VarTech Systems VT14B-C1 Manuale utente

14” Fast Scan Series User Guide 150-049

14”

Console Mount

Auto Sync Color Monitor

MODEL NUMBER:

VT14B-C1

User’s Guide

Read these instructions completely before attempting to operate your new Color Display.

VarTech Systems Inc.

Solutions for Demanding Applications

Industrial CRT and Flat Panel Displays

14” Fast Scan Series User Guide 150-049

TABLE OF CONTENTS

Sections Page

Warning and Caution 1

Operating Instructions 2

Controls 4

Mode Operations 5

Specifications 7

5BNC Connectors 3

Chassis Mount Mechanical 6

14” Fast Scan Series User Guide 150-049

-1-

The following warnings and cautions are for your safety, for the prevention of injury from electric

shock and for the safe operation of the monitor. Please read them carefully.

♦ Do not block the ventilation slots or insert any objects into the monitor through them.

♦ Do not spill water onto the monitor or spray aerosol cleaners directly onto its surfaces when

cleaning.

♦ Always position and operate the monitor on a stable and safe surface.

♦ Do not install the monitor in a damp area, or where it may be exposed to rain or other sources of

water.

♦ Ensure that all accessible cables cannot be walked on, tripped over or damaged by furniture or

other transportable objects.

♦ If the monitor is damaged or fails to function correctly, disconnect it from the AC source. Do not

attempt to repair it yourself. Consult a qualified service technician.

♦ Serious electrical shock hazards exist within the covers of the monitor. Under no circumstances

should these covers be removed.

WARNING

Changes or modifications to this unit not expressly approved by the party

responsible for compliance could void the user's authority to operate the equipment.

NOTE

This equipment has been tested and found to comply with the limits for a class B digital device,

pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference using one or more of the following

measures:

- Reorient or relocate the receiving antenna;

- Increase the separation between the equipment and the receiver;

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is needed;

- Consult the dealer or an experienced radio/TV technician for help.

SAFETY WARNINGS

Section

14” Fast Scan Series User Guide 150-049

-2-

Video Signal Correction

The monitor is supplied with a 15pin HD connector (HD15F), 5BNC input connectors and an optional

9pin connector (DB9F) arranged as shown below:

R H

OFF

75Ω ∗

HiZ

OFF

DISABLED

ENABLED*

DIP

SWITCH

*Factory Default

DDC

OPERATING INSTRUCTIONS

Section

Pin Function Pin Function

1 Red Video In 8 Blue Return

2 Green Video In 9 NC (grounded in monitor)

3 Blue Video In 10 Digital ground

4 NC 11 Digital ground

5 NC 12 NC

15 Pin D CONNECTOR:

This is an industry standard connector providing easy connection to VGA type video sources.

6 Red Return 13 Horizontal sync

7 Green Return 14 Vertical sync

15 NC

14” Fast Scan Series User Guide 150-049

BNC CONNECTORS

These connectors allow the monitor to work with Red, Green and Blue coaxial cable. The monitor

synchronization may be Sync on Green, Composite sync or Separate Horizontal and Vertical sync.

The “H” input is used for composite sync.

Video inputs:

Red, Green, Blue. 0.7v p-p into 75 Ω

Sync inputs:

1. Sync on green 0.3v p-p into 75Ωsuperimposed onto green video. (3 wire)

2. Composite sync TTL level, positive or negative, combined horizontal or vertical sync. (4 wire)

3. Separate syncs TTL level, positive or negative, separate horizontal and vertical sync. (5 wire)

DIP SWITCH SETTINGS

SW1,2,3 75Ω/ Hi Z. The input impedance of the Red, Green, Blue BNC inputs can be switched

between 75Ωand High impedance. For normal operation the switches should be in the ON position

(75Ω). If it is required to connect more than one monitor to a single video source (loop through) then

the switches may be switched to OFF so that the combined input impedance of more than one

monitor remains at 75Ω. These three switches have no effect on the 15 way D input connector.

SW4 PRIORITY. This switch becomes relevant when there are video signals present

on both the BNC and the 15 way D connectors. The monitor will automatically select

the video signal which has the highest priority. If only one video source is connected to

the monitor then the priority switch should have no effect.

SW4 ON: The BNC input is highest priority

SW4 OFF: The priority is controlled by the VT key on the front controls.

-3-

14” Fast Scan Series User Guide 150-049

— +



— +

LED

Function

Contrast

Brightness

Horizontal Position

Horizontal Size

Vertical Position (keystone)*

Vertical Size (pincushion)*

Switch

DIGITAL CONTROLS

The digital controls are located on the rear side of the monitor.

Digital Display Control

∗ Press Function button. LED will blink allowing for keystone & pincushion adjustments.

-4-

DIGITAL CONTROLS

Section

14” Fast Scan Series User Guide 150-049

-5-

MODE OPERATIONS

In the normal mode of operation, the LED is not flashing.

Disable Keypad

1.Press and release the FUNCTION (upper right) switch. The LED will now be flashing.

2.Simultaneously press the FUNCTION and the VT (upper left) switches. Note that the VT switch is

not labeled. The LED will momentarily be off and then resume flashing.

3.Press and release the FUNCTION (upper right) switch. The LED will not be flashing.

4.To enable the keypad, repeat the above steps.

Factory Default Settings

1.Press and release the FUNCTION (upper right) switch. The LED will now be flashing.

2.Simultaneously press the VT switch and the VERTICAL SIZE + (bottom right) switches. The LED

will momentarily be off and then resume flashing. All stored setups will be deleted except original

factory setups.

3.Press and release the FUNCTION (upper right) switch. The LED will not be flashing.

Display Storage

1.Adjust the display for Brightness, Contrast, Horizontal Position, Horizontal Size, Vertical Position,

Vertical Size. This is done while the LED is not flashing.

2.Press and release the FUNCTION (upper right) switch. The LED will now be flashing.

3.Adjust the display for Keystone and Pincushion.

4.Press the CONTRAST + switch. This will store the display and return the keypad to normal

operation. The LED will not be flashing.

14” Fast Scan Series User Guide 150-049

-7-

ENGINEERING SPECIFICATIONS

Size 14”

Pitch .28mm

Resolution Capabilities CGA to XGA

Active Display Area 11” x 8.3” / 279.4mm x 210.82mm

Deflection Angle 90º

Phosphor Medium Short B22

Power Source 90 - 265 volts AC autoranging

50/60 Hz, 1.5 amps ac

Power Consumption 90 Watts

Horizontal Frequency 30kHz to 54kHz

Vertical Frequency 45Hz to 100Hz

Bandwidth 90MHz

Video Input Connector HD15(F) and 5BNC

Video Input Signal Analog 0.7 p-p

Sync Separate Horizontal and Vertical TTL syncs

OR Composite TTL Syncs

OR Sync on Green

Temperature Operating: 0 to 55ºC

Storage: -25 t0 70ºC

Humidity Operating: 10 to 90% NC

Storage: 0 to 95% NC

Degaussing Automatic at power ON & Manual

Note: For continued compliance with Electromagnetic Compatibility limits, this

monitor must be used with the signal lead supplied.

Section

SPECIFICATIONS

14” Fast Scan Series User Guide 150-049

150-049-001

6.17.03

VARTECH SYSTEMS INC.

HEADQUARTERS

11529 Sun Belt Ct.

Baton Rouge, Louisiana 70809

Toll-Free: 800.223.8050

International Phone: 001.225.298.0300

Fax: 225.297.2440

E-mail: sales@vartechsystems.com

www.vartechsystems.com
