Vankyo Performance 700 W Manuale utente
Performance 700 W
User Manual •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch
2
English
3 –22
Slovenčina
23 –42
Magyar
43 –62
Deutsch
63 –83
3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
4
What’s included
Projector
Remote (Batteries Not
Included)
User Manual
HD Cable
Power Cable
Product Overview
Lens
Infrared Receiver
Keystone
Corection Ring
IR Receiver
HDMI Port2
HDMI Port 1
Audio Out
USB Port 1
USB Port 2
Power Inlet
Power Switch
5
Ok (Short press) /
Focus (Long press)
Up (focus adjustment)
Right
Down (focus adjustment)
Left
Power Button
Back
Mute
Focus
Right
Down
Home page
Menu
Volume +
Input Source
Power On / Off
Focus
Up
Left
Back
Volume -
6
Quick Start
1. Projector Installation
1 Horizontal Placement
2 Ceiling Mounting
Note: Whichever installation option you select, make sure that:
1. The projector is centred directly in front of the wall/ screen, but not tilted or
positioned at a non-standard angle to the wall/screen.
2. Select the correct mode before projection via Menu > Picture Setting > Projection
mode.
Air Inlet
7
2. Power On / Off
Plug the power cord into
an outlet and press the
Power Switch
Take off the lens cover
After 8 seconds, press the
Power Button to turn on the
projector.
Press the Power Button twice tot run off the projector, then press the Power
Swtich
3. Image Adjustment
1. Rotate the keystone correction ring to correct the vertical keystone distortion until the
image is evenly rectangular.
2. Press the focus buttons on the remote to sharpen the image focus until the blurry
image becomes clear.
8
Tip: You can also press and hold the button on the projector to centre the focus
interface, then press the Up and Down buttons on it to adjust the focus.
3. Go to the Homepage > Down Button > Setting > Picture Setting > Image Scaling to
enlarge or reduce the image size.
4. Homepage Overview
The projector will enter the homepage after you will power it on and select the language
for the first time use. Press the down button to show more options as below.
Submenu for input
Source MultiMedia
HDMI 1
HDMI 2
Setting
Input Source
Mulltiscreen
Bluetooth
Connection Status
/ Bluetooth Setup
USB Disk Status
Wi-Fi Connection
Status / Wi-Fi Setup
9
Projector Connection and Input Source
Connect your device to the projector correctly, then press on the remote to access
the page below and select the right input source, or directly select the right input source
on the homepage.
1. USB Connections
Supported Photo Format:
BMP / JPG / PNG / GIF / JPEG
Supported Audio Format:
AC3 / AAC / MP2 / MP3 / PCM / FLAC / WMA
Supported Video Format:
AVI / MP4 / MKV / FLV / MOV / RMVB / 3GP / MPEG2 /
H.264 / XVID
Supported Text Format
TXT
2. Screen Mirroring
MultiScreen
MultiMedia
10
3. HDMI Connection
This option is for connecting a device with and HDMI output port.
HDMI®, the HDMI® logo, and High-Definition multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
4. Wired Speaker and Headphone Connection
This option does not require to select any input source.
Screen Mirroring
For iOS System
Screen Mirroring Wirelessly
1. Go to the Homepage > Input source, select MULTISCREEN as the input to enter the
CAST interface.
HDMI 1
HDMI 2
