Urive Albatross Manuale utente
User manual
This is an auxiliary product for safe driving.
The Manufacturer is not held responsible for liability arising from an accident.
Use the product in accordance with the intended use.
CONTENTS
01. Before getting started with Urive Albatross Mini ............... 2
02. Precautions before using the product .............................3
03. Precautions when using the product.............................. 4
04. Features.................................................................. 6
05. Components ............................................................. 9
06. Names of Parts and Function Description ..................... 10
07. Features and Connectors ........................................... 13
08. Firmware Update.......................................................15
09. Installation Precautions.............................................. 18
10. Installation ............................................................... 19
11. GUI (Graphic User Interface)........................................ 21
12. Voice Guidance.........................................................32
13. PC Viewer Installation ................................................33
14. PC Viewer – Main.....................................................34
15. PC Viewer – Viewer Buttons........................................35
16. PC Viewer – Black-box configuration............................38
17. PC Viewer – Play List ............................................... 44
18. PC Viewer – File Open ..............................................45
19. PC Viewer – SD Card Format and Restore................... 46
20. PC Viewer – Driving Record Trace ............................. 49
21. PC Viewer – Full Screen .............................................51
22. PC Viewer - File folder’s structure...............................52
23. PC Viewer - Each file size and saving capacity .............53
24. Technical Specifications.............................................54
25. Warranty .................................................................55
2 _
01
Before getting started with Urive Albatross Mini
Urive Albatross Mini is a safety assistance device for vehicle that records front and rear image and sound
of when driving and parking.
#
Urive Albatross Mini is a trademark of MiDong E&T Co., Ltd.
#
All descriptions and contents included in this manual are protected by relevant copyright laws.
#
All other products and services used in this manual are the registered trademarks of their respective owners.
#
All the program rights used in the product belong to MiDong E&T Co., Ltd. and are protected according to relevant
copyright laws.
#
This manual is based on current conditions and may include technical or editorial errors and omissions.
#
Some changes can be made in the product to improve Urive Albatross Mini’s performance even without prior notice
to users.
#
The images used in the manual may look different from the actual screen displays depending on the printing quality.
#
It is recommended that users should read this manual carefully before using the product to use the device properly
and Safely.
#
For your own safety, please do not operate the device while driving
•#The user manual can be changed without a prior notice to users for the purpose of improving the performance of the
functions of the product.
User's Manual _ 3
02
Precautions before using the product
#
Warranty and Coverage
-
#
This product is a safety assistance device for a vehicle. The user is liable for any malfunction, failure, accident and damage to
product and car.
-
#
Depending on the driving conditions, vehicle type, and navigation environments, some functions may not be supported.
Functional support related to firmware updates for more reliable and advanced quality may vary by product. In addition,
please use this apparatus as a reference to check the driving video since the video recording function may not work in some
environments or conditions
-
#
This product does not guarantee that it records all videos of accidents and any accidents caused by an impact not big enough
to trigger the impact sensor (G-SENSOR) may not be identified as an impact video and, consequently, may not be recorded.
#
Micro SD Memory Card
-
#
Please check Micro SD memory card at least once a week and normal operation
-
#
Please format Micro SD memory card at least twice a month for normal operation
-
#
It is highly recommended to use genuine Urive Micro SD memory card.
-
#
If the micro SD memory card is inserted forcibly into the wrong direction, the card and main body may be damaged.
-
#
Use 64GB Micro SD memory card after formatting the card with Urive PC viewer or Albatross Mini main body.
Generally, the memory card has a lifetime during which it can be used (6 months are guaranteed). If it has been used for
a long period of time, it would be impossible to store new data. In that case, users need to buy a new memory card for
using the product. It should be understood in advance that the company will not be held responsible, at all, for data loss
due to long-time use. Removing the memory card or turning its power off while the recording is in progress may cause
stored data at the last stage to be deleted. The company will not be held responsible for it at all. It is recommended to
copy and store important data into other recording units.
4 _
03
Precautions when using the product
Warning - violation of the instruction may cause death or serious human injury.
The following instructions are given to ensure your safety and prevent the loss of property. Read them
thoroughly and ensure the product is correctly used. The user is liable for any damage to the product or the
car resulting from failure to follow this instruction.
Do not remodel or cut the power cable. It may result in
damage to the product or the car. The user is liable for any
damage to the product or the car caused by the remodeling
or cutting of the power cable.
Do not use out of rated voltage. Users may damaged caused
by fire or electric shock.
Do not touch the power cable with wet hands. It may result
in electrical shock.
Do not disassemble or apply shock on it arbitrarily. It may
carouse of It may result in damage to the product.
If the product is not be used for a long time, please detach
the power cable from the product or the car. The user is liable
for any damage to the product caused by the remaining of
the power cable.
Refrain from installing or manipulating the product while
driving. It may result in an accident.
User's Manual _ 5
03
Precaution - Minor injuries or insignificant damage to the product could be caused if violating the
instructions
Do not use the product for a long period of time while
connected to the electrical power of the vehicle directly.
Otherwise, the battery could be discharged.
Be careful about a reflective device, such as a navigation
device or a hi-pass terminal.
The screen will be reflected on the windshield, causing the input of video
to be interfered with. In that case, the quality of video may be degraded.
Apply the dual-side tape firmly when installing the product.
Its position can be changed when used for a long period of time or due
to the vibration from the vehicle, possibly causing the performance to
be degraded.
Take precautions when installing the external camera.
When installing it on the rear window, the quality of video will vary
depending on the density of the tinted film.
Keep the windshield clean in front of the front camera lens
always.
If the video that is improperly recorded due to impurities is fed, the
recording of the video while driving will not take place normally.
Users should pay attention to it.
Recording may not take place normally when using a non-
certified micro SD card.
The memory card must be inserted or removed while the power cable is
disconnected.
Back up the stored file periodically.
When the memory usage exceeds a certain level, files will be deleted
starting with the oldest ones while new ones are saved. Considering
that, it is required to back up the stored files periodically to prevent
necessary ones from being removed.
Keep the memory card separately when a car accident occurs
or when the card is checked for any damage .
When the black box is used continuously and the memory usage level
exceeds a certain level, files will be deleted starting with the oldest
ones in individual folders while new ones are stored, which could cause
necessary files to be deleted.
6 _
04
Features
High-quality video recording with clear images and an optimal viewing angle
- Resolution: Front 1280x720, Rear 1280x720
- Viewing angle(diagonal): Front 120°, Rear 105°
Full touch LCD screen with smart GUI
- The front and rear real time video and recorded video files can be viewed on a 3.0-inch wide LCD screen. In addition,
thanks to a smart GUI-based touch method, environment setting and SD card formatting can be carried out directly
from the LCD screen.
Real time image check and record on 3” LCD screen
Real time image check and record on 3” LCD screen with PIP (Picture-in-picture) and Drag-and-drop for front and rear
images. System configuration and SD card format available with a touch.
Formatting on the LCD function is supported
The auto format function is supported on the Albatross Mini’s touch LCD.
Driving Mode
Records videos in 1minute segment.
Event (Impact) Mode
Detects impact and saves 20 second of video with built-in 3D G-Sensor (10 seconds before and after the impact) in the
event folder in driving mode.
User's Manual _ 7
04
Manual (Forced) Mode
Saves 20 second of video in driving mode by touching “Manual Recording” button on the screen (10 seconds before
and after the touch) in the event folder.
Intelligent parking monitoring
Records automatically video with motion detector, a differentiated technology from Urive, when the car gets shock or
detects any motion near the car while the car is parked.
Automated memory management
The system overwrites sequentially from the oldest files to record and save the latest driving, events and parking
surveillance regardless of the volume limit of memory card.
Genuine Urive Albatross Mini PC viewer
Urive Albatross Mini PC viewer provides convenient file play, system configuration and firmware update functions with
stylish GUI.
Battery discharge protection device
In order to prevent a car battery from discharge during the parking mode, Urive Albatross Mini has parking timer and
voltage cut-off setting mode. If the voltage is lower than the set volume, it executes the voltage cut-off automatically
for preventing the car discharging. Users can set the cut-off voltage in the dedicated viewer. (cut off voltage: 5stpes,
timer: 5 steps)
8 _
04
Voice announcement and voice recording
Auto-saver
1)
#
The auto-saver function allows the LCD to be turned off for its safe use when the car’s internal temperature rises (above
the guaranteed LCD temperature). While the LCD is turned off, if the recording continues and the temperature
decreases to the deactivating level, the LCD screen will be turned on automatically.
2)
#
The voice announcement: LCD off caused of high temperature.
- Announcement : “The LCD has been shut down due to the high temperature.”
3)
#
The LCD OFF caroused of high temperature should be kept until the temperature decrease even when the car engine
start.
4)
#
The Announcement is announced when the LCD OFF caroused of high temperature.
This announcement is announced only in the driving mode.
5)
#
The LCD OFF coursed of high temperature with the Announcement in the driving mode. The temperature decreases,
the LCD screen will be turned on automatically.
6)
#
The drive recorder is power off in the parking mode when the temperature is awfully high.
User's Manual _ 9
05
Components
Please check if all the basic components below are packed in the gift box before use.
If any of the components are missing or damaged, please contact your retailer.
Vehicle drive
recorder and holder
GPS Module
MicroSD Card
Reader
Rear camera
and cable(6m)
Cigar Jack
Power cable
Double-sided
Adhesive Tape
Power cable
Allen Key
Urive MicroSD
memory card
User’s Manual
Optional Accessories
Components are subject to change for performance and quality improvement without prior notice.
(The images for user’s understanding can be different from the real one)
Basic Components
