Tripp Lite PDU3MV6H50 Manuale utente

3-Phase Metered PDU, 12.6 kW, 45 208V outlets (36

C13, 9 C19), 6 ft Hubbell CS8365C 50A input

connection

MODEL NUMBER: PDU3MV6H50

Description

Tripp Lite 3 phase Metered PDU / Power Distribution Units offer real-time local reporting of current levels in amps

via set of 3 built-in digital meters. Enables visual monitoring of PDU current levels to preserve proper loading

balance and prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet

power distribution from any protected UPS, generator or mains input power source. High quality design includes

rugged all-metal housing and secure rackmount installation with included mounting accessories.

Features

12.6kW 3 phase 208V Metered Power Distribution Unit / PDU

Set of 3 built-in current meters continuously report load current in amps for all 3 output phases

Attached Hubbell CS8365C 50A (3P+E) 208V 3 phase input plug with 6 ft. / 1.8m cord

0U, 70 in. / 178cm vertical form factor supports installation in 2 or 4 post equipment racks

45 total 208V outlets (36 C13, 9 C19) arranged in three breakered single phase output load banks

Included cord retention brackets keep vital network equipment plugged in and continuously powered

Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications (set of 2 9mm

buttons pre-installed, 2 9mm and 4 6mm spare buttons included)

TAA Compliant Version Available - Order Tripp Lite PDU3MV6H50TAA

Specifications

OVERVIEW

PDU Type Metered

OUTPUT

Highlights

Metered 12.6kW 3 Phase 208V

PDU; 70 in. / 178cm 0U vertical

rackmount

Reports load current per-phase

via set of 3 built-in current meters

Hubbell CS8365C 50A (3P+E)

208V 3 phase input; 6 ft. / 1.8m

line cord

45 208V outlets total (36 C13, 9

C19)

Toolless button-mount

installation; cord retention

brackets included

Applications

Ideal for 3 phase network

configurations in datacenters and

heavily configured equipment racks

Package Includes

Metered PDU with pre-installed

mounting buttons

Cord retention brackets

Spare installation buttons (2 9mm

/ 4 6mm)

Rack mounting brackets

Owner's manual

1 / 3

Output Capacity Details 12.6kVA total; 20A per bank (balanced)

Frequency compatibility 60 Hz

Output nominal voltage 208V single phase

Overload protection 3 20A double-pole circuit breakers (1 per output phase)

Outlet quantity / type 45 total - 36 C13, 9 C19

Outlet Type IEC-C13, IEC-C19

INPUT

PDU Input Voltage 208

Maximum Input Amps (A) 35

PDU Plug Type HUBBELL CS8365C 50A

Input cord length (ft.) 6

Input cord length (m) 1.83

Phase 3-Phase

PHYSICAL

Shipping Dimensions (HWD/in) 76.8 x 9.5 x 5.3

Shipping Dimensions (HWD/cm) 195 x 24.1 x 13.5

Shipping weight (lbs) 16.1

Shipping weight (kg) 7.3

Unit Dimensions (HWD/in) 70 x 2.65 x 1.71

Unit Dimensions (HWD/cm) 177.8 x 6.73 x 4.34

Unit weight (lbs) 14.5

Unit weight (kg) 6.6

Material of construction Steel

Style Vertical rackmount

Form factors supported Vertical rackmount installation supported with included mounting brackets; supports toolless mounting in

button-mount compatible racks

PDU Form Factor Vertical (0U)

ENVIRONMENTAL

Operating Temperature Range 0 - 50C / 32 - 122F

Storage Temperature Range -15C - 60C / 5 - 140F

Relative Humidity 0-95% non-condensing

CERTIFICATIONS

TAA Compliant Option TAA Compliant Version Available - Order Tripp Lite PDU3MV6H50TAA

2 / 3

Certifications Tested to UL60950-1 (USA, Canada), NOM (Mexico), Class A (Emissions), ROHS

WARRANTY

Product Warranty Period (Worldwide) 2-year limited warranty

Related Items

Optional Products

Model Number Description Qty.

P004-002-13LA AC Power Extension Cable - C13 Left Angle to C14 - 2' 1

P004-002-13RA AC Power Extension Cable - C13 Right Angle to C14 - 2 ft. 1

P047-006 6-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1

P047-010 10-ft. 14AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C14) 1

P036-002-19LA 2-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 Left Angle to IEC-320-C20) 1

P036-002-19RA 2-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 Right Angle to IEC-320-C20) 1

P036-002 2-ft. 12AWG Heavy Duty Power cord (IEC-320-C19 to IEC-320-C20) 1

More information, including related products, owner's manuals, and additional technical specifications, can be found online at:

http://www.tripplite.com/sku/PDU3MV6H50.

Specifications are subject to change without notice. Photos may differ slightly from final products.

3 / 3
