Tripp Lite PDUMH32HV Manuale utente
Single Phase Metered PDU, 7.4kW 32A 230V, 2U
Horizontal Rackmount, 18 outlets (2 C19, 16 C13),
3.6m cord, IEC-309 Blue 230V 32A input plug
MODEL NUMBER: PDUMH32HV
Description
Tripp Lite Metered Power Distribution Units / PDU systems continuously report output load level in amps to help
network managers prevent overloads and plan for future growth. Supplies equipment with continuous power
from any protected UPS, generator or mains input power source. Highly reliable design includes rugged all-metal housing and secure rackmount installation
with included mounting accessories.
Features
32A single phase 230V Metered Power Distribution Unit / PDU
Set of two lighted current meters separately report power consumption in amps for each output load bank
Attached IEC-309 32A (2P+E) input plug with 12 ft. / 3.6m line cord
2U horizontal rackmount format installs in two rack spaces
18 total 230V outlets (2 C19, 16 C13)
Outlets are arranged in two separately breakered and metered 16A load banks (each with 8 C13 and 1 C19 outlet)
Mounting flanges support installation in 2 and 4 post racks, with additional support for wall-mount and under-counter installation formats
Front-panel grounding lug
Included cord retention brackets
TAA Compliant Version Available - Order Tripp Lite PDUMH32HVTAA
Specifications
OVERVIEW
PDU Type Metered
OUTPUT
Highlights
Metered single phase 32A 230V
2U horizontal rackmount PDU
Set of 2 current meters reports
current in amps for each output
load bank
Attached 12 ft. / 3.6m cord with
IEC-309 32A (2P+E) input plug
18 total 230V outlets (2 C19, 16
C13)
Reversible housing, 12.5 in. /
31.75cm depth
Applications
Ideal for network configurations
requiring a metered PDU
Package Includes
2U metered PDU
Mounting brackets
Plug retention brackets
User manual
1 / 4
Output kW capacity 7.36
Output Capacity Details 7.4kW; 32A maximum
Frequency compatibility 50 / 60 Hz
Output nominal voltage 230V
Overload protection Outlets are arranged in two 16A banks of 9 outlets each (1 C19 / 8 C13); Each bank is protected by a separate
circuit breaker
Outlet quantity / type 16 C13 and 2 C19 outlets
Outlet Type IEC-C13, IEC-C19
INPUT
Nominal Input Voltage(s) Supported 230V AC
PDU Input Voltage 230
Maximum Input Amps (A) 32
PDU Plug Type IEC-309 32A BLUE (2P+E)
Input cord length (ft.) 12
Input cord length (m) 3.65
Phase Single-Phase
LEDS ALARMS & SWITCHES
Switches n/a
PHYSICAL
Shipping Dimensions (HWD/in) 5.5 x 20.5 x 17
Shipping Dimensions (HWD/cm) 14 x 113 x 80.6
Shipping weight (lbs) 16.2
Shipping weight (kg) 7.4
Unit Dimensions (HWD/in) 3.5 x 17.5 x 12.5
Unit Dimensions (HWD/cm) 8.9 x 44.5 x 31.75
Unit weight (lbs) 13.7
Unit weight (kg) 6.2
Material of construction Steel
Style Rackmount
Form factors supported 2U rackmount
PDU Form Factor Horizontal (1U, 2U, etc)
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
2 / 4
CERTIFICATIONS
TAA Compliant Option TAA Compliant Version Available - Order Tripp Lite PDUMH32HVTAA
Certifications Tested to CE (IEC 60950-1), UL, CSA, Class A, RoHS compliant
WARRANTY
Product Warranty Period (Worldwide) 2-year limited warranty
Related Items
Optional Products
Model Number Description Qty.
P004-002-5 5-Pack of 2-ft. 18AWG Power cord
(IEC-320-C14 to IEC-320-C13) 1
P005-002 2-ft. Heavy-Duty 14AWG Power cord
( IEC-320-C13 to IEC-320-C14) 1
P005-006 6-ft. Heavy-Duty 14AWG Power cord
(IEC-320-C13 to IEC-320-C14) 1
P005-010 10-ft. Heavy-Duty 14AWG Power cord
(IEC-320-C13 to IEC-320-C14) 1
P004-002-13RA AC Power Extension Cable - C13 Right Angle to C14 - 2 ft. 1
P004-004 4-ft. 18AWG Power cord
(IEC-320-C14 to IEC-320-C13) 1
P004-006 6-ft. 18AWG Power cord
(IEC-320-C14 to IEC-320-C13) 1
P004-006-2C13 6-ft. AC Power Extension Splitter Cable
( C14 to 2 x C13 ) 1
P047-002 2-ft. 14AWG Heavy Duty Power cord
(IEC-320-C19 to IEC-320-C14) 1
P047-004 4-ft. 14AWG Heavy Duty Power cord
(IEC-320-C19 to IEC-320-C14) 1
P047-006 6-ft. 14AWG Heavy Duty Power cord
(IEC-320-C19 to IEC-320-C14) 1
P047-010 10-ft. 14AWG Heavy Duty Power cord
(IEC-320-C19 to IEC-320-C14) 1
P036-002 2-ft. 12AWG Heavy Duty Power cord
(IEC-320-C19 to IEC-320-C20) 1
P036-006 6-ft. 12AWG Heavy Duty Power cord
(IEC-320-C19 to IEC-320-C20) 1
P036-002-19LA 2-ft. 12AWG Heavy Duty Power cord
(IEC-320-C19 Left Angle to IEC-320-C20) 1
P036-002-19RA 2-ft. 12AWG Heavy Duty Power cord
(IEC-320-C19 Right Angle to IEC-320-C20) 1
3 / 4
P032-002-2C13 2-ft. AC Power Splitter Cable
( C20 to 2 x C13 ) 1
P036-006-2C19 6-ft. AC Power Splitter Cable
( C20 to 2 x C19 ) 1
P036-002-20LA 2-ft. 12AWG Heavy Duty Power cord
(IEC-320-C19 to IEC-320-C20 Left Angle) 1
P036-002-20RA 2-ft. 12AWG Heavy Duty Power cord
(IEC-320-C19 to IEC-320-C20 Right Angle) 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at:
http://www.tripplite.com/sku/PDUMH32HV.
© 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement.
Specifications are subject to change without notice. Photos may differ slightly from final products.
4 / 4
