Vantron MOB-WBT-56 Manuale utente
Product Name: Module
Model Name: MOB-WBT-56
Hardware Manual
Rev 2.1
2021/03/01
Chengdu Vantron Technology Co., Ltd.
User’s Manual
Revision record
Rev.
Date
Change Description
Editor
1.0
2021-02-01
Initial Version
XJ.WU
MOB-WBT-56
WiFi 11ac + Bluetooth V5.0
Product Description
The device is Module, model name is MOB-WBT-56,
Features：
•IEEE 802.11a/b/g/n/ac dual-band radio with virtual-simultaneous dual-band
operation
•Single-stream spatial multiplexing up to 433.3 Mbps data rate.
•Supports 20, 40, 80 MHz channels with optional SGI(256 QAM modulation)
•Supports Bluetooth V5.0+EDR with integrated PA for Class 1.5 and Low
Energy (BLE).
•Concurrent Bluetooth, and WLAN operation
•Simultaneous BT/WLAN receive with single antenna
•Supports standard SDIO v3.0 and backward compatible with SDIO v2.0 host
interfaces.
- SDIO v3.0(4-bit) —up to 208 MHz clock rate in SDR104 mode
•BT host digital interface:
- UART (up to 4 Mbps)
•IEEE Co-existence technologies are integrated die solution
•ECI —enhanced coexistence support, ability to coordinate BT SCO
transmissions
around WLAN receives
•
Front view Back view
General Specification：
Model name
MOB-WBT-56
Product
Description
Support WI-FI/Bluetooth function
1Tx/1Rx 802.11ac/a/b/g/n WIFI+BT 5.0
Dimension
L*W*H:12*12*1.5mm
WIFI interface
SDIO v2.0/v3.0
BT interface
UART/PCM
Operating
temperature
-30℃to 85℃
Storage
temperature
-40℃to 125℃
Humidity
Operating humidity less than85% Non-condensing
Antenna
Model:81800UXX2
Antenna type: Internal Antenna
Connector Type: USS RFI
Peakgain:2400-2480MHz:2.66dBi, 5150-5850MHz:5.41dBi
Voltages：
Bluetooth Specification：
Wi-Fi RF Specification
2.4GHz RF Specification：
Support 802.11b,802.11g,802.11n (20MHz)
5GHz RF Specification：
Support 802.11a,802.11n (20MHz,40MHz),802.11ac (20MHz,40MHz,80MHz)
General Statements
1. Antenna List:
Antenna type: PIFA Antenna
Connector Type: USS RFI
BT/2.4GWIFI Antenna Gain: 2.66dBi
5GWIFI Antenna Gain: 5.04dBi
Antenna impedance: 50 (Ω)
Frequency range: 2400-2500MHz/5150-5850MHz
2. Any change of antenna type is not allowed. The module only used PIFA
antenna.
3. Host containing the modules must comply with FCC Rule requirement.
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device is intended only for OEM integrators under the following conditions:
(For module device use)
The antenna must be installed such that 20 cm is maintained between the antenna
and users, and the transmitter module may not be co-located with any other
transmitter or antenna. As long as 2 conditions above are met, further transmitter test
will not be required. However, the OEM integrator is still responsible for testing their
end-product for any additional compliance requirements required with this module
installed.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed (for example,
digital device emissions, PC peripheral requirements, etc.). The end-product may
need Verification testing, Declaration of Conformity testing, a Permissive Class II
Change or new Certification. Please involve a FCC certification specialist in order to
determine what will be exactly applicable for the end-product.
FCC Radiation Exposure Statement
This modular complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter. This modular must be installed and
operated with a minimum distance of 20 cm between the radiator and user body.
If the FCC identification number is not visible when the module is installed inside
another device, then the outside of the device into which the module is installed must
also display a label referring to the enclosed module.
This exterior label can use wording such as the following: “Contains Transmitter
Module FCC ID: 2AAGEWBT56/IC: 11152A-WBT56 Or Contains FCC ID:
2AAGEWBT56/IC: 11152A-WBT56”
When the module is installed inside another device, the user manual of the host must
contain below warning statements;
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may
cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
The module is not a limited module. Any company of the host device which install this
modular with limit modular approval should perform the test of radiated emissionand
spurious emission according to FCC part 15C : 15.247 and 15.209 requirement,Only if
the test result comply with FCC part 15C : 15.247 and 15.209 requirement，then the
host can be sold legally..
IC Warning
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
The modular can be installed or integrated in mobile or fix devices only. This modular cannot be
installed in any portable device.
IC Radiation Exposure Statement
This modular complies with IC RF radiation exposure limits set forth for an uncontrolled
environment. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter. This modular must be installed and operated with a minimum distance
of 20 cm between the radiator and user body.
For a host manufacture's using a certified modular, if (1) the module's IC number is not visible
when installed in the host, or (2) if the host is marketed so that end users do not have
straightforward commonly used methods for access to remove the module so that the IC number
of the module is visible; then an additional permanent label referring to the enclosed module:
"Contains Transmitter Module IC: " 11152A-WBT56 " or "Contains IC: 11152A-WBT56 " must
be used.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement
Le modular peut être installé ou intégré dans un mobile ou réparer une seule chose
Installation dans n’importe quel appareil portable.
Déclaration de rayonnement IC
Ce modular complies avec des radiations émettrices de rayonnement Environnement. Ceci ne
doit pas être co-localisé ou opérer avec des autres Ce modular doit être installé et obtenu avec
une distance minimale de 20 cm entre les radiateurs et le corps de l’utilisateur.
Pour un hôte, on utilise un modular, si (1) le numéro de module est non visible
Quand on est installé dans le serveur, or (2) si le propriétaire est commercialisé Straightforward
commonly used for the access to remove travail so that the number IC en vue Le module est
visible;Ensuite, le label permanent a été attribué au module: "Contient le Module IC:"
11152A-WBT56 " ou "contenu IC: 11152A-WBT56 " doit" be used.
