V-TAC VT-519 Manuale utente
WEEE Number: 80133970
INSTALLATION MANUAL
WALL SURFACE EMERGENCY EXIT LIGHT
VT-519
SAFETY:
• Installaon of this luminaire should only be carried out by a qualified electrician or
competent person to the current IEE Wiring Regulaons (BS7671)
• Please isolate mains prior to installaon/maintenance
• Check the total load on the circuit, including when this luminaire is fied, does not
exceed the rang of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress of Protecon) rang of this luminaire when deciding the
locaon for Installaon
• This product is Class II double insulated
• This product is non-dimmable
INSTALLATION:
• Provide power to the required point of installaon
• Remove the top cover as shown below in the image
• Using the top cover as a template, mark the locaon for, and drill 2 fixing holes
ensuring not to infringe with any joists, gas or water pipes or electrical cables.
• Feed the mains cable through the cable entry hole in the top cover.
• Connect mains cable into push-fit terminal block ensuring correct polarity is observed,
see the following figures for maintained, non-maintained and switched maintained
wiring diagram.
• Connect flying lead from baery pack to the socket on the PCB.
• Refit the exit sign to the top cover ensuring all 4 lugs lock into place.
• Switch on the power supply and ensure green LED indicator is illuminated
WARNING:
• This product must be disconnected from the circuit if subjected to any high voltage or
insulaon resistance tesng. Irreparable damage will occur if this instrucon is not
followed
• Recommended roune test procedure in accordance with BS5266
• Daily check – check that the status GREEN LED indicator is illuminated
• Monthly funconal test – simulate a mains supply failure for approx. 30 secs by
operaon of key switch or switching off a circuit breaker. Ensure normal supply is
restored aer test and the indicator status LED is illuminated
• Twice yearly conduct a one hour duraon test - simulate a mains supply failure for one
hour connuous test by operaon of key switch or switching off circuit breaker. Ensure
normal supply is restored aer test and the indicator status LED is illuminated
• Annual full three hour duraon test - conduct a three hour connuous duraon test.
Simulate a mains supply failure for three hour connuous test by operaon of key switch
or switching off circuit breaker. Ensure normal supply is restored aer test and the
indicator status LED is illuminated
• If the luminaire fails any of the above tests, please contact a qualified electrician.
L
N
Ls
Live
(brown)
Neutral
(blue)
L
N
Ls
Live
(brown)
Neutral
(blue)
Non Maintained
Opera�on
Maintained
Opera�on
Switched
Maintained Opera�on
Switched
Live
(brown)
Live
(brown)
Neutral
(blue)
L
N
Ls
GENERAL:
The LEDs fied in this product are non-replaceable. The unit should be recycled in the
correct manner when it reaches the end of its life. Check local authories for where
facilies exist.
Clean with a so dry cloth only, do not use aggressive cleaning products or solvents
which may damage the fing.
GUARANTEE
• This product is only guaranteed against defects in manufacture.
• The warranty is valid for two years from date of purchase.
• The warranty does not cover damage caused by improper installaon or abnormal wear
caused.
• The manufacturer does not warrant damage to surfaces resulng from improper
removal Or installaon.
In case of any query/issue with the product you can reach out to us at [email protected]
