Tripp Lite U339-E02 Manuale utente

Owner’s Manual

USB 3.0 to Dual SATA

Docking Station with

Erase Feature

Model: U339-E02

WARRANTY REGISTRATION

win an ISOBAR surge protector in our monthly drawing!

tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

All trademarks are the property of their respective owners.

Este guía esta disponible en español en la página de Tripp Lite:

tripplite.com/support

Ce guide est disponible en français sur le site Web de Tripp Lite :

tripplite.com/support

Русскоязычная версия настоящего краткого руководства представлена

на веб-сайте компании Tripp Lite по адресу: tripplite.com/support

Product Features

Package Includes

• Connects two 2.5” or 3.5” SATA I, II, or III hard drives

• Quickly access hard drive content without the hassle of time-

consuming internal installation

• Accepts 2.5” hard drives up to 2 TB and and 3.5” hard drives

up to 14 TB *

• Supports USB 3.0 data transfer rates up to 5 Gbps and is

backward compatible with USB 2.0 and USB 1.1 standards

• Supports UASP (Serial Attached SCSI Protocol) for speeds

faster than USB 3.0**

• Ofﬂine Erase function clears the content of two SATA hard

drives simultaneously without connecting to a host or computer

• Erasing status displays via progress LEDs

*Will work with larger hard drives as they become available.

**Requires UASP-enabled host controller. UASP is supported by

Windows 8 and later, Mac OSX 10.8 and later and Linux.

• U339-E02 Dual-Bay SATA Docking Station

• External Power Supply (Input: 100-240V)*

• USB 3.0 A to B Cable – 3 ft. (0.8 m)

• Owner’s Manual

*Includes North America NEMA 1-15P plug.

Feature Identiﬁcation

System Requirements

A2.5”/3.5” SATA HDD/SSD

Drive Bays

BPower LED

CHDD/SSD Drive Bay LEDs

DErase Button

EErase Process LEDs

FUSB 3.0 Type-B Port

GOn/Off Switch

HDC-In Input

• (x2) 2.5” or 3.5” SATA Hard Drives

• Computer with an available USB port

Notes:

• A USB 3.0 port is required to achieve speeds up to 5 Gbps.

• The ofﬂine erase function will not work if the U339-E02 is connected

to a computer or any other source via USB cable.

USB 3.0 ON/OFF 12V 3A

F G H

Operation

Note: If the SATA hard drive has not been formatted, it must ﬁrst be

formatted using a computer Disk Management utility in order to access

drive contents.

1. Connect the included power supply to the docking station,

then to an available wall outlet or a Tripp Lite Surge Protector.

2. Insert a 2.5” or 3.5” SATA hard drive into an available bay on

the docking station, making sure it is securely seated on the

SATA connector. Repeat this step to connect an additional

hard drive.

3. Connect the included USB 3.0 cable to the docking station

and a computer.

4. Use the ON/OFF switch on the back of the unit to power the

docking station. The red Power LED will illuminate to indicate

power is being received. The red drive bay LEDs (HDD1 &

HDD2) will illuminate to indicate a hard drive is connected

to the corresponding port and blink when data is being

transferred.

Operation

Ofﬂine Erasing

Note: The ofﬂine erase function will not work if the U339-E02 is

connected to a computer or any other source via USB cable.

1. Connect the included power supply to the docking station,

then to an available wall outlet or a Tripp Lite Surge Protector.

2. Insert a 2.5” or 3.5” SATA hard drive into an available bay on

the docking station, making sure it is securely seated on the

SATA connector. Repeat this step to connect an additional

hard drive.

Note: Two SATA hard drives can be erased simultaneously.

3. Use the ON/OFF switch on the back of the unit to power the

docking station. The red Power LED will illuminate to indicate

power is being received. The red drive bay LEDs (HDD1 &

HDD2) will illuminate to indicate a hard drive is connected to

the corresponding port and blink when the erase function is

being performed.

4. Press and hold down the Erase button until the blue Progress

LEDs begin to blink, then release the Erase button. The 25%

Progress LED will start to blink, indicating the erasing process

is underway.

5. Once all four blue Progress LEDs (25%, 50%, 75%, 100%)

have stopped blinking and are glowing solid blue, the erasing

process has completed.

Warranty and

Product Registration

1-Year Limited Warranty

Tripp Lite warrants its products to be free from defects in materials and workmanship

for a period of one (1) year from the date of initial purchase. Tripp Lite’s obligation

under this warranty is limited to repairing or replacing (at its sole option) any

such defective products. To obtain service under this warranty, you must obtain a

Returned Material Authorization (RMA) number from Tripp Lite or an authorized Tripp

Lite service center. Products must be returned to Tripp Lite or an authorized Tripp

Lite service center with transportation charges prepaid and must be accompanied

by a brief description of the problem encountered and proof of date and place of

purchase. This warranty does not apply to equipment, which has been damaged by

accident, negligence or misapplication or has been altered or modiﬁed in any way.

EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO WARRANTIES, EXPRESS OR

IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A

PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied

warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the

purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite BE LIABLE FOR DIRECT,

INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT

OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH

DAMAGE. Speciﬁcally, Tripp Lite is not liable for any costs, such as lost proﬁts or

revenue, loss of equipment, loss of use of equipment, loss of software, loss of data,

costs of substitutes, claims by third parties, or otherwise.

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be

automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

*No purchase necessary. Void where prohibited. Some restrictions apply. See

website for details.

Warranty and

Product Registration

Regulatory Compliance Identiﬁcation Numbers

For the purpose of regulatory compliance certiﬁcations and identiﬁcation, your

Tripp Lite product has been assigned a unique series number. The series number

can be found on the product nameplate label, along with all required approval

markings and information. When requesting compliance information for this product,

always refer to the series number. The series number should not be confused with

the marketing name or model number of the product.

WEEE Compliance Information for Tripp Lite Customers and Recyclers

(European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and

implementing regulations, when customers buy new electrical and electronic

equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis

(this varies depending on the country)

• Send the new equipment back for recycling when this ultimately

becomes waste

Tripp Lite has a policy of continuous improvement. Speciﬁcations are subject to

change without notice. Photos and illustrations may differ slightly from actual

products.

1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support

19-07-474 93-39DE_RevA
