TRENDnet TK-408K Manuale utente

4-Port PS/2 KVM Switch Kit with Audio

TK-408K (v1.2R)

The 4-Port PS/2 Audio KVM Switch lets you control multimedia PCs

with just one keyboard, monitor, mouse, microphone, and a set of

speakers. The KVM switch not only allows you to share your monitor,

keyboard and mouse but you can also share microphone and speak-

ers. With just a simple press of a button, this KVM switch eliminates the

hassle of cable swapping and switching between 4 PCs. With it’s Hot-

Plug, Auto-Scan and Hot-Key operating features, the TK-408K is the

perfect choice for managing 4 PCs. Separate KVM cables are included.

FEATURES

•Manageupto4computers/serverswithonesetofconsoledevices

•PS/2keyboard/mouseemulationwith4setsofdetachableKVMcables

•CompliantwithWindows98(SE)/ME/2000/XP/2003Server/VistaandLinux

•Highvideoquality,upto2048x1536resolution

•Listentomusicfromonecomputerwhileworkingontheother

•Auto-ScanandLEDdisplayforeasystatusmonitoring

•Computerselectionbyfacepanelpushbuttonsorkeyboardhotkeycommends

•Keyboardstatusrestoredwhenswitchingbetweencomputers

•Plug&Playandhot-pluggable

•2-yearlimitedwarranty

TK-408K

rev: 06.04.2009

4-Port PS/2 KVM Switch Kit with Audio

TK-408K (v1.2R)

TK-408K

rev: 06.04.2009

SPECIFICATIONS

HARDWARE

Connections • 4computers

Cables • 2setsof1.2m(4ft.)PS/2KVMcables,2setsof1.8m(6ft.)PS/2KVMcables

• 2setsof1.2m(4ft.)audiocable,2setsof1.8m(6ft.)audiocable

Cable Interface

(all male)

• ToKVM

• 1xVGA/SVGAHDB15-pin

• 1x3.5mmspeakerjack

• 1x3.5mmmicrophonejack

• ToComputer

• 1xPS/2keyboard6-pinminidin

• 1xPS/2mouse6-pinminidin

• 1XVGA/SVGAHDB15-pin

• 1x3.5mmspeakerjack

• 1x3.5mmmicrophonejack

PC Port Connections

(all female)

• 4xVGA/SVGAHDB15-pin

• 4x3.5mmspeakerjack

• 4x3.5mmmicrophonejack

Console Port Connectors

(all female)

• 1xPS/2keyboard6-pinminidin

• 1xPS/2mouse6-pinminidin

• 1xVGA/SVGAHDB15-pin

• 1x3.5mmspeakerjack

• 1x3.5mmmicrophonejack

Computer Selection • Frontpanelpushbuttonsorkeyboardhotkeycommands

Auto-Scan Interval • 5seconds

Keyboard State • Saveandrestore

Power Type • PS/2interfacepower

Dimensions • 167x80x28mm(6.6x3.2x1.1in.)

Weight • 178g(6.3oz.)

Temperature • Operating:0°C~40°C(32°F~104°F)

• Storage:-20°C~60°C(-4°F~140°F)

Humidity • 0%~90%,non-condensing

Certications • CE,FCC

CONTACT INFORMATION

20675ManhattanPlace,Torrance,CA90501USA

Tel:1-310-961-5500

Fax:1-310-961-5511

Web:www.trendnet.com

Email:[email protected]

1-888-326-6061

PACKAGE CONTENTS

TK-408K

Multi-LanguageQuickInstallationGuide

4setsofPS/2KVMCable(2x1.2m/4ft.,2x1.8m/6ft.)

4setsofaudioCable(2x1.2m/4ft.,2x1.8m/6ft.)

RELATED PRODUCTS

TK-208K 2-PortPS/2KVMSwitchKitw/Audio

TK-407K 4-PortUSBKVMSwitchKit

TK-409K 4-PortUSBKVMSwitchKitwithAudio
