OWNER'S MANUAL

ELITE 8805

ELITE SERIES

EXPANSION HANDSET

OWNER'S

MANUAL

Welcome

Checking the Package Contents

Congratulations on your purchase of the Uniden ELITE8805 Series optional

handset and charger. This expansion handset is compatible with models

in the following series: ELITE8815/ELITE8815+1 and

ELITE8855/ELITE8855+1 (Model numbers may vary).

Each model within this series will support up to ten handsets. You can

place a fully featured cordless handset anywhere in your home as long as

AC power is available to connect to the handset's charging cradle.

The ELITE8805 Series expansion handset will not operate unless it has

been registered to your main base. Refer to the owner's manual supplied

with your main base model for detailed instructions on operating your

new expansion handset.

Your phone is compatible with other Uniden 5.8GHz Digital Expandable

Systems. Models include the ELITE series (ELITE8815, ELITE8815+1,

ELITE8855 and ELITE8855+1) and the DSS7800 series (DSS7815,

DSS7815+1, DSS7855 and DSS7855+1).

Your new handset has many advanced features that may NOT be

supported by main base models such as the DSS7800 Series. Please visit

our website at www.uniden.com.au or www.uniden.co.nz for feature

comparisons.

Make sure you have received the following items in the package.

If any of these items are missing or damaged, contact your retailer.

IMPORTANT

Backward /Forward Compatibility

• Cordless Handset

• Charging Cradle

• AC Adapter (AAD-600S)

(INPUT:240V AC 50Hz)

(OUTPUT:9V DC 210 mA)

• Audio Recording Cable

• Battery Pack (BT-0003)

• Belt Clip

• This Owner’s Manual

• Other Printed Material

(1)

Installing Your Expansion Handset

Follow these three easy steps to get your new handset ready to use:

Install the battery pack.

Connect the charger and charge your new handset for 15 - 20 hours.

Press down on the handset battery case

cover (use the finger indention for a better

grip) and slide the cover downward to

remove.

Place the battery pack in the battery

compartment with the connectors on the

battery and on the compartment aligned.

Place the battery case cover back on the

handset and slide it upwards until it clicks

into place.

•

Replacement batteries are available.

Please see our website at

www.uniden.com.au or www.uniden.co.nz

• Recharge your handset on a regular

basis by returning the handset to

the charger after each phone call.

Rechargeable Ni-MH Batteries

Must Be Recycled or Disposed of Properly

Step 1: Install the Battery Pack

Use only the Uniden battery (BT-

0003) supplied with your phone.

(2)

Step 2: Connect the Charger

Step 3: Register the Handset

Connect the AC adapter to

the jack and to a

standard 240V AC wall outlet.

Set the charger on a desk or

tabletop, and place the

handset in the charger with

the LCD screen facing

forward.

Make sure the LED

illuminates. If the LED does not

illuminate, check to see that the AC adapter is plugged in and that

the handset makes good contact with the charger charging contacts.

•

• Place the charger close to the AC outlet so that you can

unplug the AC adapter easily.

Charge the handset for 15 - 20 hours before using.

DC IN 9V

charge

Use only the supplied AAD-600S AC adapter. Do not use

any other AC adapter.

YOU NEED TO REGISTER THE ELITE8805 SERIES TO THE MAIN BASE

BEFORE USE!

For Backward Compatible Base Models - DSS7800 series [DSS7815,

DSS7815+1, DSS7855 and DSS7855+1]

Disconnect the AC adapter from the main base.

While pressing down on the following key, reconnect the AC adaptor.

DSS7815/DSS7815+1 models - key

DSS7855/DSS7855+1 models - key

Keep pressing the key until the CHARGE LED starts to blink.

On the handset, press and hold the key until you hear a beep.

find handset

flash/find hs

(3)

For ELITE8815/ELITE8815+1

For Main Base Models ELITE8855/ELITE8855+1

Press and hold the Registration

button at the underside of the base.

Keep pressing the Registration

button until the handset charge

LED on main base starts to blink.

On the handset, press and hold the

key until you hear a beep.

With the main base in standby mode (i.e. not being used), press

on the base.

Use the up/down key to select .

The base LCD screen will display the following prompt:

On the handset, press and hold the key until you hear a beep.

menu/select

System Setup

On handset, press and hold "#" key for 2 sec

De-register the handset

Press and hold and for more than 5 seconds. Select

The phone will ask you to confirm the deregistration. Select .

Select at instruction 1 if handset has previously

been registered to another base and you want to register to a new

base.

end #

Deregister Hs

Yes

Replacing Base

(4)

Registration button

Using Your Expansion Handset

Now that your new handset is registered, it can perform all the same

functions as the handsets originally included with your phone. With

your new handset, you can;

• Transfer calls between handsets

• Use two handsets as 2-way radios in DirectLink mode

• Use two handsets or a handset and the base as a baby/room

monitor

• Hold 3 to 4 way conference calls (depends on the model)

• Access the integrated answering device or voice mail using the

handset

• Record Distinctive Ringer Tones

See the owner's manual that came with your main base for complete

instructions on operating your new expanded digital phone. You can

also download owner's manuals from our website at www.uniden.com.au or

www.uniden.co.nz.

(5)

Using the joystick

The joystick makes it easy

to use your phone. The

four most commonly used

functions are accessible

just by moving the

joystick:

To enter the menu, press the centre of

the joystick inwards.

Highlight the option you want by moving the

joystick up, down, right, or left on the

handset. This will move the cursor; the

option currently highlighted appears in

reversed out text.

Select the highlighted option by pressing in

on the center of the joystick.

To exit the MENU and return to standby, press the key on the

handset.

To go back a level in the menu, press the

end

back/hold/int'com

(6)

Setting Advanced Features

• When using your handset with the backward-compatible

DSS7800 Series (DSS7815, DSS7815+1, DSS7855 and

DSS7855+1), some advanced features (such as

Reminders) may not be compatible.

• Please refer to your respective (DSS7815, DSS7815+1,

DSS7855 and DSS7855+1) Owner's Manual.

1) Connect the audio recording cable to the handset and sound source

(e.g. stereo or CD player). Insert one end of the audio recording

cable into the handset's headset jack and the other end into the

sound source. You can also simply use the handset's microphone by

holding the handset close to the sound source.

2) Select menu option .

3) Go to .

4) Select a location from 1-5, and press the soft key.

5) Select . To start recording, press the soft key. The

message counter displays 20 and then begins to count down.

6) When you are finished recording, press the soft key. The

phone will play the recorded ringer. To re-record the ringer, press

the soft key.

7) Enter the title of this ringer (up to 12 Characters) using the number

keypad, the soft key, right, or left key.

8) Press the center of the joystick, you will hear a confirmation tone,

and appears.

1) Select menu option .

2) Go to and highlight the animation you want.

3) Press the soft key to activate it.

1) Select menu option .

2) Go to and highlight the wallpaper you want. Press the

soft key to see the wallpaper or the center of the joystick to

activate it.

Record Ringer Tones

OPTIONS

RECORD

STOP

ReRec

DELETE

Set Animation Type

SELECT

Set Themes (wallpaper)

VIEW

Rec/Edit Rings

Record

Done!

Animation Type

Wall Paper

(7)

Set Color Scheme (Color handsets Only)

Creating and Editing Phonebook Entries

STORE

OPTIONS

DONE

Operational Restrictions

Setting Privacy Mode

OPTIONS

1) Select menu option .

2) Go to and select the color you want. As you scroll

through the options, the phone displays the highlighted color for you.

Press the joystick to the left, and then press the soft key for the

1st entry. From the 2nd entry, press the soft key. Select

to store, or to edit the location. Enter as

much information as you want. Press the center of the joystick to enter

each entry and confirm the selection. When you finish, press the

soft key to save this phonebook entry.

Several of your handset's advanced settings such as Room Monitor,

Unique ID and Call Privacy, will operate differently with the DSS7800

Series Phones.

Privacy mode prevents interruption from other registered handsets or

the base. This works only when the phone is in use:

While on a call, press the soft key. Use the joystick to select

appears in the display. To exit

Privacy Mode, use the same procedure.

1) Select menu option .

2) Go to

3) Select .

4) Use the joystick to select .

You will hear a confirmation tone.

Color Scheme

New

Entry Edit Selection

Call

Privacy, Privacy Mode On

Handset.

Call Privacy

(8)

Setting Unique ID

Setting Room Monitor On/Off

You can assign special ringer tones to anyone in your phonebook. When

your phone gets a call, it looks up the Caller ID information in your

phonebook; if you have assigned a distinctive ringer and pictures to

that number, the phone uses them to tell you who's calling.

1) Select .

2) Go to

3) Select .

4) Use the joystick to select .

A confirmation tone tells you that distinctive ringing is active.

When viewing a Caller ID entry, the picture that

corresponds to the Phonebook Unique ID setting appears.

If the Unique ID is set to Off, the phone uses the default

picture for viewing Caller ID entries.

To prevent the monitoring of a particular handset or the base, simply

turn off the Room Monitor Feature.

To turn off the Room Monitor:

1) Select .

2) Go to .

3) Select .

4) Use the joystick to select .

You will hear a confirmation tone.

Handset.

Unique ID

Handset

Room Monitor

Off

(9)

Indice

Altri manuali Uniden Cornetta

Uniden

Uniden WDECT 2355 Manuale utente

Uniden

Uniden WDECT2380 Manuale utente

Uniden

Uniden DECT 3105 Manuale utente

Uniden

Uniden DCX291 Manuale di servizio

Uniden

Uniden DCX320 Manuale di servizio

Uniden

Uniden MULTIRANGE DRX332 Manuale utente

Uniden

Uniden TCX860 Manuale utente

Uniden

Uniden TCX4 Series Manuale utente

Uniden

Uniden DCX170 Manuale utente

Uniden

Uniden WDECT2380 Manuale utente

Uniden

Uniden XDECT 8105WP Manuale utente

Uniden

Uniden DSS 2405 Manuale utente

Uniden

Uniden DWX337 Manuale utente

Uniden

Uniden TCX 805 Manuale utente

Uniden

Uniden DCX170 Manuale utente

Uniden

Uniden DCX170BT Manuale utente

Uniden

Uniden DCX330 Manuale utente

Uniden

Uniden DS 805 Manuale utente

Uniden

Uniden TRUc46 Manuale utente

Uniden

Uniden DECT1820 Manuale utente

Uniden

Uniden DCX160 Manuale utente

Uniden

Uniden TCX860 Manuale utente

Uniden

Uniden DCX220 Manuale utente

Uniden

Uniden D1484 series Manuale utente

Manuali Cornetta popolari di altre marche

Swissvoice

Swissvoice ePure HD Manuale utente

Philips

Philips TD6736/BH051P Manuale utente

ASCOM

ASCOM I62 - Manuale utente

LG-Ericsson

LG-Ericsson LIP-9010 Manuale utente

GE 1583 Manuale utente

iiNet

iiNet Handset Manuale utente

ASCOM

ASCOM 9p23 Manuale utente

AT&T

AT&T DLP70110 Manuale utente

AirCell

AirCell ST 3100 Manuale utente

Eaton

Eaton HHIR-LCD-PROG Istruzioni per il montaggio

Mitel

Mitel 112 Manuale utente

SBC

SBC SBC-381H Manuale utente

Mitel

Mitel 5602 Manuale utente

ASCOM

ASCOM d81 Messenger Istruzioni per l'installazione

SpectraLink

SpectraLink 7522 Manuale utente

Avaya

Avaya L100 Series Come usare

ooma

ooma HD2 Handset Manuale utente

Yealink

Yealink IPW56 Manuale utente
