Variscite DART-SD410 Manuale utente

DART-SD410 based on Qualcomm Snapdragon 410

Evaluation Kit Quick Start Guide

123456

1514 17

18 19

8 7

Features:

1. 5V DC In Jack (J18)

2. USB Debug (J21)

3. Microphone Jack (J16)

4. Headset Jack (J15)

5. Gigabit Ethernet Jack (J22)

6. USB Device (J20)

7. Dual USB Host (J14)

8. Speaker connector placeholder (J19)

9. LVDS Header (J11)

10. 24bit LVDS expansion placeholder (12)

11. HDMI (J9)

12. UART0 Header (J7)

13. Capacitive Touch (J4)

14. I2C/SPI Header (J5)

15. GPIO/I2S Header (J8)

16. JTAG Header (J6)

17. Camera Board PCB Connector (J10) –

Interfaces with VAR-EXT-CB410

18. micro SD Card slot (J3)

19. RTC Battery Holder (JBT1)

20. Back Button (SW8)

21. Boot select switch (SW3)

22. Home Button (SW5)

23. USB Boot switch (SW7)

24. Power Button (SW9)

25. On/Off switch (SW10)

Evaluation kit initial Setup

1. Carefully remove the 7” LCD and

VAR-SD410CustomBoard board from the

package.

2. Plug the supplied USBtypeAtomicroBcable

between the USB debug connector (J21) and

a PC USB port. Wait for USB device

enumeration and driver installation.

3. Connect the supplied 5V DC power supply to

5V DC In Jack (J18).

4. PowerOntheboardbyOn/Offswitch (SW10).

5. The Board will boot into preloaded OS.

Downloaded from Arrow.com.

P/N VSS0113B - v1.1

DART-SD410 based on Qualcomm Snapdragon 410

Evaluation Kit Quick Start Guide

Setting the Host PC for Debug

1. Download any PC terminal program.

Variscite suggests using Putty

2. Set PC terminal parameters as follows:

- Baud Rate: 115200

- Data bits: 8

- Stop bits: 1

- Parity: None

- Flow Control: None

Preparing images

1. The Package includes a microSD card which

contains a recovery SD Card image for

installing OS and recovery.

The image can also be downloaded from

Variscite FTP site.

Booting and OS Burning

1. Insert included SD Cart into SD Card

slot (J3).

2. Set Boot select switch (SW3) to the ON

position in order to boot from SD Card.

3. Plug a USB type A to micro B cable

between the USB Debug connector (J21)

and a PC USB port.

4. Power ON the VAR-SD410CustomBoard

By plugging the wall adapter power

connector into the 5V power jack (J18) and

to a 120VAC~240VAC power source.

5. The system will read the image from

external SD card and boot into Debian

Release.

6. Navigate to /media/linaro/OSes/Android or

to /media/linaro/OSes/Debian folder on the

SOM using PC terminal program.

7. Execute update.sh script by running

./update.sh

This will flash the OS to the On SOM

eMMC.

8. Wait till Done message appear.

9. Power off the VAR-SD410CustomBoard.

10. Set Boot select switch (SW3) to the OFF

position to boot from the On SOM eMMC.

11. Power ON the VAR-SD410CustomBoard

12. Boot messages are printed in the PC’s

terminal window and the flashed OS will

start.

13. For additional instructions follow:

http://variwiki.com/index.php?title=DART-

SD410_Android_Getting_Started

Additional Support Links

1. Wiki pages:

http://variwiki.com/index.php?title=Main_Pa

2. Variscite Customers Portal:

http://www.variscite.com/support/variscite-

customer-portal

3. VAR-DVK-SD410:

https://www.variscite.com/product/evaluatio

n-kits/dart-sd410-kits/

4. DART-SD410:

https://www.variscite.com/product/system-

on-module-som/cortex-a53-krait/dart-sd410-

qualcomm-snapdragon-410/

5. VAR-SD410CustomBoard:

https://www.variscite.com/product/single-

board-computers/var-sd410customboard/

Thank you for purchasing Variscite’s

product.

For additional assistance please

contact: sales@variscite.com
