INSTALLATION INSTRUCTION

WEEE Number: 80133970

LED BULKHEAD

INTRODUCTION & WARRANTY

TECHNICAL DATA

Thank you for selecting and buying V-TAC Product. V-TAC will serve you the best. Please read

these instructions carefully before starting the installing and keep this manual handy for future

reference. If you have any another query, please contact our dealer or local vendor from whom

you have purchased the product. They are trained and ready to serve you at the best. The

warranty is valid for 5 years from the date of purchase. The warranty does not apply to damage

caused by incorrect installation or abnormal wear and tear. The company gives no warranty

against damage to any surface due to incorrect removal and installation of the product. The

products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would

void the warranty. This product is warranted for manufacturing defects only.

5

YEAR

WARRANTY

*

Model Was Lumens Input Power IP Rang Microwave Sensor

Emergency Baery

Backup

VT-08 8w 720 NO NO

VT-09 8w 720 YES NO

VT-11 10w 720 NO YES

VT-12 10w 720 YES YES

VT-15 15w 1400 NO NO

VT-16 15w 1400 YES NO

VT-17 17w 1400 NO YES

VT-19 17w 1400 YES YES

AC200-240V

50/60 Hz IP65

INSTALLATION INSTRUCITONS

STEP 1

Remove the cover by twisng the diuser an-clockwise and set aside. Carefully remove the LED tray and unplug it

from the LED driver, and set aside

STEP 2 STEP 3

Hold the product in place, mark & drill the holes Make the AC Power conneon through the

into the wall and nail the alligator into the hole. waterproof rubber cap.

STEP 4

Install the LED tray and diuser back and switch on.

SENSOR WIRING DIAGRAM

In case of any query/issue with the product please reach out to us at [email protected]

V-TAC EUROPE LTD, Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B

SENSOR SETTINGS

Detec Hold Daylight Stand-by Stand-by

Area Time Threshold Period dimming level

It can be The me period Daylight sensor The is the me period the is the dimming

adjusted by the light will priors moon the light keeps dimming level, the light keeps

combining be ON aer the sensor. Set down aer the last during the stand-by

DIP switches for last detecon. Threshold for detecon. Period.

speciapplicaon. Specineeds.

If disabled, only

moon sensor

will work

APPLICATION (Funcn Demo – Dimmable Control/Corridor funcn)

When mo is detected, when mon is detected, Aast den, the A stand-by period,

but the daylight is suient, and the daylight is light will be dimmed down the light will be OFF.

enough, the light will insucient, the light to stand-by dimming level

remain OFF. will be ON. (10%, 30%).

Pre-Install Emergency funcon test.

-Connect the AC cable according to the below diagram

-Press the test buon on the driver. The emergency funon will be acvated, and the charging indon will be o.

-Disconnect the bay pack, the charging indicated LED o.

NOTE: Ar installn, allow 36 hours to ensure full baery charge and then interrupt the supply.
