol:

CSMA/CD

Cabling:

UTP Cat. 3, 4, 5, EIA/TIA-568 100-ohm screened

twisted-pair (STP), 100 meters max. RG58A/U

50 Ohms Coaxial Cable, 185 meters max.

Speed:

10Mbps

Ports:

8 RJ-45 ports

LEDs:

Per Unit: Power, Collision, BNC

Per Port: Link/RX

•

Power:

7.5V DC, 1A, 7.5W max. External Power Adapter

Dimensions:

177 x 72 x 30 mm

(6.97 x 2.83 x 1.18 inches) (L x W x H)

Temperature:

Operating: 0 °C ~ 50 °C (32 °F ~ 122 °F)

Storage: -10 °C ~ 70 °C (14 °F ~ 158 °F)

Humidity:

Operating: 10% ~ 90% (non-condensing)

Storage: 5% ~ 90% (non-condensing)

Certifications:

FCC, CE, VCCI -A

•

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
