TRENDnet TE100-S50g Manuale utente

The compact 5-Port 10/100Mbps GREENnet Switch (model TE100-S50g)

provides improved bandwidth performance, ease of use and reliability, all while

reducing power consumption by up to 40%*.

GREENnet technology automatically adjusts power voltage as needed, resulting

in substantial energy savings. Embedded GREENnet technology works right out

of the box with no management requirement.

Boost your office efficiency and reduce network congestion with a total switching

capacity of 1Gbps with Full-Duplex Mode. Plug and Play this sturdy metal switch

for reliable high-speed network connectivity.

TE100-S50g (V1.0R)

5-Port 10/100Mbps GREENnet Switch

TE100-S50g

rev: 06.30.2010

• 5 x 10/100Mbps Auto-Negotiation, Auto-MDIX Ethernet ports

• GREENnet technology reduces power consumption when:

a. Ethernet port is not in use

b. Connected device is turned off

c. Connected device is in power-saving mode

d. Based on Ethernet cable length

• Compliant with IEEE 802.3/IEEE 802.3u standards

• 1Gbps switching fabric

• Store-and-Forward switching architecture with non-blocking wire-speed performance

• IEEE 802.3x flow control support

• Provides 1k MAC address entries

• Compliant with Windows, Linux, and Mac Operating Systems

• Sturdy metal housing

• Diagnostic LEDs

• Plug & Play installation

• 3-Year Limited Warranty

FEATURES

switches

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

TE100-S50g (V1.0R)

5-Port 10/100Mbps GREENnet Switch

TE100-S50g

60m

Full Power

60m

Delivers less power

to unused ports

100m

on on

less power

20m

Regular

Switch

GREENnet

Switch

20m

Delivers less power

when devices are off

Delivers less power

with shorter

cable lengths

on on

off less power

*Max power savings compared with standard TRENDnet

switches.

Network Media

Power Adapter

Data Rate

Protocol / Topology

Power Consumption

Switch Fabric

Interface

Data RAM Buffer

Dimensions

Weights

Humidity

Temperature

Certifications

• IEEE 802.3 10Base-T

• Ethernet: UTP/STP Cat. 3, 4, 5 up to 100m

• 1K entries

• 7.5V DC, 1A external power adapter

• Operating: 0° ~ 40° C (32° ~ 104° F)

• CE, FCC

• CSMA/CD, Star

• 2.1W (max.)

• 384Kbits

• 116 x 25 x 70mm (4.57 x 0.98 x 2.76 in.)

• Ethernet: 10Mbps/20Mbps (Half/Full-Duplex)

• Fast Ethernet: 100Mbps/200Mbps (Half/Full-Duplex)

• Operating: 10%~90% (non-condensing)

• 225g (7.8 oz)

• 1Gbps forwarding capacity

• 5 x 10/100Mbps Auto-MDIX RJ-45 ports

• Power, Link/ACT, 100Mbps

Filtering Table

Diagnostic LED

Standards

Hardware

SPECIFICATIONS

• Fast Ethernet: UTP/STP Cat. 5, 5e, 6 up to 100m

• IEEE 802.3u 100Base-TX

• IEEE 802.3x Flow Control

• Storage: -10° ~ 70° C (14° ~ 158° F)

• Storage: 5%~90% (non-condensing)

*Max power savings compared with standard TRENDnet switches.

RELATED PRODUCTS

PACKAGE CONTENTS

TE100-PCBUSR

TEG-S50g

TE100-PCIWN 10/100Mbps PCI Adapter

• Power adapter (7.5V DC, 1A)

10/100Mbps PC Card

• TE100-S50g

5-Port Gigabit GREENnet Switch

• Multi-Language Quick Installation Guide
