Tripp Lite TE Series Manuale utente

1111 W. 35th Street

Chicago, IL 60609 USA

Customer Support: (773) 869-1234

www.tripplite.com

Quick Installation: p. 3

Basic Operation: p. 4 - 5

Storage & Service: p. 5

Specifications: p. 6

Safety: p. 2

Warranty & Insurance: p. 6

Owner's Manual

TE SERIES

Standby UPS Systems (120V)

ESPAÑOL:p.7-11

FRANÇAIS:p.12-16

This manual contains important instructions and warnings that should be

followed during the installation, operation and storage of all Tripp Lite UPS

Systems. SAVE THESE INSTRUCTIONS

UPS Location Warnings

• Install your UPS indoors, away from excess moisture, heat, dust

and direct sunlight.

• For best performance, keep the indoor temperature between 32° F

and 104° F (between 0° C and 40° C).

• Leave adequate space around all sides of the UPS for proper ventilation.

UPS Connection Warnings

• Connect your UPS to a three-wire, grounded AC power outlet. Do not

remove or modify the ground pin of the UPS's plug. Do not use two-

prong adapters with the UPS's plug.

• Do not plug your UPS into itself; this will damage the UPS and void your

warranty.

• If you are connecting your UPS to a motor-powered AC generator,

the generator must provide clean, filtered computer-grade output.

Equipment Connection Warnings

• Do not use Tripp Lite UPS Systems for life support applications in which

a malfunction or failure of a Tripp Lite UPS System could cause failure

or significantly alter the performance of a life-support device.

• Do not connect surge suppressors to the output of your UPS. This may

damage your UPS and will void both the surge suppressor and UPS

warranties.

Battery Warnings

• Your UPS does not require routine maintenance. Do not open your UPS

for any reason. There are no user-serviceable parts inside.

• Battery replacement must be performed by qualified service personnel.

Because the batteries present a risk of electrical shock and burn from

high short-circuit current, observe proper precautions. Unplug and

turn off the UPS before performing battery replacement. Use tools

with insulated handles and replace the existing batteries with the same

number and type of new batteries (Sealed Lead-Acid). Do not open the

batteries. Do not short or bridge the battery terminals with any object.

• The UPS batteries are recyclable. Refer to local codes for disposal

requirements or call 1-800-SAV-LEAD (1-800-728-5323) for complete

recycling information. Do not dispose of the batteries in a fire.

• Do not attempt to add external batteries.

Important Safety Instructions

Quick Installation

Plug your UPS into an

electrical outlet.

Plug your computer,

monitor and external

modem into battery-

supported outlets. Plug

other equipment into

surge-only outlets.*

Set your UPS’s “OFF –

ON” Switch.**

USA, Canada & Western Europe

· Set it and leave it “ON” at all times.

All Other Countries

· Set to “OFF” when you are not using

connected equipment.

(WARNING! When set to "OFF," UPS will not

provide battery backup during a blackout or

brownout)

· Set to “ON” when you are using

connected equipment.

–Optional Installation–

(select models)*

OPTION 1 (UPS Software)

Using Tripp Lite Cable (if supplied) connect

the DB9 port of your UPS to the DB9 port of

your computer. Load software (if supplied)

and run the installation program appropri-

ate for your operating system.

OPTION2(BrownoutVoltageAdjustment)

Adjust the Voltage Potentiometer (UPS

back panel) clockwise to lower the voltage

point at which the UPS switches from on-

line to battery output.**

* Your UPS will function properly without these

connections or settings. ** For users who

experience frequent, severe brownouts to avoid

excessive battery drain. Note: Use caution when

adjusting the potentiometer while the UPS is

powering a voltage-sensitive load.

* Separate battery-supported/surge and surge-only outlets are available only on select models (identified on the back of

your UPS). Your UPS is designed to support only computer equipment. You will overload your UPS if you connect

household appliances, laser printers or surge suppressors. ** See Basic Operation section for the Switch Function, UPS

Conditions and Setting Advantages.

OPTION 2

OPTION 1

NORM

Switches

With your UPS plugged in, set this switch according to the

recommendations in Step 3 of the Quick Installation section.

"ON" Position

Function: ENABLES battery backup. UPS Conditions: The UPS

battery is charging. Power is ON at the UPS receptacles. The " "

indicator light is illuminated. Setting Advantages: Provides bat-

tery backup during blackouts or brownouts.

"OFF" Position

Function: DISABLES battery backup. UPS Conditions: The UPS

battery is charging. Power is ON at the UPS receptacles. The " "

indicator light is illuminated. The " " indicator light is flashing.

Setting Advantages: continues to charge the battery when power

is present while turning OFF the inverter to prevent battery backup

operation when equipment is not in use.

Note: Only UPS models equipped with a “MUTE/TEST” switch allow you to “cold start” them and

use them as stand-alone power sources when utility power is not present. To “cold start” your UPS,

first turn your UPS ON. Then, move the MUTE/TEST switch to the left, hold momentarily and

release when the " " indicator light begins to flash.

Use this momentary switch to do two things:

Silence the UPS alarm*

Move this switch to the left and release it. Note: When the battery

is nearly depleted the alarm resumes (and cannot be silenced) to

alert you to immediately shut down connected equipment.

Test your UPS's battery charge

Leave your connected equipment ON. With your UPS plugged in

and turned ON, move this switch to the left; hold it there for 2

seconds and release it. The UPS will momentarily switch to battery

to test its charge. If the UPS alarm sounds or the properly-sized

load is not supported, let your UPS charge its batteries for 12 hours

and repeat the test. If alarm still sounds, contact Tripp Lite for

service. CAUTION: Do not unplug your UPS to test its batteries.

This will remove safe electrical grounding and may introduce a

damaging surge into your network connections.

*The UPS alarm consists of a series of short beeps followed by a brief pause. The alarm is activated

when the UPS switches to battery during a blackout or brownout.

If you experience severe brownouts that cause the UPS to fre-

quently switch to battery, the adjustable voltage potentiometer

allows you to prevent excessive battery drain by lowering the

voltage point at which the UPS switches to battery. Turn it

clockwise to lower the voltage point as much as 18% below the

nominal setting of 99 volts (set fully clockwise).

Note: Your UPS’s optimal setting will depend on the voltage conditions in your area. Adjust it

clockwise until you reduce the frequency your UPS switches to battery. Your UPS will function

properly at any setting. Use caution when adjusting the potentiometer while the UPS is powering

voltage-sensitive loads.

Basic Operation

OFF ON

NORM

Available

on select

models

Other UPS Features

AC Receptacles

The receptacles provide your connected equipment with AC line

power during normal operation. They will provide battery power

during blackouts and brownouts only if the “OFF/ON” Switch is set

to the “ON” position. The receptacles also protect your equipment

against damaging surges and line noise. Select models, however,

feature “surge-only” receptacles (identified on the back of your

UPS) that provide peripherals with surge protection without com-

mitting precious battery power to support them during blackouts.

DB9 Port (Available on select models)

The DB9 port connects your UPS to any workstation or server. Use

with Tripp Lite software and cabling to automatically save open

files and shut down equipment during a blackout. This port sends

contact-closure signals to indicate line-fail and low-battery sta-

tus. It also receives a shut down signal from the connected

computer to conserve the UPS battery charge. Contact Tripp Lite

Customer Support for more information.

Indicator Lights

All Indicator Light descriptions apply when the UPS is plugged into a

wall outlet and turned ON.

This green light will turn ON whenever your UPS is plugged in and

receiving normal AC line power.

This red light will turn ON when your UPS is providing your

equipment with battery power.

This yellow light will turn ON after you test your UPS battery’s

charge with the “Mute/Test” Switch to indicate that the UPS’s

battery is less than fully charged. If it stays on continuously,

contact Tripp Lite for service. The light will flash after you set the

“OFF/ON” Switch to the “OFF” position to indicate that the UPS will

not provide battery backup during a blackout or brownout.

This red light will turn ON when the UPS’s capacity has been

exceeded while it is operating from battery power (either during a

self-test or during a blackout). Remove overload from battery-

supported outlets immediately.

Available on

select models

FCC Part 68 Notice (U.S. only)

If your Fax Modem Protector causes harm to the telephone network, the telephone company may temporarily discontinue your service. If possible,

they will notify you in advance. If advance notice isn’t practical, you will be notified as soon as possible. You will be advised of your right to file

a complaint with the FCC. Your telephone company may make changes in its facilities, equipment, operations or procedures that could affect the

proper operation of your equipment. If it does, you will be given advance notice to give you an opportunity to maintain uninterrupted service. If

you experience trouble with this equipment, Fax Modem Protector, please contact the Manager of Technical Support; Tripp Lite; 1111 W. 35th

Street, Chicago, Illinois 60609; Phone: (773) 869-1234, for repair/warranty information. The telephone company may ask you to disconnect this

equipment from the network until the problem has been corrected or you are sure the equipment is not malfunctioning. There are no repairs that

can be made by the customer to the Fax Modem Protector. This equipment may not be used on coin service provided by the telephone company.

Connection to party lines is subject to state tariffs. (Contact your state public utility commission or corporation commission for information.)

TE 300 TE 700L

Output Capacity (VA/Watts): 300/200 700/450

Battery Runtime (Half Load/Full Load) Minutes: 86/37 83/35

Battery Recharge Time: 2-4 hrs. 2-4 hrs.

Approvals: UL, cUL, NOM UL, cUL, NOM

Modem/Fax Protection (starts at 260V): 1 line –

ALL MODELS:

Input Voltage/Frequency (120V/60 Hz); On Battery Output Voltage Range (120V +/- 5%); Output Waveform Line Mode (filtered sine

wave); Output Waveform Battery Mode (PWM sine wave); AC Surge Suppression (exceeds IEEE 587 Cat. A & B standards); AC Noise

Attenuation (>40 dB); AC Protection Modes (H to N, H to G, N to G)

Specifications

Storage & Service

Storage

First turn your UPS OFF and disconnect its power cord from the wall outlet. Then

disconnect all equipment to avoid battery drain. If you plan on storing your UPS

for an extended period of time, fully recharge the UPS batteries once every three

months by plugging the UPS into a live AC outlet and letting the UPS charge for

4 to 6 hours. If you leave your UPS batteries discharged for an extended period

of time, they will suffer a permanent loss of capacity.

Service

If returning your UPS to Tripp Lite, please carefully pack the UPS using the

ORIGINAL PACKING MATERIAL that came with the unit. Enclose a letter

describing the symptoms of the problem. If the UPS is within the 2 year warranty

period, enclose a copy of your sales receipt.

Battery Replacement Door

Under normal conditions, the original battery in your UPS will last

several years. Battery replacement should be performed only by

qualified service personnel. Refer to “Battery Warnings” in the

Safety section on page 2.

Altri manuali per TE Series

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Tripp Lite UPS

Tripp Lite

Tripp Lite SmartOnline 220/380 Manuale utente

Tripp Lite

Tripp Lite SmartPro INT Rackmount Intelligent Network UPS... Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU6K Manuale utente

Tripp Lite

Tripp Lite HT1000UPS Manuale utente

Tripp Lite

Tripp Lite SmartOnline 5KVA Manuale utente

Tripp Lite

Tripp Lite AVRT450U Manuale utente

Tripp Lite

Tripp Lite AGOM5516 Manuale utente

Tripp Lite

Tripp Lite SmartOnline Single-Phase 10kVA Manuale utente

Tripp Lite

Tripp Lite SMART2200RM2UN Guida alla configurazione

Tripp Lite

Tripp Lite SmartOnline 220/380V Manuale utente

Tripp Lite

Tripp Lite SMART700DV Manuale utente

Tripp Lite

Tripp Lite SMARTINT3000VS Manuale utente

Tripp Lite

Tripp Lite SMART700HG Manuale utente

Tripp Lite

Tripp Lite ST750RMXL2U Manuale utente

Tripp Lite

Tripp Lite OMNIVS1500XLCD Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU1500LCD1U Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU2000RTXLCD2U Manuale utente

Tripp Lite

Tripp Lite UPS System AVRX550U Manuale utente

Tripp Lite

Tripp Lite SM1500RMXL2UTAA Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU750XL Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU3000RTXR3U Manuale utente

Tripp Lite

Tripp Lite AGSM5000Y3U3I Manuale utente

Tripp Lite

Tripp Lite SmartOnline SU1000RT2UHV Manuale utente

Tripp Lite

Tripp Lite OmniSmart OMNISMART1050 Manuale utente

Manuali UPS popolari di altre marche

Pylontech

Pylontech Victron & Pylontech US5000 Manuale utente

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuale utente

Mecer

Mecer ME-1000-WTU Manuale utente

Mustek

Mustek PowerMust 530(B) Plus Manuale di installazione e funzionamento

Emerson

Emerson Liebert NXL series Manuale utente

MAKELSAN

MAKELSAN BOXER SERIES Manuale utente

Block

Block PC-0524-400-0 Manuale utente

CyberPower

CyberPower CP585LCD Manuale utente

Eaton

Eaton 3S Istruzioni per il montaggio

CyberPower

CyberPower Office Tower Series UPS 1000 Manuale utente

CyberPower

CyberPower BM100 Manuale utente

Best Power

Best Power 610 Manuale utente

Best Power

Best Power Unity/I UT3K Manuale utente

Mustek

Mustek PowerMust 400 Offline Manuale utente

Xantrex

Xantrex Trace 512 UR-UPS Manuale utente

Forza

Forza SL-1501UL Manuale utente

LEGRAND

LEGRAND keor 310081 Manuale utente

ABB

ABB Conceptpower DPA 500 Manuale utente
