Performance V630W
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch
2
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
3
Please read tis manual thoroughly before using this product and keep it for future
reference.
Packing list
Performance V630 Remote Carrying Bag User Manual
(Batteries not included)
AV Cable HD Cable Power Cable
Notice
Recommended – Video, Movie
NOT Recommended – PowerPoint, Excel, Word
4
Function overview
Lens
Focus
Keystone
Menu
Power Button
Input Source
Down
Left
Up
Right
Power Input
Speaker
Air Inlet
IR
HD-1
USB
Air Outlet
Memory Card Slot
AV In Audio Out
VGA
Play/Pause
Power Button
Fast Reverse
Up
Left
Back
Volume -
Mute
Fast Forward
Right
Down
Input Source
Menu
Volume +
Vertical/Horizontal
Keystone Correction
Play/Pause
5V Out
HD-2
5
Quick Start
1) Plug the power cord into an outlet.
2) Take off lens cover.
3) Connect your device to the projector correctly.
* Original USB cable (not included)
4) Press the Power Button to turn on the projector.
5) Select the correct input source to project your device.
6) Adjust the kickstand accordingly.
7) Adjust the keystone and focus ring to get the best image performance.
8) Press the Power Button twice to turn off the projector.
Keystone
Focus
6
Keystone Correction
Option 1: Adjust the keystone on the projector to adjust the image shape.
Option 2: Press on the projector/remote, then select OPTION > Keystone. Press the
button to select from H. Calibration, V. Calibration and Auto Adjust, then press
to start correcting the image shape.
Vertical & Horizontal Correction
TIPS:
•If you select Auto Adjust, the projected image will perform a vertical adjustment
automatically.
•The range of the digital keystone correction is ± 50°. To optimize your view
experience, please keep the keystone under 25° if digital adjustment is needed.
Input source
Press on the projector or remote to enter the interface of Input Source.
A. Screen Mirroring
7
B. VGA Connection
C. HD Connection
D. Multimedia Connection
8
Projector Connection
Screen Mirroring
IMPORTANT:
1. Before screen mirroring, please press the button on the projector/remote
to enter the interface on Input Source and select Screen Mirroring.
2. Press OK button on the projector / remote to switch the interfaces between Screen
Mirroring for iOS System and Screen Mirroring for Android System.
9
Screen Mirroring through Wireless Connection
For iOS System
* Streaming with cellular data
1) Turn on the projector, select Screen Mirroring as the input source to enter the
interface f Screen Mirroring for iOS System.
2) Go to the settings of your iOS mobile device and connect it to the WIFI of
Performance-V630W-XXXXXX (pwd:12345678). Please ignore the exclamation mark
before it.
3) Activate Screen Mirroring/Air Play Mirroring function on your iOS mobile device, then
search for the projector.
4) Select Performance-V630W-XXXXXX from the searching results to connect.
5) The display of your iOS mobile device will be projected to the wall/screen via cellular
data after a successful connection.
10
* Streaming with your router’s WIFI
1) Turn on the projector, select Screen Mirroring as the input source to enter the
interface f Screen Mirroring for iOS System.
2) Go to the settings of your iOS mobile device and connect it to the WIFI of
Performance-V630W -XXXXXX.
3) Visit http://192.168.49.1 from a browser on your mobile device, tap WIFI AP > Scan,
select your router’s WIFI and enter the right password, then tap Connect to continue.
4) Your router’s WIFI will be displayed on interface of Screen Mirroring for iOS System
after a successful connection.
