Vantrue Element 3 Manuale utente

English/Deutsch/Français/Polski Element 3

User Manual

122mmX130mm

70g

Voice-Controlled 3 Channel Dash Cam

更新内容：

英文33页有文字修改

Hey, find us here:

www.vantrue.net/contact facebook.com/vantrue.live

CONTENTS

VERZEICHNIS

CONTENU

SPIS TREŚCI

Installation

Installations

Installation

Instalacja

139

134

178

Warranty & Support

Kundendienst

Garantie & Support

Gwarancja & wsparcie

132

176

Specifications

Produktspezifikationen

Spéciﬁcation

Dane techniczne

Camera Overview

E3-Teile

Vue d'ensemble de la caméra

Budowa kamery

136

106

152

Basic Operation

Funktion

Opérationdebase

Podstawowe funkcje

135

What's in the box?

Was ist in der box?

Qu'y a-t-il dans la boîte？

Co znajdziemy w pudełku？

- 1 -

1. What’s in the Box?

dust-free

cloth*1

Warning

Stickers *2 L.

CPL Filter

A. VANTRUE® E3

Dash Cam

Type-C Rear

Camera Cable

(20ft)

User Manual

M. N.

B. RC05 Rear

Camera

Crowbar*1 K.

GPS Adhesive

Mount

VANTRUE®Wireless

Remote Controller

F. Type-C USB Data

Cable (3ft, for

data transfer only)

Car Charger with

Built-in Type-C

Cable (11.4 ft)

3M Adhesive

Stickers

Electrostatic

stickers *2

Optional Accessories

Element 2

User Manual

Voice-Controlled Dual Dash Cam

- 2 -

2. Camera Overview

ENEN

5 6 7

131211

VTJE1210130

NO. DescriptionName

Front Facing Camera for video recording road

Events;

2 Front Camera

Delivers sound during video playback;

Speaker

Connect to Type C cable or car charger for

external power supply;

Power Port

Type-C USB port for charging or transferring data;

Video stream port for streaming rear camera's

recording;

4 Type-C USB /

Rear Cam Port

2.45 inch LCD Display Screen;5 Screen

Camera for in-car video recording;7 Interior Camera

Steady green light means the camera is connecting;

6 REC

- 3 -

Records clear audio with the video footage;

Microphone

Serial Number for warranty registration.

Serial Number

9During video recording, long press to turn off the

screen and short press to stop recording; In standby

state, short press to confirm the action; In playback

mode, short press to stop/Start the video Recording;

Button

During video recording, short press will lock the

current file and capture a picture, long press for

power off;In standby status, short press will capture

a picture, long press will shut down;In WiFi state,

short press to exit WiFi, long press to power off;

14 Button

During video recording and standby, short press to

switch the video window; In menu setting and file

browsing, short press to display the previous option,

long press to scroll up to display options; in

playback mode, short press to fast forward; In WiFi

mode, press any key to exit WiFi;

Button During video recording and standby, long press to

quickly enter parking mode, and short press to turn

on/off the microphone; In menu settings, long press

to scroll through menu options, and short press to

display the next menu option; During file browsing,

long press to scroll to display file, short press to

display the next file; In playback mode, short press

to pop up the delete file menu; In WiFi mode, press

any key to exit WiFi;

Button

In the recording mode, long press to turn on/off

WiFi; In the standby state, short press to enter/exit

the setup menu, and long press to turn on/off WiFi;

In the WiFi mode, press any key to exit WiFi;

Button

- 4 -

15 MicroSD Card

Slot

16 Reset Button Press to force reset the device;

ENEN

Provides expandable storage (up to 512GB in

FAT32, U3 or higher).

LED Indicator

DescriptionLED

Steady green light Instandbystatus

Camera is recording

LED Status

REC

Blinking green light

14:39:07 02-10-2023

00:00:37 MP/H

1440P+1080P+1080P 30FPS

- 5 -

Screen Overview

3. Installation

3.1 Installing a Memory Card (Recommended: Vantrue U3 high-speed

microSD card).

Please insert a memory card (memory card capacity: 32GB-512GB, card

speed: U3/Class10/A2). The dashcam has certain requirements on the

card speed of the memory card. For reliable operation, we recommend

using a VANTRUE SD card(sold separately).

Loop recording OFF

Loop recording for 1 min

Loop recording for 3 min

Loop recording for 5 min

MIC is ON MIC is OFF

NO Memory card

inserted

G-Sensor ON

G-Sensor OF

Recorded driving

speed (KMH or MPH)

Video Resolution

GPS Signal Connecting

GPS Signal Locked

Voice Assistant is ON

Voice Assistant is OFF

MP/H

Memory card inserted

Icons for Indicating Buttons

Remote control is connected

Blinking means the remote

control is not connected

IR LED OFF

IR LED ON

IR LED AUTO ON/OFF

Recording Time

(Current Clip

Current Time (24H)

Snapshot

Emergency

File Locked

Current Date (MM/DD/YY)

Collision Detection ON

1080P Low Bitrates

Recording ON

720P Low Bitrates

Recording ON

Motion Detection ON

Low Framerate Parking

Mode

Time Lapse On

Wi-Fi OFF

2.4G Wi-Fi ON

5G Wi-Fi ON

2.4G Wi-Fi Connected

5G Wi-Fi Connected

If the camera is recording, please press the button to pause the

recording, then press the button to enter the menu, then enter

“System Setup,” select the format, and confirm to format the memory

card until it prompts "Formatted successfully''.

After inserting the memory card, if the screen prompts "Card error,

please format" (please note that the recorder does not record at this

time), please directly press the button to enter the menu and start

the formatting process.

- 6 -

Memory Card Installation: There is an icon indicating the insertion direction

of the memory card. Please push the memory card into the card slot

according to the direction indicated by this icon, until a "click" sound is

heard in the card slot, indicating that the memory card is inserted properly.

The microSD card should be formatted once a month to maximize the

lifetime of the memory card.

Pleasedonottakethecardoutwhenthecameraisrecordingincase

theimportantvideofilesmissing.

REMINDER:

ENEN

Before using this card, please follow the steps below to format it properly:
