Vestamatic Excellence Manuale utente

Excellence

Sunshade Control

Installation and Operating Instructions

Safety precautions

Please note, that the

Vestamatic

Excellenc

sunshade cont

rol requires an

operating voltage of 230 V

, 50 Hz. Therefore, the connection box may

only be installed and connected by a qualified professional electrician.

If work is performed on sunshade or roof windows, which are controlled by

the

Vestamatic

Excell

ence

sunshade control, the operating voltage must be

turned off at the connection box.

The control was designed for correct use as described in the operating

instruc

tions. Any changes or modifications thereof are not permissible and

result in loss of al

l warranty claims.

Check the Excellence

sunshade control for signs of mechanical damage

immediately after unpacking. If there is any damage due to the shipping,

notify the supplier immediately.

Do not start up the control in case there is any damage!

If safe operation of control or sunshade can not be guaranteed, the

Excellenc

sunshade control must be turned off immediately and protected

against unintentional operation.

the

Excellenc

sunshade control is not connected to a rain or frost pro

tecto

rs, we recommend to set the control (depending on the sunshade

design) to manual operation at temperatures below +1 °C (32 °F) for safety

reasons. That way, automatic extending (e.g. at sunlight

) can be avoided.

Make sure to always replace used batteries

in the operator and display

element with batteries of the same type.

Caution!

Risk of explosion, if incorrect battery types are used.

Dispose of used batteries only according to hazardous waste

regula

tions.

The use of plug

in power supplies, that are

not optionally delivered by the

Excellence

sunshade control manufacturer can cause malfunctions and/or

damage to the control and is thus not permissible.

Follow the installation and operating instructions carefully.

Contents

Safety precautions

age 2

Contents

page 3

–

Introduction

page 5

Installation

Installing the control unit

page 6

–

First steps

Start

page 8

–

Touch

screen calibration

page 10

Operation

page 11

Menu general

page 12

Measured values

page 13

Info

General

ge 13

Touch

screen lock

page 14

Communication test

page 14

Status

page 15

Settings

General

page 16

Time

page 17

User settings

General

page 18

Wind

page 19

Sun

page 20

Temperature

page 21

Time

page 22

Rain

page 23

Run time

page 23

verse time

page 24

Contents

Extended settings

General

page 24

Code

page 25

Test mode

page 26

Wind sensors

page 26

Expanded wind range

page 27

Wind velocity unit

page 27

Wind sensor type

page 28

Wind response delay

page 28

Sun senso

page 29

Sun sensor assignment

page 29

External button direct/deadman

page 30

Rain priority

page 30

Rain motor 1

page 31

Rain motor 2

page 31

Continuous up command/run time

page 32

Continuous down command/run time

page 32

Motor 2 roof win

dows

page 33

Language

page 33

Error and alarm messages

page 34

–

Maintenance and care

page 36

Technical data

page 37

Menu navigation

page 38

Adjustable values and times

page 39

–

Wiring diagrams

Connection of decentralized controls

page 41

Direct connection of 2 drives

page 42

Connecting the operator element Excellence

via a 2

wire interface

page 43

Setting the rain sensor sensitivity

page 44

Introduction

Congratulations for buying the

Vestamatic

Excellenc

sunshade control.

You

have purchased a high

quality product that features many practical functions

and is manufactured according to the highest quality standards.

Please take the time to read these operating instructions carefully prior to

start

up, in order to guarantee op

timum effectiveness and reliability.

The delivery extent of the

Vestamatic

Excellenc

sunshade control includes the

following items:

Control unit, consisting of

–

connection box

–

operator and display element (touch

screen)

Wall mounting plate fo

r operator and display element

Mounting material

Display cleaning cloth

Four batteries (not applicable for 2

wire interface)

Installation and operating instructions

In the following, the term “control” is used for the entire system, consisting

connection box (sensor motor box) and operator and display element (touch

screen monitor).

Installation Installing

the control unit

Please note, that the installation of the

Vestamatic

Excellence

sunshad

control may only be carried out by a qualified professional electrician.

If you have purchased a control with radio connection, avoid large metal

objects between control and operator and display element and adjacent to the

mounting location. Large metal

objects can impair the radio connection.

Turn off the operating voltage.

Remove the connection box cover and mount the housing with the four

holes in the housing corners. Mount the housing in such a way, that the

cable inlets are located on the low

er housing side. Do not mount the con

nec

tion box in a location exposed to direct sunlight.

Connect the power supply cables and external connections according to

the wiring diagram (see page 41).

Mount the control unit out of the range of people, children and animals.

All cables must be permanently wired.

Attention:

Currently valid VDE

regulations must be observed when

connecting the device, in particular DIN VDE 0100/0700 as

well as the currently valid regulations of your local power

supplier and th

e accident prevention regulations.

The output is potential

free, which is important when triggering decen

tralized controls.

When directly connecting a motor (230 V~, 50 Hz), make sure to bridge

ter

minal C of the motor output with terminal L of

the mains connection.

Installing

the control unit Installation

If you have purchased a control unit with two

wire interface, mount the

operator and display element as follows:

–

Mount the wall bracket in the desir

ed location. The mounting location of the

operator and display element must not be exposed to direct sunlight.

–

Remove the left cover from the battery compartment of the operator and

display element, by pulling it to the left and off the housing.

–

Pierce

the circular openings prepared for the cable inlets on the housing

rear side.

–

Connect the two

wire interface.

–

attach the battery compartment cover in its original position.

–

Hang the operator and display element onto the wall bracket.

–

Connect th

e voltage supply of the connection box.

Proceed as described in section “First steps”.

Ensure you have re

attached the cover!

If you have purchased a radio

controlled unit, perform the installation as follows:

–

Turn on the connection box operating voltag

–

Remove the covers from the battery compartment of the operator and

display element, by pulling them to the side and off the housing.

–

Insert the delivered batteries as indicated.

Proceed as described in section “First steps”.

Ensure you have re

attac

hed the cover!

If you have decided on the wall mounting, teach

in the operator and display ele

ment to the connection box by performing a ‘communication test’ (see page 14).

That way, you can find a suitable mounting location, that allows for trouble

free

communication between touch

screen and connection box.

The mounting location of the operator and display element must not be ex

posed to direct sunlight.

–

Mount the wall bracket in the desired location.

–

attach the battery compartment cover in its o

riginal position.

–

Hang the operator and display element onto the wall bracket.

Important:

For test purposes, the system can be operated in the test mode

(see “Extended settings” on page 24).

First steps

Start

Please note, starting

up the control requires opening the connection box.

Therefore, start

up must be carried out only by a qualified professional electri

cian.

Systems with two

wire interface:

Ensure that the slide

switch, loca

ted in the terminal cut

out behind the left bat

tery compartment of the operator and display unit, is set in the upper position.

The slide switch in the connection box next to the radio module (for the exact

location, please see the wiring diagram) must al

so be set in the upper position.

Other configuration steps are not required.

Radio

controlled systems:

Ensure that the slide

switch, located in the terminal cut

out behind the left bat

tery compartment of the operator and display unit, is set in the lo

wer position.

The slide switch in the connection box next to the radio module (for the exact

location, please see the wiring diagram) must also be set in the lower position.

The operator and display element must be “taught

in” to the connection box as

foll

ows:

–

Activate the operator and display element.

–

Insert the batteries in the compartments of the operator and display

element or connect the plug

in power supply (available as special

accessory) to the operator and display element.

Start

First steps

The following message will be displayed on the touch

screen of the operator

and display element.

Now, you can select between demo and

teach

in mode. In the demo mode, no radio

connectio

n between the operator and

display element and control unit can be

established. Therefore, control operations

or configuration steps cannot be per

formed. If the operator and display element

has not been “taught

in” with the con

nec

tion box, select the te

ach

in mode by

pressing the ‘TEACH

IN’

button.

After selecting the teach

in mode, the following message is displayed:

Make sure, the supply voltage for the con

nec

tion box is turned on. If it is not, turn on

the operating voltage and wait for at least

5 seconds. Then tap the ‘TEACH

IN’

but

ton of the connection box (see wiring dia

gram) with an

insulated

screwdriver. The

red LED next to the button will flash. If the

operator and display element recognizes

the connection box, the LED will stop flash

ing

and the touch

screen will display the

standard user interface. The system is now

ready

operate.

Taught

in operator and display elements can be deleted by pressing the

‘TEACH

IN’

button on the connection box for 5 seconds.

Touch

screen calib

ration

After long periods of operation, the touch

screen accuracy may deteriorate and

require re

calibration.

Activate the calibration function as follows:

Turn off the operating voltage by moving the slide

switch located behind

the left battery comp

artment (in the terminal cut

out) into the opposite

position.

Press the touch

screen and keep it pressed.

Turn the operating voltage back on, by moving the slide

switch back into its

original position.

Keep the touch

screen pressed for 3 seconds

until the operator and display

element is activated.

When the following screens are displayed, follow their instructions: First

press the dot in the upper left corner then press the dot in the lower right

corner. Then press the screen again at any posit

ion in order to return to

nor

mal operation.

Indice

Altri manuali Vestamatic Unità di controllo

Vestamatic

Vestamatic IF SMI RS-485 DIN RAIL Series Manuale utente

Vestamatic

Vestamatic Rolltec Pro Manuale utente

Vestamatic

Vestamatic Touch Centre XL 4C Wired Manuale utente

Vestamatic

Vestamatic Rolltec Plus 500 Manuale utente

Vestamatic

Vestamatic Rolltec Plus G/S Manuale utente

Vestamatic

Vestamatic VestaLogo 500 Manuale utente

Vestamatic

Vestamatic Rollmat Plus V3.1 Manuale utente

Vestamatic

Vestamatic Vesta Building Controller Manuale utente

Vestamatic

Vestamatic IF SMI KNX 24VDC Manuale utente

Vestamatic

Vestamatic MC BS4 Manuale utente

Manuali Unità di controllo popolari di altre marche

Festo

Festo Compact Performance CP-FB6-E Manuale elenco delle parti

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuale utente

JS Automation

JS Automation MPC3034A Manuale utente

JAUDT

JAUDT SW GII 6406 Series Guida rapida

Spektrum

Spektrum Air Module System Manuale utente

BOC Edwards

BOC Edwards Q Series Manuale utente

KHADAS

KHADAS BT Magic Manuale utente

Etherma

Etherma eNEXHO-IL Manuale utente

PMFoundations

PMFoundations Attenuverter Manuale utente

GEA

GEA VARIVENT Manuale utente

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuale utente

Altronix

Altronix LINQ8PD Istruzioni per il montaggio

Eaton

Eaton Powerware Series Manuale utente

WAGO

WAGO 750-407/040-000 Manuale utente

Sony

Sony CCU-590 Manuale utente

Graco

Graco 25D614 Manuale utente

Task Force Tips

Task Force Tips YE-RF-900 Manuale di programmazione

Shini

Shini SPV-U Series Manuale utente
