Verizon 4G LTE Scheda tecnica

Get to Know

Your Device

4G LTE BROADBAND ROUTER WITH VOICE

FRONT VIEW

The Verizon 4G LTE Broadband Router with Voice is a wireless device that

delivers Internet connectivity and telephone service. You can make a phone

call and simultaneously provide network and Internet connectivity for up to 10

devices via Wi-Fi and up to 3 devices via Ethernet. Refer to this guide for setup

and usage tips.

NOTE:

A voice plan is not required for E911 calls. Emergency service is available regardless of

your service plan.

Power on/off button

Network indicator

Wi-Fi indicator

Local Area Network

(LAN) indicator

WPS button

Scroll left/right

Select button

DISPLAY

ICON STATUS ICON MENU/CAROUSEL

Voice mail messages Wi-Fi name/password

Connected devices Connected devices

Data signal strength indicator* Voice signal strength indicator*

Network activity indicator Data signal strength indicator*

Internet connectivity indicator Battery charge indicator

Network roaming indicator Software update

Voice signal strength indicator* About

Home

Data usage*

*NOTE:

Voice and Data availability is dependent upon the selected price plan.

LED STATES

LED COLOR-STATE DESCRIPTION

Power

button Blue-solid Normal operation

Blue-blinking Battery is charging

Red-solid No AC power. Device operating on battery only

Internet

indicator Red-solid Indicates internet connectivity

Unlit Indicates no internet connectivity

Wi-Fi

indicator Blue-solid Wi-Fi user(s) connected but not transmitting or

receiving

Blue-blinking Wi-Fi user(s) connected and transmitting or receiving

Unlit No Wi-Fi user(s) are connected

LAN

indicator Blue-solid User(s) connected but not transmitting or receiving

Blue-blinking User(s) connected and transmitting or receiving

Unlit No user(s) connected

WPS

button Amber-blinking Searching for wireless devicesto connect via WPS. You

have two minutes to start WPS on your wireless device

Green-solid WPS connection successful

Red-blinking Router could not find the wireless device. Try again to

establish the WPS connection

BACK VIEW

**NOTE: Future feature

Optional antenna port 1

Optional antenna port 2

Phone port 1

Phone port 2

Home Security port**

Ethernet port 1

Ethernet port 2

Ethernet port 3

Power port

Desktop stand

Top cover

Battery cover

BEFORE YOU BEGIN

STEP 1: INSTALL THE BATTERY

1. Remove the battery cover on the underside of the device.

2. Plug in and insert the battery, keeping the red cable to the center of the device

and the metal contacts facing up, then replace the battery cover.

STEP 2: PLUG IN THE POWER CORD

1. Plug the power cord into the device power port.

2. Plug the power adapter into an AC wall outlet. The device will power on and

guide you through a welcome process for connecting via Wi-Fi. Once complete,

verify at least one bar of the voice signal strength indicator ( ) is lit. If not,

move device to an alternative location that provides a stronger signal.

WARNING! Be sure to use the power cord that came with your device to avoid damage that

may void the warranty.

STEP 3: CONNECTING YOUR TELEPHONE

This device provides ports for up to two telephones. Both ports use the same

telephone number.

1. Unplug your telephone’s cord from your wall’s telephone jack.

WARNING! Do not plug this device into your telephone wall jack.

2. Plug the end of the telephone cord that was just removed from the wall jack

into one of the two phone ports on the back of the device. The other end of

the cord must remain plugged into the back of your telephone’s base unit.

NOTE: The telephone and telephone cord are sold separately. Rotary, pulse dialing, and Voice over

IP (VoIP) phones are not supported.

IMPORTANT!

If the device is in active mode and running on the battery alone, only voice calls are

supported.

If the Power button is pressed and held, the device will enter charging mode. When

in charging mode, the device screen displays the battery charge indicator ( ). To

resume normal operation, press the Power button. To completely turn off the device,

disconnect from AC power.

STEP 4: INITIAL ACTIVATION

Transferring Your Existing Number

Customers transferring a phone number will not be able to send or receive calls on the 4G

LTE Broadband Wireless Router with Voice until the transfer process is complete. This

process can take 2–10 business days.

To check the status of your transfer, visit www.verizonwireless.com/lnp or call

(877) 567-4899.

Activating a New Number

Your device automatically activates the new number after the device is powered

on, as long as network coverage is available. Make a call to test service.

NOTE: If you are not subscribed to a plan with voice service and would like to add this feature, dial

*611 to sign up for service.

IMPORTANT!

• A voice plan is required to make and receive calls.

• Customers may need to use the three-digit Area Code when dialing local

and long distance numbers.

SETTING UP VOICE MAIL

To set up and manage your voice mail, dial *86 and follow the system prompts.

For more details about your voice mail service, visit

www.verizonwireless.com/voicemail.

CONNECTING INTERNET/NETWORK DEVICES

You can connect up to three wired devices such as laptops, printers and gaming

consoles via Ethernet.

1. Plug the end of an Ethernet cable* into one of the three Ethernet ports.

2. The other end of the cable must remain plugged into the Ethernet port of the

device you wish to connect.

Sold separately

Connect up to three

devices via Ethernet

SYSTEM REqUIREMENTS FOR WI-FI CONNECTIVITY

To connect wirelessly to your 4G LTE Broadband Router with Voice, devices

such as laptops and tablets must be Wi-Fi capable.

• Compatible with all major operating systems.

• Works with the latest versions of browsers, including Android™, Chrome™,

Firefox®, Internet Explorer®, Safari™ and Mobile Safari™.

PASSWORDS

Your default Wi-Fi Network Name (SSID) and Wi-Fi Password will appear on

the 4G LTE Broadband Router with Voice display upon initial power up. You can

also access your Wi-Fi Name and Wi-Fi Password using the following steps:

1. Power on your 4G LTE Broadband Router with Voice.

2. On the device screen, select Menu and open the Wi-Fi Name and Password

option.

3. Select Open to display the Wi-Fi Name/Password.

To access your Admin Password for the 4G LTE Broadband Router with Voice

Web Interface:

1. Select Menu and select the About option.

2. Select Open > More > More to display the Web Interface Admin Password.

NOTE: Your default Wi-Fi and Web Interface Admin Password are the same. To change the Wi-Fi

Password, follow the instructions in ACCESSING ADVANCED SETTINGS.
