TRENDnet TPE-S160 Manuale utente

TPE-S160

1.01

Quick Installation Guide

Table of Contents

Version 03.23.2010

English 1

1. Before You Start

LEDs 2

3. Hardware Installation 3

Technical Specifications 7

Troubleshooting 8

1. Before You Start

ŸComputer with Network adapter installed

ŸRJ-45 Network Cable

ŸThe surface must support at least 3.8 kg (8.4 lb) for the Switch.

ŸThe power outlet should be within 1.82 meters (6 feet) of the Switch

ŸMake sure that there is proper heat dissipation from and adequate ventilation

around the Switch

ŸDo not place heavy objects on the Switch

ŸIEEE 802.3af Powered Device

Package Contents

ŸTPE-S160

ŸMulti-Language Quick Installation Guide

ŸPower cord (1.8m / 6ft)

ŸRackmount Kit

System Requirements

Optional Equipment

Note:

The TPE-S160 only supports Powered Devices that follow the IEEE 802.3af

standard.

ŸTPE-112GS

ŸEIA standard 19” rack

2. LEDs

Link/ACT

PoE (Power over Ethernet)

Power

Device Status LED Color Sequence Definition

PoE

(Power over Ethernet)

Power

Link/ACT

Amber Solid

Solid

Blinking

Amber

Green

N/A Off

Off

N/A

PoE device is connected

No PoE device is connected.

No connection to the port

Device powered On

Device powered Off

10/20Mbps (Half/Full Duplex) or

100/200Mbps (Half/Full Duplex)

Duplex Connected (per port)

Data Transmitting/Receiving (per port)

3. Hardware Installation

1. Connect the Power Cord to the TPE-S160 and

then to a power outlet.

2. Move the Power switch to the on position.

3. Connect a RJ-45 network cable from the

computer to an available Ethernet port on the

TPE-S160.

4. Connect a RJ-45 cable from a PoE port (1~16)

on the TPE-S160 to the LAN port of the PoE

device (e.g. TEW-638PAP)

5. Verify that the following TPE-S160 LED are on:

Power, PoE and Link/ACT.

Note: Take note of the power requirements for your non-PoE device. The TPE-112GS

only supports non-PoE devices with an output power of 5V, 7.5V, 9V or 12V DC.

Using a non-PoE device with the TPE-S160 and the TPE-112GS (PoE Splitter)

1. Select the voltage (5V, 7.5V, 9V or 12V) on the

TPE-112GS that is required for your non-PoE

device.

5. Verify that the following TPE-S160 panel lights

are on: Power, PoE and Link/ACT.

2. Connect an Ethernet cable from a port (1~16)

on the TPE-S160 switch to the PoE IN port on

the TPE-112GS.

3. Connect the built-in Ethernet cable on the

TPE-112GS to the non-PoE device's LAN port

(e.g. TEW-637AP).

4. Connect the provided Jumper cable to your

non-PoE device's power jack (e.g.TEW-637AP)

and to the TPE-112GS's power jack.

The Switch can be mounted in an EIA standard-size, 19-inch rack, which can be placed

in a wiring closet with other equipment.

Rack Mount

1. Attach the mounting brackets to both sides of

the chassis and secure them with the provided

screws.

2. Carefully position the chassis onto the rack.

Align the bracket to the screw holes on the

rack, then use the screws provided with the

equipment rack to mount the chassis.

Technical Specifications

Hardware

Standard

ŸIEEE 802.3 10Base-T

ŸIEEE802.3u 100Base-TX

ŸIEEE 802.3af Power over Ethernet

ŸIEEE 802.3x Flow Control

16 x 10/100Mbps Auto-MDIX PoE ports

On/Off power switch

ŸEthernet: 10/20Mbps (half/full duplex)

ŸFast Ethernet: 100/200Mbps (half/full duplex)

1.5Mbits

4K MAC entries

3.2Gbps

100~240VAC 50/60Hz, internal universal switching power

Power, Link/Activity, PoE Act/Status

Ÿ6 Watts max. (no Power Device (PD) connected)

Ÿ260 Watts max. (16 PoE devices connected)

ŸOperating: 0° ~ 45°C (32° ~ 113°F)

ŸStorage: -10° ~ 70°C (14° ~ 158°F)

Ports

Power Switch

Data Transfer Rates

Data RAM Buffer

Address Table

Switch Fabric

Power

Diagnostic LEDs

Power Consumption

Temperature

10%- 95% (non-condensing)

440 x 220 x 44 mm (117.3 x 8.7 x 1.7 in.)

3.1 kg (6.9 lb)

CE, FCC

ŸUp to 15.4 watts per port; PD classification

ŸPolymer switch for short protection

ŸPoE: pin 3,6 for power (+) and pin 1,2 for power (-)

Humidity

Dimensions

Certifications

Weight

PoE

Power over Ethernet

Troubleshooting

1. After connecting the Switch to a power outlet, the LEDs do not turn on.

1. Check the connection of the power cord to the TPE-S160 and the power outlet.

2. Verify that the power switch is set to the On position.

3. Check that the power outlet is receiving power.

2. After I connect my PCs to the Switch, I am unable to share files.

1. Check the LEDs on the Switch. Make sure the Link/ACT LED is on.

2. Check the network cable. The minimum length of the cable is 1.5 meters and

the maximum length of the cable is 100 meters.

3. Disable any software firewall program.

4. Verify that you have file sharing enabled. Please contact your Operating

System support for more information.

3. After I connect my PCs to the Switch, I can only get onto the Internet from one

computer.

The Switch was not designed to share Internet between multiple computers. You

need to get an Internet router such as the TW100-S4W1CA.

4. My 802.3af Powered device does not power on when I plug the device into the

Switch. What should I do?

1. Verify that the PoE device supports IEEE 802.3af protocol.

2. Verify that the power switch is set to the on position.

3. Power cycle the PoE switch. Move the power switch to the off position. Wait 15

seconds, then move the power switch back to the on position.

4. Plug the device into a different port on the PoE switch.

5. Try using another RJ-45 network cable.

5. Where is the uplink port located on the Switch?

Since all the ports on the Switch are Auto-MDIX, any of the ports can be used as

an uplink port.

If you still encounter problems or have any questions regarding the TPE-S160 please

contact Trendnet's Technical Support Department.
