Tripp Lite SmartOnline SU1000XLCD Manuale utente

SU1000XLCD is not for sale in Colorado, Vermont and Washington state. Customers in these states

should purchase the recommended ENERGY STAR® 2.0 model instead: SU1000RTXLCD2U. Learn

more about ENERGY STAR 2.0 and sales restrictions in these states.

SmartOnline 120V 1kVA 900W Double-

Conversion UPS, Tower, Extended Run, Network

Card Options, LCD, USB, DB9 Serial

MODEL NUMBER: SU1000XLCD

Description

Do you need to protect small- to medium-size servers, networking equipment and telecom systems

against data loss, downtime and equipment damage due to power outages, voltage fluctuations and

transient surges? Tripp Lite’s SU1000XLCD SmartOnline® Tower UPS System is the solution! Featuring a

1000VA/900W capacity and true on-line operation with pure sine wave output and zero transfer time to

battery, it provides the highest level of power protection for mission-critical equipment. The

SU1000XLCD’s large internal battery set supports connected equipment during blackouts, and runtime is

expandable with optional external battery packs (Tripp Lite model BP24V15RT2U, BP24V28-2U or

BP24V70-3U), sold separately. The SU1000XLCD has 6 5-15R outlets, including 2 single-outlet load

banks that are individually controllable to reboot select equipment on demand or maximize battery runtime

for mission-critical equipment. USB and DB9 communication ports support messaging of detailed UPS

operational parameters and line power status. PowerAlert UPS management software is available via free

download. It comes backed by $250,000 of Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico

only).

Features

Ideal for Protection of Mission-Critical Equipment

True On-Line Operation with Pure Sine Wave Output and Zero Transfer Time

Individually Controllable Outlets

Reliable, Expandable Battery Backup

Highlights

1000VA / 1kVA / 900 watt on-

line double-conversion tower

UPS

●

100/110/120/127V 50/60Hz

output, high efficiency economy

mode option

●

Interactive LCD with 10

selectable screens of UPS and

site power data

●

Expandable runtime, Hot-

swappable batteries

●

USB, RS232 & EPO ports,

Network Management Card

options

●

2 independently switched load

banks

●

NEMA 5-15P input; 6 5-15R

outlets

●

To use the Auto Probe feature,

this product requires a

WEBCARDLX network interface

(sold separately) running LX

firmware update 15.5.2 or later

●

Package Includes

SU1000XLCD SmartOnline®

Tower UPS System

●

USB, DB9 and EPO Cables

●

Owner’s Manual

●

1 / 6

Specifications

High Power Factor and Highly Efficient Operation Reduces BTU Output

AC Line and Tel/Ethernet Surge Suppression

EMI/RFI Line Noise Filtering

LCD Screen and Audible Alarm

USB/DB9 Ports, Network Management Cards and PowerAlert Software

www.tripplite.com/poweralert

Emergency Power Off (EPO) Capability

Peace of Mind

OVERVIEW

UPC Code 037332174666

UPS Type On-Line

INPUT

Rated input current (Maximum Load) 10A

Nominal Input Voltage(s) Supported 100V AC; 110V AC; 120V AC; 127V AC

Nominal Input Voltage Description 120V factory default

UPS Input Connection Type 5-15P

Input Circuit Breakers 15A

UPS Input Cord Length (ft.) 10

UPS Input Cord Length (m) 3.1

Recommended Electrical Service 15A 120V

Input Phase Single-Phase

OUTPUT

2 / 6

Output Volt Amp Capacity (VA) 1000

Output Capacity (kVA) 1

Output Watt Capacity (Watts) 900

Output kW Capacity (kW) 0.9

Output Capacity Details ON LINE MODE: Maximum output capacity rating is reduced to 810W at 100V nominal; FREQUENCY

REGULATION / CONVERSION MODE: Maximum output ratings are reduced in frequency regulation / conversion

mode (127/120/115/110V 630 watts / 100V 567 watts)

OVERLOAD CAPACITY: Supports inverter operation up to 105% load continuously, 125% load for 3 minutes; 150%

load for 30 seconds and >150% load for 0.5 seconds before switching to BYPASS (when bypass input voltage and

frequency are WITHIN bypass limits) or SHUTDOWN (when bypass input voltage or frequency are OUTSIDE

bypass limits)

Power Factor 0.9

Crest Factor 3:1

Nominal Voltage Details 120V default

Frequency Compatibility 50 / 60 Hz; Supports 50 to 60 Hz and 60 to 50 Hz conversion

Frequency Compatibility Details ON LINE MODE: Output frequency is automatically configured to match nominal input frequency on startup; Output

matches input frequency when +/-5Hz of nominal; Output is regulated to +/-0.05Hz when input frequency exceeds

+/-5Hz of nominal. UPS switches to battery mode when input frequency is below 40Hz or above 70Hz.

FREQUENCY REGULATION / CONVERSION MODE: Output is regulated to +/-0.05Hz of selected output frequency

when input is 40 to 70Hz; UPS switches to battery mode when input frequency is below 40Hz or above 70Hz.

BATTERY MODE: Output is regulated to +/-0.05Hz of selected nominal.

Output Voltage Regulation (Line

Mode) +/- 2%

Output Voltage Regulation

(Economy Line Mode) +/- 10%

Output Voltage Regulation (Battery

Mode) +/- 3%

Load Management Receptacles Two switchable single-outlet 5-15R load banks

Output AC Waveform (AC Mode) Pure Sine wave

Output AC Waveform (Battery

Mode) Pure Sine wave

Nominal Output Voltage(s)

Supported 100V; 110V; 115V; 120V; 127V

Output Receptacles (6) 5-15R

Individually Controllable Load Banks Yes

BATTERY

Battery Type Valve Regulated Lead Acid (VRLA)

Full Load Runtime (min.) 3.8 min. (900w)

Half Load Runtime (min.) 12.8 min. (450w)

Expandable Battery Runtime Extended runtime supported via optional external battery packs

Expandable Runtime Yes

Expandable Runtime Description External battery configurations require the use of Tripp Lite's External Battery Configuration Software, see manual

for details

3 / 6

External Battery Pack Compatibility  <a class="productLink" href="//www.tripplite.com/External-24V-2U-Rack-Tower-Battery-Pack-for-select-Tripp-

Lite-UPS-Systems~BP24V15RT2U">BP24V15RT2U</a>  (limit 1);  <a class="productLink"

href="//www.tripplite.com/External-24V-2U-Rack-Tower-Battery-Pack-select-Tripp-Lite-UPS-Systems~BP24V28-

2U">BP24V28-2U</a>  (limit 1);  <a class="productLink" href="//www.tripplite.com/External-24V-3U-

Rack-Tower-Battery-Pack-select-Tripp-Lite-UPS-Systems~BP24V70-3U">BP24V70-3U</a>  (multi-pack

compatible)

DC System Voltage (VDC) 24

Battery Recharge Rate (Included

Batteries) Less than 3 hours from 10% to 90% (typical, full load discharge)

Battery Access Battery access door

Internal UPS Replacement Battery

Cartridge  <a class="productLink" href="//www.tripplite.com/2U-UPS-Replacement-Battery-Cartridge-for-Select-Tripp-

Lite-UPS~RBC24V-LCD">RBC24V-LCD</a>

Battery Replacement Description Hot-swappable, user replaceable batteries

VOLTAGE REGULATION

Voltage Regulation Description Online, double-conversion power conditioning

Overvoltage Correction 2% output voltage regulation during overvoltages to 150

Undervoltage Correction 2% output voltage regulation during undervoltages to 55V (33% load), 70V (70% load), 100V (100% load)

USER INTERFACE, ALERTS & CONTROLS

Front Panel LCD Display Front panel LCD information and configuration screen offers detailed UPS and site power status and operating data,

plus configuration of voltage, frequency, operating mode, alarm function and a variety of additional options

Switches 2 switches control off/on power status and alarm-cancel/self-test operation

Alarm Cancel Operation Power-fail alarm can be temporarily silenced using alarm-cancel switch; silent mode alarm configuration option

available

Audible Alarm Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown

conditions

SURGE / NOISE SUPPRESSION

UPS AC Suppression Joule Rating 570

UPS AC Suppression Response

Time Instantaneous

UPS Dataline Suppression 1 line TEL/DSL (1 in / 1 out); 10/100Base T Ethernet

EMI / RFI AC Noise Suppression Yes

PHYSICAL

Primary Form Factor Tower

Cooling Method Fan

Installation Form Factors Supported

with Included Accessories Tower

Primary UPS Depth (mm) 335

Primary UPS Height (mm) 254

Primary UPS Width (mm) 173

4 / 6

Shipping Dimensions (hwd / cm) 35.31 x 24.89 x 45.72

Shipping Dimensions (hwd / in.) 13.90 x 9.80 x 18.00

Shipping Weight (kg) 15.20

Shipping Weight (lbs.) 33.50

UPS Housing Material Steel

UPS Power Module Dimensions

(hwd, cm) 25.40 x 17.27 x 33.53

UPS Power Module Dimensions

(hwd, in.) 10 x 6.8 x 13.2

UPS Power Module Weight (kg) 13.02

UPS Power Module Weight (lbs.) 28.7

ENVIRONMENTAL

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Relative Humidity 0 to 95%, non-condensing

AC Mode BTU / Hr. (Full Load) 341

AC Economy Mode BTU / Hr. (Full

Load) 128

Battery Mode BTU / Hr. (Full Load) 585

AC Mode Efficiency Rating (100%

Load) 90%

AC Economy Mode Efficiency Rating

(100% Load) 95%

Audible Noise < 50 dB at front side 1m

Operating Elevation (m) Up to 3000m

COMMUNICATIONS

Network Management Cards  <a class="productLink" href="//www.tripplite.com/SNMP-Web-Management-Accessory-Card-SmartPro-

SmartOnline-UPS-Systems~SNMPWEBCARD">SNMPWEBCARD</a> ;  <a class="productLink"

href="//www.tripplite.com/Web-Management-Accessory-Card-SmartPro-SmartOnline-UPS-

Systems~TLNETCARD">TLNETCARD</a> ;  <a class="productLink" href="//www.tripplite.com/Web-

Management-Accessory-Card~WEBCARDLX">WEBCARDLX</a> ;  <a class="productLink"

href="//www.tripplite.com/MODBUS-Management-Accessory-Card-UPS-Remote-Monitoring-

Control~MODBUSCARD">MODBUSCARD</a> ;  <a class="productLink"

href="//www.tripplite.com/Programmable-Relay-I-O-Card~RELAYIOCARD">RELAYIOCARD</a>

Network Monitoring Port Description Supports detailed monitoring of UPS and site power conditions; DB9 port supports RS232 and contact closure

communications

PowerAlert Software For local monitoring via the UPS’s built-in communication ports, download PowerAlert Local software at

https://www.tripplite.com/poweralert

Communications Cable USB and DB9 cabling included

WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

Network Management Card

Description Network management card optional

5 / 6

not imply any affiliation with or endorsement by them. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Tripp Lite uses primary and third-party agencies to test its products for compliance with standards. See a list of Tripp Lite's testing agencies:

https://www.tripplite.com/products/product-certification-agencies

Communications Interface Contact closure; DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface; USB (HID enabled)

LINE / BATTERY TRANSFER

Transfer Time Zero transfer time (0 ms.) in online, double-conversion and frequency regulation / conversion modes;

Low Voltage Transfer to Battery

Power (Setpoint) 55V (33% load), 70V (70% load), 100V (100% load)

High Voltage Transfer to Battery

Power (Setpoint) 150

FEATURES & SPECIFICATIONS

Cold Start (Startup in Battery Mode

During a Power Failure) Cold-start operation supported

High Availability UPS Features Auto Probe Monitoring and Reboot (requires WEBCARDLX); Automatic inverter bypass; Expandable battery backup;

Hot swappable batteries; On-Line/Double-Conversion; Remote management; Sine wave output; Surge/noise

protection; Zero transfer time

Green Energy-Saving Features High efficiency economy mode operation; Individually controllable load banks; Schedulable daily hours of economy

mode operation

STANDARDS & COMPLIANCE

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)

WARRANTY

Product Warranty Period

(Worldwide) 2-year limited warranty

Connected Equipment Insurance

(U.S., Canada & Puerto Rico) $250,000 <a class="insuranceLink" href="//www.tripplite.com/support/insurance-policy">Ultimate Lifetime

Insurance</a>

6 / 6

Indice

Altri manuali Tripp Lite UPS

Tripp Lite

Tripp Lite SMART1000LCDU Manuale utente

Tripp Lite

Tripp Lite SMART1200LCD Manuale utente

Tripp Lite

Tripp Lite OmniSmart UL2601-1 Manuale utente

Tripp Lite

Tripp Lite INTERNET550U Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU8000RT3U Manuale utente

Tripp Lite

Tripp Lite UPS System AVRX750U Manuale utente

Tripp Lite

Tripp Lite BCPERS450 Manuale utente

Tripp Lite

Tripp Lite SmartPro SMART1500 Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU1000RTXL2U Manuale utente

Tripp Lite

Tripp Lite SMARTINT3000VS Manuale utente

Tripp Lite

Tripp Lite SmartOnline Single-Phase 10kVA Manuale utente

Tripp Lite

Tripp Lite SmartPro SMART1500RM2UL Manuale utente

Tripp Lite

Tripp Lite SmartPro SMART500USB Manuale utente

Tripp Lite

Tripp Lite SmartPro SMX1200XLHG Manuale utente

Tripp Lite

Tripp Lite SMART3000RM2UL Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU12000RT4UHW Manuale utente

Tripp Lite

Tripp Lite SU10KMBPKX Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU3000RTXL2U Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU16KRT Manuale utente

Tripp Lite

Tripp Lite SmartPro SMART3000RMXL2U Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU1500XL Manuale utente

Tripp Lite

Tripp Lite SM3000RMNAFTA Manuale utente

Tripp Lite

Tripp Lite INTERNET900U Guida

Tripp Lite

Tripp Lite BCPERS450 Manuale utente

Manuali UPS popolari di altre marche

Pylontech

Pylontech Victron & Pylontech US5000 Manuale utente

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuale utente

Mecer

Mecer ME-1000-WTU Manuale utente

Mustek

Mustek PowerMust 530(B) Plus Manuale di installazione e funzionamento

Emerson

Emerson Liebert NXL series Manuale utente

MAKELSAN

MAKELSAN BOXER SERIES Manuale utente

Block

Block PC-0524-400-0 Manuale utente

CyberPower

CyberPower CP585LCD Manuale utente

Eaton

Eaton 3S Istruzioni per il montaggio

CyberPower

CyberPower Office Tower Series UPS 1000 Manuale utente

CyberPower

CyberPower BM100 Manuale utente

Best Power

Best Power 610 Manuale utente

Best Power

Best Power Unity/I UT3K Manuale utente

Mustek

Mustek PowerMust 400 Offline Manuale utente

Xantrex

Xantrex Trace 512 UR-UPS Manuale utente

Forza

Forza SL-1501UL Manuale utente

LEGRAND

LEGRAND keor 310081 Manuale utente

ABB

ABB Conceptpower DPA 500 Manuale utente
