Uniden iGO CAM 800 Manuale utente
iGO CAM 800
Accident CAM
Vehicle Recorder
For more exciting new products please visit our website:
Australia: www.uniden.com.au
New Zealand: www.uniden.co.nz
NOTE
Uniden does not represent this product to be waterproof. Do not
expose this product to Rain or Moisture.
NOTE
This product is intended for use in a motor vehicle. Don’t install
the device where it will block the driver’s view of the road
(including the mirrors!) or the deployment of the airbag.
NOTE
Keep your attention on the road! Don’t try to operate or focus
on any device while driving. If you have to concentrate on a
device, pull off the road for a few minutes.
NOTE
Ensure that the camera lens is kept clean and there is nothing
blocking the lens.
NOTE
Don’t leave the device in direct sunlight for a long period of time
or where the temperature could go above 60°C.
2
UNIDEN iGO CAM 800 Vehicle Recorder
Important Safety Instructions
CONTENTS
Important Safety Instructions ............................................. 2
What Do I Do First? ................................................................4
Make Sure These Items Arrived in the Box ................................................4
Controls & Indicators ............................................................5
How Do I Put It in My Car? .................................................... 7
Attaching the Windshield Mount .................................................................7
Operation .............................................................................. 8
SD Card ...................................................................................................................8
Plug it in, Power On/O ................................................................................... 8
Video Mode .......................................................................................................10
Photo Mode .......................................................................................................14
Playback Mode ..................................................................................................16
Connecting to a PC ......................................................................................... 16
Important Information ...................................................................................17
Warranty ..............................................................................18
3
UNIDEN iGO CAM 800 Vehicle Recorder
4
UNIDEN iGO CAM 800 Vehicle Recorder
Make Sure These Items Arrived in the Box
What Do I Do First?
DC (CAR) Adaptor
USB Cable
AV Cable
• If any item is missing or damaged, contact your place of purchase
immediately. Never use damaged products!
• Need help? Get answers at our website:
www.uniden.com.au for Australian model.
www.uniden.co.nz for New Zealand model.
iGO CAM800
• Owner’s Manual
Windshield Mount
Controls & Indicators
Ref Component Description
1 Front Lens Front Lens
2 MENU In standby, open the Menu
3 MODE Use this button to switch between various modes -
Video, Photo and Playback
4 LED Left - glows red when the unit is charging
Right - glows red when the unit is powered on
5SOS In the Video mode, use this button to lock/save
(from overwrite) the current recording.
UNIDEN iGO CAM 800 5Vehicle Recorder
MODE
MENU
6Vehicle RecorderUNIDEN iGO CAM 800
6SWITCH Use this button to switch between the lenses
(front or back) to take a photo.
7UP • In Menu list, move the cursor, one line up
• Use this button to mute audio recordings
8 DOWN • In Menu list, move the cursor, one line down
• Use this button to get a full screen display.
9 Back Lens Back Lens
10 LCD Screen LCD Screen
11 Microphone Records sound
12 Power Press and hold to switch on or off the unit
13 Reset If the device fails to operate properly, try resetting
thedevice.Presstheresetbuttonbyusingane
pen or paperclip.
14 OK • In Video mode, press this button to start video
recording. Press again to stop recording.
• In Photo mode, press this button to take a photo
• Pressthisbuttontoconrmaselectioninthe
Menu.
• Conrmchangesinthesettings.
15 micro SD Card
Slot
Use this slot to insert the SD card
16 DC IN • Connect External Power & charge battery
• Connect to PC for data (SD card) transfer
17 AV Out Connects to an external device
18 Bracket Slot Fit the bracket hook of the windshield mount
7
UNIDEN iGO CAM 800 Vehicle Recorder
Attaching the Windshield Mount
How Do I Put It in My Car?
1. Insert the bracket hook into the bracket slot provided on the top of the unit.
L
2. After inserting the hook, slide it down till it locks in position.
NOTE
Suction cups will not stick well on a curved/textured or wet surfaces.
3.Pressthesuctioncupatagainstthewindshield.
4. Push the suction lock up, until it snaps into place and tighten the locking
collar to secure.
5. Gently pull on the mount to make sure it is secure.
It maybe a good idea to secure the power cord with cable clips so that it does
not interfere while driving.
SD Card
NOTE
A compatible micro SD card (not supplied) is required to
record and store video and photos.
The unit can support micro SDHC cards (High Capacity SD) up to 32GB in
capacity. A micro SDHC card of at least 4GB capacity and minimum Class 6
speed is recommended.
Insert a formatted micro SD card gently in the slot at the bottom of the unit. To
remove the card from the slot, press the edge of the SD card inwards for it to
pop out and then pull it out of the slot.
Plug it in, Power On/Off
NOTE
When connected to a car charger with power, the unit will power
on automatically, go into the video mode and start recording.
1. Connect the DC car adaptor to the power connector (USB port) found on
the device.
2. Connect the other end of the DC car adaptor to your car’s cigarette lighter.
3. When connected to the car charger the unit will power on automatically
and start recording.
At other times, press and hold the Power button to turn it on or off.
NOTE
Only use the DC car adaptor that comes with your device. Any
other adaptor might damage the device.
Operation
At other times, press and hold the Power button to turn it on or off.
8Vehicle RecorderUNIDEN iGO CAM 800
Full Half full Low Empty
Battery Information
Although primarily designed for in-car use, the unit can operate from its built-
in 800mAh battery for up to 35 minutes.
Please note, the power usage would depend on day/night recording and
resolution setting.
The unit will charge the battery whenever power is detected through the
USBport.Whentheunitisbeingcharged,theleftRedLEDwillash.Itwill
automatically turn off when the unit has been charged completely. The unit
will take about 2 hours to charge completely.
Battery Alert
The image given below indicates the battery level at different stages.
9
UNIDEN iGO CAM 800 Vehicle Recorder
10
UNIDEN iGO CAM 800 Vehicle Recorder
Video Mode
Recording
When connected to a car charger, the unit automatically starts recording, the
Videoiconwillstartashingonthescreen.
Tostoprecording,pressOKandtheVideoiconwillstopashingindicating
that the recording has stopped.
Protect the Current Recording
While recording, if you want to protect the current recordings, then press the
SOS button, the lock icon will appear on the screen. This indicates
thatthoserecordings/leshavebeenlockedandwillnotgetreplacedbynew
video clips, even when the SD card has reached its full capacity.
NOTE
To record a video, ensure that a valid SD card (not supplied) is
inserted in the given slot. Also note, that inserting/removing the
SD card causes the device to shutdown.
Using the iGO CAM 800 you can record videos and take photos. To record
videos, you need to ensure that the unit is in the video mode.
